PA168X SIP Phone Http Setup Guide (V1.60)
PA168X SIP Phone Http Setup Guide
Configured by WEB....................................................................................................... 2
：
......................................................................................................... 3
Audio settings: ............................................................................................................... 5
Dial Plan settings:.......................................................................................................... 7
：
................................................................................................ 10
Other settings:.............................................................................................................. 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the PA168X and is the answer not in the manual?

Questions and answers

Related Manuals for PalmMicro PA168X

Summary of Contents for PalmMicro PA168X

  • Page 1: Table Of Contents

    PA168X SIP Phone Http Setup Guide (V1.60) PA168X SIP Phone Http Setup Guide Configured by WEB....................... 2 Network Setting ： ......................3 Audio settings: ....................... 5 Dial Plan settings:......................7 SIP Protocol Setting ： ....................10 Other settings:......................15...

  • Page 2: Configured By Web

    PA168X SIP Phone Http Setup Guide (V1.60) When PA168X SIP phone is properly installed, you can set each parameters through PC and Web browser. Details please refter to 《Pa168X SIP phone Spec and Install》 Configured by WEB Double click icon to open the IE browser. Input the IP address of the...

  • Page 3: Network Setting

    Select this item to enable DHCP mode. With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. PA168X IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters...
  • Page 4 PA168X SIP Phone Http Setup Guide (V1.60) it is a protocol especially designed for them. With this system, ADSL ISP automatically assigns all the required IP parameters to any device connected to it when the device log on. modem： If the IP phone used with modem, please select this item to get relevant network parameters auto.

  • Page 5: Audio Settings

    DNS server here. ● mac: MAC address is the physical address supplied by the Ethernet NIC. PA168X phone is shipped from the factory with a unique algorism MAC address printed on the back of the base. Audio settings: Fig 1.3 Audio Setting...
  • Page 6 PA168X SIP Phone Http Setup Guide (V1.60) ● codec5: Set the priority 5 of the audio compression algorithm. The options are g729，g7231，g711u，g711a , gsm, ilbc and null. ● codec6: Set the priority 6 of the audio compression algorithm. The options are g729，g7231，g711u，g711a , gsm, ilbc and null.

  • Page 7: Dial Plan Settings

    PA168X SIP Phone Http Setup Guide (V1.60) list. dtmf : Set ring as ordinary rings in different frequency not disturb: Set the phone do not ring by selecting this item. user define：Set ring as music saved by user by selecting this item.
  • Page 8 PA168X SIP Phone Http Setup Guide (V1.60) dialnum: Use dial number by selecting this item. With this item selected, please enter the dial prefix into dial number field. prefix: Use specially service by selecting this item. Hotline: Use Hotline function by selecting this item. With this item selected, please enter the hotline number into dial number field.
  • Page 9 PA168X SIP Phone Http Setup Guide (V1.60) ● innerline: Enable/disable innerline call by selecting corresponding items from dropdown list. disable: Disable call innerline by selecting this item. enable: enable call innerline by selecting this item. ● innerlineprefix: With enable selected in innerline dropdown list, please fill the prefix number pick up to inner line, such as 0.

  • Page 10: Sip Protocol Setting

    PA168X SIP Phone Http Setup Guide (V1.60) ● Use digitmap: Enable/disable digit map by checking/unchecking the box. SIP Protocol Setting： Fig 1.5 SIP Protocol Setting ● use service: Enable/disable service by checking/clearing this box. To make calls through SIP Proxy Server, please check this box; otherwise, phone can only make IP-to IP calls.
  • Page 11 PA168X SIP Phone Http Setup Guide (V1.60) keimen: Use Keimen’s system mediaring: Use Mediaring’s SIP system italkbb: Use ItalkBB’s SIP system nortel: Use Nortel’s SIP system net2phone: Use Net2phone’s SIP system Fwd: Free SIP service; please visit www.freeworldialup.com more information.
  • Page 12 PA168X SIP Phone Http Setup Guide (V1.60) disable: Select this item when the sip proxy server and IP phone in the same LAN, or the sip proxy system supports the IP phone working behind the LAN. enable: When the system does not support IP phone working behind the LAN, please select this item to search public IP address of the NAT device.
  • Page 13 PA168X SIP Phone Http Setup Guide (V1.60) ● phone number: The local phone number or username of this phone, usually is allocated by system. ● account: With SIP system which requires authentication, please put the username/account into this field. ● pin: With SIP system which requires authentication, please put the password into this field.
  • Page 14 PA168X SIP Phone Http Setup Guide (V1.60) ● dtmf payload : When DTMF select rfc 2833.This parameter can be used indicating type of RTP payload type. The value can be use integer 96-101. ● prack: Enable/disable support pre-ack(RFC3262) by checking/clearing this box.

  • Page 15: Other Settings

    MAC address only at the FTP server specify by upgradeaddr item . ppp id: pa168X phone will find matching firmware binary file and configuration file of the ppp id only at the FTP server specify by upgradeaddr item .
  • Page 16 PA168X SIP Phone Http Setup Guide (V1.60) upgradeaddr item . ● upgrade addr: Put URL of upgrade server supplying upgrade program and configurations into this field , URL rules is below: HTTP://IP address or domain name: port number FTP: //IP address or domain name: port number TFTP: //IP address or domain name: port number ●...
  • Page 17 PA168X SIP Phone Http Setup Guide (V1.60) Fig 1.7 Setting Page using ordinary pin with Debug set as 0 [disable] ● Save Settings : Click this button to save the configuration and the phone will reboot. Once the phone reboots successfully, the new configuration is effective.
  • Page 18 PA168X SIP Phone Http Setup Guide (V1.60) Name field following 001, and then input 5989426454 into Phone number field. Then Jack’s number 5989426454 is saved in phone book. Then please click Save/Back button. In normal state, you can use speed dial to call numbers saved in phone book.
  • Page 19 PA168X SIP Phone Http Setup Guide (V1.60) Reserves the right to make changes in technical and product specification without prior notice. PA168X SIP Phone Http Setup Guide (V1.60) Copyright© 2003---2007 All rights reserved...
