The HDMI Switch is with a remote control for easy switching within four digital
video sources. It allows four HDMI devices to one HDMI display that is a convenient
way of arranging the HDMI devices.
In addition, the HDMI SWITCH can help end-user to connect more digital devices
such as DVD player, PS3, Digicam, or Handcam.
Compatible with HDMI 1.3a
Connects audio & video to HDMI compatible HDTV, LCD Monitors or Digital
Projectors.
Supports 2.25Gbps signaling rate for 480i/p, 720i/p, and 1080i/p resolution with
8/10/12-Bit color depth
Support source active port auto detection
Four HDMI receiver input, one HDMI transmitter, support to WUXGA mode
Easy switching between four digital video sources using IR remote control of the
switch button on the switcher.
Supports HDCP compliant devices.
INTRODUCTION
HS-V3A0-A
FEATURES
Advertisement
Table of Contents
Summary of Contents for FuchiComm HS-V3A0-A
- Page 1 INTRODUCTION HS-V3A0-A The HDMI Switch is with a remote control for easy switching within four digital video sources. It allows four HDMI devices to one HDMI display that is a convenient way of arranging the HDMI devices. In addition, the HDMI SWITCH can help end-user to connect more digital devices such as DVD player, PS3, Digicam, or Handcam.
-
Page 2: Package Contents
SPECIFICATION Function Specification Model No. HS-V3A0-A PCB No. HS-V3A0-PR** Chipset Parade PS421 Input 4 x HDMI Female A type Output 1 x HDMI Female A type Port Selection Select button or IR Remote Power 1 x Red Color LED Select... - Page 3 Installation...
-
Page 4: User Manual
User Manual: Connect the HDMI cables from the HDMI source devices to the HDMI switch inputs. Connect the HDMI cable from your display ( monitor or projector ) into the HDMI switch output. Plug the 5V DC power supply into the HDMI switch. Select the desired input as follows: From the switch front panel –...
