Lanzar VBD1900MP Owner's Manual

Mobile audio system

Advertisement

Quick Links

VBD1900MP
OWNER'S MANUAL
Mobile Audio System
• PLL Synthesizer Stereo Radio
• Digital Compact Disc Player
• Automatic Memory Storing
• Electric Undetachable Panel
• Preset Equalization
• Electronic Shockproof (ESP) Function
• CD Changer Control
• Remote Control

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBD1900MP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lanzar VBD1900MP

  • Page 1 VBD1900MP OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • Digital Compact Disc Player • Automatic Memory Storing • Electric Undetachable Panel • Preset Equalization • Electronic Shockproof (ESP) Function • CD Changer Control • Remote Control...
  • Page 2: Table Of Contents

    CONTENTS Installation ........3 Pausing playing ......12 Take out screw before installation...3 Previewing all tracks ....12 DIN Front-Mount (Method A) ..3 Repeating individual tracks or Installing the unit......3 whole CDs ........12 Removing the unit......4 Playing all tracks in random ..12 DIN Rear-Mount (Method B) ...5 Selecting disc ......12 Using the front panel ....6 MP3 operation .......13...
  • Page 3: Installation

    INSTALLATION Notes: TAKE OUT SCREW BEFORE INSTALLATION • Choose the mounting location where Before install the unit, please remove the the unit will not interfere with the two screws. normal driving function of the driver. Take out screw before installation •...
  • Page 4: Removing The Unit

    INSTALLATION Sleeve Note: to install the short threading terminal L Key of the mounting bolt to the back of the Outer Trim Ring unit and the other long threading terminal to the dashboard. Spring Washer Hex Nut Metal Strap R Key Mounting Bolt Plain Washer Tapping Screw...
  • Page 5: Din Rear-Mount (Method B)

    INSTALLATION DIN REAR-MOUNT (Method B) 1. Factory-installed radio bracket 2. Car radio mounting bracket 3. Screw 4. After aligning the car radio mounting bracket with the factory-installed radio bracket, tighten the screws (5 x 5mm) at 2 places on each side. 5.
  • Page 6: Using The Front Panel

    USING THE FRONT PANEL 1. When the front panel is in initial state and the unit is off, press the right-top inside button on the back of the front panel shortly to turn on the unit and some information will be shown on the CLOSE Button display, then you can press and hold the button for several second to turn...
  • Page 7: Wiring Connection

    WIRING CONNECTION AUX IN CABLE (BLACK) WHITE (BLACK) CD CHANGER CONNECTOR SOCKET FUSE ANTENNA CONNECTOR RCA CABLE (GREY) WHITE GREEN SUBWOOFER CABLE BLUE POWER ANTENNA IGNITION SWITCH (ACC+) CHOKE YELLOW MEMORY BACK-UP (B+) BLACK GROUND (B-) FRONT Rch FRONT Lch WHITE GREY SPEAKER...
  • Page 8: Operation

    OPERATION LOCATION OF KEYS 18 11 26 19 20 21 14 22 27 15...
  • Page 9: Sound Adjustment

    OPERATION • SWITHCHING ON/OFF THE UNIT The beep is generated when every Switch on the unit by pressing right- button is pressed. top button (1) on the back of the front - BEEP OFF mode: panel shortly and some information will The beep is disabled.
  • Page 10: Esp Function

    OPERATION sensor (26). Press the function keys on the handset to control the system. • ESP FUNCTION If the unit has the electronic shockproof function, it can be shockproof about several ten of seconds and this depends on the EPROM IC of the unit. •...
  • Page 11: Radio Operation

    OPERATION RADIO OPERATION scan preset station. When the field strength level is more than the • SWITCHING TO RADIO MODE threshold level of stop level, the Press MODE button (6) shortly to radio is holding at that preset select radio mode, the radio mode number for several seconds with appears in the display together with releasing mute, then searches...
  • Page 12: Cd Operation

    OPERATION CD OPERATION CDC OPERATION • SWITCHING TO CD MODE You can connect a CD changer to the unit If there is no CD inserted in the driver: with CDC operation version only. Information When the front panel is in State 3, press on handing CDs, inserting CDs and button (4), the front panel will slide down operating the CD changer can be found in...
  • Page 13: Mp3 Operation

    OPERATION MP3 OPERATION • REPEATING THE SAME TRACK Press RPT button (21) to continuously • SWITCHING TO CD (MP3) MODE repeat the same track. Press it again If there is no MP3 disc inserted in the to stop repeat. driver: When the front panel is in State 3, •...
  • Page 14: Display Information

    OPERATION - Use the corresponding buttons to pressing BND/LOU (ENTER) button. select the characters A to Z, blank, 0 to 9, _, -, +. “MP3” icon turns on when MP3 disc is played - Press SEL button to confirm entry and blinks when it is in navigation mode.
  • Page 15: Mixed-Cd Operation

    OPERATION MIXED-CD OPERATION DISC NOTE If available, the unit can play the mixed- A. Notes on discs: CD disc (the disc contains both CD audio 1. Attempting to use non-standard shape tracks and MP3 files). discs (e.g. square, start, heart) may When you insert a mixed-CD disc into damage the unit.
  • Page 16: Remote Control

    REMOTE CONTROL FUNCTION KEYS & CONTROL 1. PWR = Power ON/OFF Button 2. DSP (0) = Display Button (_, -, +, 0 For MP3 Operation) 3. SEL = Select Button (Character Shift Right For MP3 Operation) 4. VOL = Volume Up Button (Character Select (A,B~8,9,0) For MP3 Operation) 5.
  • Page 17: Specification

    SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 165 (D) x 50 (H) Tone Controls : ± 10 dB - Bass (at 100 Hz) : ± 10 dB - Treble (at 10 KHz) Maximum Output Power : 4 x 50 Watts Current Drain...
  • Page 18: Trouble Shooting

    TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution No power. The car ignition switch is If the power supply is properly not on.
  • Page 19 www.lanzar.com...
  • Page 20 88-C2580-03...
