Summary of Contents for Ubiquity Smart Technology DDR-E08AA
- Page 1 DDR-E08AA Hardware User Manual 2015 FEB V1.0...
-
Page 2: Table Of Contents
DDR-E08AA Hardware User Manual Contents CAUTION .............................. 1 Introduction ............................2 1. Product Overview ........................2 2. Main functions ........................... 2 Unpacking ............................3 1. Accessories ..........................3 2. Unpacking ........................... 3 Installation ............................3 Product appearance ......................... 4 1. Front Panel ..........................4 2. -
Page 3: Caution
DDR-E08AA Hardware User Manual A. CAUTION To our dear customers! Thank you for using our products. If you encounter any problems when using, please do not hesitate to contact our resellers. We will provide excellent services to you via our resellers. -
Page 4: Introduction
DDR-E08AA Hardware User Manual B. Introduction Product Overview This equipment is an excellent digital surveillance product designed specifically for the security use. Using embedded LINUX operating system, it makes the system more stable. Using standard H.264 video compression and G.711A audio compression technology achieves audio and video functions such as high-quality, low bit rate and single-frame playback. -
Page 5: Unpacking
DDR-E08AA Hardware User Manual C. Unpacking Accessories ★ Power cable and adaptor AC100-240V/DC12V 4A x 1PCS ★ HDD screws x 4pcs ★ Mouse (optional) Unpacking When you receive the product, check first whether the packing of the equipment has obvious damage. The protective material used for the package during transport can cope with most of the accidental impact;... -
Page 6: Product Appearance
DDR-E08AA Hardware User Manual E. Product appearance Front Panel Under the live viewing mode, press MENU to enter the MENU MENU main menu. Exit the current menu. Under the live mode, press the REC button to enter recording menu. STOP Stop the playback under the playback mode. -
Page 7: Rear Panel
DDR-E08AA Hardware User Manual Rear Panel 8ch DVR illustration 8 CH Video Input (BNC) E-SATA LAN Port VGA output HD digital output USB 3.0 DC12 Power Input DC12V... -
Page 8: Installation Illustration
DDR-E08AA Hardware User Manual Installation Illustration Video input Input interface is BVC type; input signal is PAL/NTSC BNC（1.0VP-P，75Ω）. The Video signal should comply with national standards, a higher signal to noise ratio, low distortion, low-interference; clear images, no deformation, nature color and appropriate brightness. - Page 9 DDR-E08AA Hardware User Manual Regular degaussing will help to maintain the normal operation of the monitor. Keep away from equipment with strong electromagnetic interference. Using TV as video output device is an unreliable alternative. It is also required to minimize the time of use and strictly control the power, the interference caused by neighboring devices.
-
Page 10: Q & A And Maintenance
DDR-E08AA Hardware User Manual F. Q & A and Maintenance 1. Q & A Q 1. After power on, DVR doesn’t work. A: The possible causes: 1. Wrong power input 2. bad connection of power cable 3. Power error 4. Firmware update error 5. - Page 11 DDR-E08AA Hardware User Manual 3. Video transmission distance is too far or video transmission line attenuation is too much. 4. Wrong settings of colors, brightness in the DVR Q 6. No recorded file in local side A : The possible causes: 1.
-
Page 12: Maintenance
DDR-E08AA Hardware User Manual 4. Bad DVR output Q 12. Networking not stable A : The possible causes: 1. Networking not stable 2. IP conflict 3. MAC conflict 4. LAN card error (PC/DVR) Q 13. USB backup error A : The possible causes: 1. - Page 13 DDR-E08AA Hardware User Manual Do not remove audio/video cables when the DVR is powered on, or they will be damaged. Do not use the TV interface in the DVR video output (VOUT), or the DVR output circuit will be damaged easily.
-
Page 14: Appendix : Specifications
DDR-E08AA Hardware User Manual G. Appendix : Specifications System CPU: Hisilicon SoC Operating system：Linux Storage Device/Interface Build in SATA interface x 2, compatible SATA / SATA II / SATA III HDD( Max. 8TB) E-SATA x 1(Max. 16T) User Interface DVR IR remote control Video And Other Dual video：HD OUT/VGA... - Page 15 DDR-E08AA Hardware User Manual Browser： MS IE7-IE11 Support Equipment Support megapixel DTV Camera Power DC12V / 4A Operating Temperature 0-45℃ ★Product specifications are subject to change without notice; please contact us for the latest information.
- Page 16 Contact Information: Ubiquity Smart Technology (UST Taiwan) TEL: +886-3-5777-368 FAX: +886-3-5777-339 Mail: sales@ubiquitysmaet.com...
