Page 2
01-08 English 09-16 Deutsch 17-24 Français...
Page 3
High Resolution HD Digital Camera CMOS Sensor * Maximum video size:1920*1080(2M pixels) * Maximum snapshot image size: 4000*3000(12M pixels snapshot) * Video mode: MJPG and YUY2 * Hi-speed USB 2.0(recommended) * Transmission rate: 1920*1080up to 30fps under MJPG mode * Signal-noise ratio: greater than 48dB *Dynamic range: greater than 72dB * Image focus: 3cm to infinity * Non-compression image processor...
Page 4
Your new Webcam will ship with the following items. * 1 ×TeckNet C018 1080P Webcam * 1 ×Driver CD * 1 ×User Manual Notice: Please make sure the webcam is plugged into the USB port before installation. 1. Insert Driver/Application Disc into CD-ROM drive,install the driver by double clicking Setup and...
Page 5
2. Click “Automatically run Realtek camera manager when you start up the computer”, the camera icon will appear in the Taskbar. 3.Start your webcam by selecting the USB Video Device application from Start menu as shown below.
How to preview the picture? Right Click the Webcam Icon in the Taskbar, and choose “Show Main Panel“. Left click the preview window in the upper left corner, then you can see it. How to take a picture? Select “Photograph” icon and choose your favourable image size. Click “save” and choose a disk or folder for your pictures, and then click “snapshot”.
Page 7
How to adjust the resolution? Enter“Data Information”and choose “disable”, you can adjust the resolution of preview window. The window size will keep VGA size.
Page 8
How to use settings and advanced setting? Click “Image Control”then“Camera Control”, you can adjust the quality of the picture and other settings. Adjust the parameter to your favourite setting It's very important to set the frequency the same as your local power supply Click it under low-light surrounding At the following panels you can set image style, photo frame,filter effect, face track and digital zoom for your video and pictures.
Page 9
Photo frame setting field In this area, users can achieve Effects setting field face tracking function...
Page 10
We warrant that products purchased from authorized distributors will meet the applicable product specifications and be free from all defects in design, assembly, materials and workmanship. Please contact TeckNet retailers, or visit our website for more information about the product. Please access Technical Support and Return on the web for help.
Page 11
Hohe Auflösung HD Digitalkamera CMOS-Sensor * Maximale Videogröße: 1920 * 1080 (2 Mio. Pixel) * Maximale Bildgröße Snapshot: 4000 * 3000 (12 Mio. Pixel Snapshot) * Video-Modus: MJPG und YUY2 * Hi-Speed USB 2.0 (empfohlen) * Übertragungsrate: 1920 * 1080 bis zu 30 Bilder pro Sek.
Page 12
Ihre neue Webcam wird mit dem folgenden Zubehör ausgeliefert: * 1 × TeckNet C018 1080P Webcam * 1 × Treiber CD * 1 × Benutzerhandbuch Hinweis: Bitte stellen Sie sicher, dass die Webcam mit dem USB-Anschluss verbunden ist, bevor Sie die Installation ausführen.
Page 13
2. Setzen Sie das Häckchen bei “Automatisch Realtek Kameramanager ausführen beim Systemstart”, das Kamerasymbol wird in der Taskleiste angezeigt werden. 3.Starten Sie die Webcam, indem Sie die USB Videogerät- Anwendung im Startmenü auswählen, wie unten angezeigt .
Page 14
Wie erzeugt man die Vorschau eines Bildes? Klicken Sie in der Taskleiste mit der rechten Maustaste auf das Symbol der Webcam , und wählen Sie „Zeige Hauptbedienfeld“, ein Linksklick auf das Vorschaufenster in der oberen linken Ecke und es wird angezeigt. Wie nimmt man ein Foto auf? Wählen Sie das “Fotografie”-Symbol und wählen Sie ihre favorisierte Bildgröße aus.
Page 15
Wie kann die Auflösung eingestellt werden? Geben Sie die “Dateninformationen ” ein und wählen Sie “deaktivieren”. Sie können nun die Auflösung für das Vorschaufenster einstellen. Die Fenstergröße wird die VGA-Größe beibehalten.
Page 16
Wie nimmt man Änderungen der Einstellungen und der Erweiterten Einstellungen vor? Klicken Sie auf “Bildkontrolle” dann auf “Kamerakontrolle”. Sie können nun die Qualität des Bildes einstellen neben weiteren Einstellungen. Passen Sie die Parameter für die beliebtesten Einstellungen an Es ist sehr wichtig, die Frequenz an die ihrer lokalen Einstellungen anzupassen Schalten Sie es ein in Umgebungen mit wenig Restlicht...
Page 17
Einstellungsfeld für Fotorahmen In diesem Bereich können Einstellungsfeld für Effekte Benutzer die Gesichtverfolgung einstellen...
Page 18
Wir garantieren, dass Produkte, die von autorisierten Händlern gekauft werden, den geltenden Produktspezifikationen entsprechen und frei von allen Mängeln in Design, Montage, Material und Verarbeitung sind. Bitte kontaktieren Sie einen TeckNet Einzelhändler oder besuchen Sie unsere Website für weitere Informationen über das Produkt.
Page 19
Caméra Numérique Haute Résolution HD à Capteur CMOS * Résolution vidéo maximale : 1920*1080(2M pixels) * Résolution photo maximale : 4000*3000 (capture en 12M pixels) * Mode Vidéo : MJPG et YUY2 * USB 2.0 Hi-speed (recommandé) * Vitesse de transmission : 1920*1080 jusqu'à 30ips en mode MJPG * Rapport signal/bruit : supérieur à...
Page 20
Votre nouvelle Webcam est envoyée avec les éléments suivants. * 1 × Webcam TeckNet C018 1080P * 1 ×CD de pilote * 1 ×Manuel d'Utilisation Remarque: Veuillez-vous assurer que la webcam est connectée à un port USB avant l'installation. 1. Insérer le Disque Pilote/Application dans le lecteur de CD-ROM, installer le pilote en double cliquant sur Installation et le système exécutera automatiquement les programmes nécessaires et affichera les...
Page 21
2. Cliquer sur “Lancer automatiquement le gestionnaire de caméra Realtek au démarrage de l'ordinateur ”, l'icône de la caméra va apparaître dans la barre des tâches. 3. Démarrer votre webcam en sélectionnant l'application Périphérique Vidéo USB dans le menu Démarrer comme illustré...
Page 22
Comment prévisualiser les images ? Faire un clic droit sur l'Icône de la Webcam dans la barre des tâches, et choisir “Afficher le Panneau Principal “. Cliquer sur la fenêtre de prévisualisation dans le coin supérieur gauche, alors vous pourrez la voir. Sélectionner l'icône “Photographie”...
Page 23
Comment régler la résolution? Entrer dans “Information Données” et choisir “inactif”, vous pouvez régler la résolution de la fenêtre de prévisualisation. La taille de la fenêtre restera en VGA.
Page 24
Comment utiliser les réglages et réglages avancés ? Cliquer sur “Contrôle de l'Image” puis sur “Contrôle de la Caméra”, vous pouvez ajuster la qualité de l'image et d'autres réglages. Ajuster les paramètres à votre réglage favori Il est très important de régler cette fréquence comme celle de votre alimentation secteur Cliquer ici en environnement sombre Sur les panneaux suivants vous pouvez régler le style l'image, le cadre photo, les effets...
Page 25
Champ de réglage du cadre photo Dans cette zone, les utilisateurs peuvent activer la fonction de Champ de réglage des effets suivi de visage...
Page 26
Veuillez contacter les revendeurs de TeckNet, ou vous rendre notre site web pour plus d'information sur le produit. Pour obtenir de l'aide, veuillez accéder au Support technique et Retour sur le web.
Page 27
TeckNet PO BOX 122 Liverpool L9 7 WQ www.tecknetonline.co.uk...
