TempleTouch Premium User Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Table of contents:
Safety warnings
Section 1:

Quick Start

Section 2:
measuring guidelines
Section 3:
Directions for use
Section 4:
Room Temperature Display
Section 5:
Using ODPT
Section 6:
Setting the operating scale
Section 7:
Installing and replacing the batteries
Section 8:
About body temperature measurement
Section 9:
Troubleshooting and special indications
Section 10:
Care and cleaning
Section 11:
Technical Information
Section 12:
Warranty and Service Information
IMPORTANT! Read Instructions for Use before using the thermometer.
Safety warnings:
1. Keep the thermometer out of the reach of children.
2. Do not drop the thermometer or expose to heavy shock. The unit is not shock proof.
3. Do not immerse thermometer in water or any other liquid.
The unit is not water proof.
4. Do not store the unit in direct sunlight, at a high temperature, in high humidity or
dust. Performance of the unit may be degraded.
5. Stop using the thermometer if it operates erratically or if display malfunctions.
6. Clean the thermometer probe before storing (see section 10).
7. Do not attempt to disassemble the unit except to replace the batteries.
1. QUICK START
1. Press and release the POWER button.
2. Unit will beep twice when ready.
3. Verify temple or underarm mode: Push the SET button if you wish to change.
4. Hold firmly to temple or underarm, wait for long beep and read results.
2. Measuring guidelines:
1. Measurement body location is the temple, in proximity to the temporal artery,
between the end of the eyebrow and the hairline.
2 2. Do not place the thermometer on scarred tissue compromised by skin disorder, open
– Medicine Timer
TM
F or
C
o
o
non-invasive
sensor
Set
button
Power
button
Timer
button

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Premium and is the answer not in the manual?

Questions and answers

Summary of Contents for TempleTouch Premium

  • Page 1: Quick Start

    Table of contents: non-invasive sensor Safety warnings Section 1: Quick Start button Section 2: measuring guidelines Section 3: Directions for use Power button Section 4: Room Temperature Display Section 5: Using ODPT – Medicine Timer Section 6: Setting the operating scale F or Timer Section 7:...

  • Page 2: Directions For Use

    sores or abrasions and patients in trauma. 3. Temperature readings are affected by many factors including exercise and drinking hot or cold beverages prior to taking a reading. 4. Consult your physician when using drug therapies that may raise the local skin temperature in the forehead;...
  • Page 3 For underarm measurement: a. Place the thermometer probe in the center of the armpit as shown (figure 6). Gently press the thermometer's probe in an upward motion. b. leave the patient's arm raised up until completed. Correct placing and good contact with the skin ensure reliable readouts.
  • Page 4 How to Set & Start Timer a. Setting- up the time cycle: The ODPT timer is set for 6 hours by default. To change the cycle (from 1-8 hours): 1. Switch OFF the thermometer. 2. Press and hold the SET button. 3.
  • Page 5 6. Setting the operating scale °F or ° C The device setting is by default Fahrenheit (°F). To change the scale to °C, or back to ° F: 1. While OFF, press and hold the SET button. 2. Continue pressing SET, then press the POWER button. 3.
  • Page 6 of day and body location. Hot or cold baths, physical exercise, smoking and drinking, hot or cold drinks may change body temperature by one degree or more. The following table shows the temperature ranges: What is fever? Average normal temperature ranges Forehead Over 37.8°...
  • Page 7 Indication: The measured temperature is above 107.6°F (42°C) and the display presents: HI Instruction: 1. Turn the unit OFF and then ON again. 2. Retake temperature using proper technique (see section 3). 3. If still reads HI, this indicates that the patient has a high fever. WARNING! A high fever or low body temperature requires seeking immediate medical attention Indication 1:...

  • Page 8: Care And Cleaning

    10. Care and Cleaning * Wipe the tip and probe with an alcohol swab or a cotton swab moistened with 70% isopropyl alcohol before & after each use. After cleaning, wait at least 2 minutes before taking a measurement for the unit to readjust to room temperature.
  • Page 9 12. Warranty and Service Information: All private label Walgreens products have a lifetime guarantee against manufacturers defect under normal use. Following the directions closely will ensure years of dependable operation. If the thermometer does not function properly, first check the batteries (see section 7).
