Please read this manual carefully before operating your navigation device. Retain it for
future reference. Operation of our device is very easy, simply you press the button or
touch the screen.
What is GPS?
The Global Positioning System (GPS) is a satellite-based navigation system made up of
a network of 24 satellites placed into orbit by the U.S. Department of Defense. GPS was
originally intended for military applications, but in the 1980s, the government made the
system available for civilian use. GPS works in any weather conditions, anywhere in the
world, 24 hours a day. There are no subscription fees or setup charges to use GPS.
Safety is the most important, the followings you must
comply with:
1.Always operate the vehicle in a safe manner. Do not become distracted by the
navigation while driving, and always be fully aware of all driving condition. Minimize the
amount of time spent viewing the screen of the navigation while driving and use voice
prompts when possible. Do not enter destinations, change settings, or access any
functions requiring prolonged use of the unit'controls while driving. Pull over in a safe
place before attempting such operations.
2.Do not kink or crease the power cable or place heavy objects on the power cable. Fire
can result from damaged power cables.
3. Immediately power off the player and unplug the AC adapter if smoke or odors emit
from the player or adapter.
4. Note that malfunctions may occur if you use the product in places where static
electricity occurs frequently.
5. Never attempt to open and repair the product yourself.
6. Please use the battery that the machine provided , or the product maybe
Damaged
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TrailBlazer 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mapmyindia TrailBlazer 2

  • Page 1 Please read this manual carefully before operating your navigation device. Retain it for future reference. Operation of our device is very easy, simply you press the button or touch the screen. What is GPS? The Global Positioning System (GPS) is a satellite-based navigation system made up of a network of 24 satellites placed into orbit by the U.S.
  • Page 2 7. Do not use for many hours at extremely low or high temperature. 8.If the product emits an unusual order or excessive heat, or you notice anything else that seems unusual, do not use the product . 9.when you install the mount, fixed well the machine to motorcycle handlebars, to avoided the machine fall down and damaged 10.
  • Page 3 Name of the components: Host GPS Device: Power Key: Power on/off Display Screen MINI USB Port: 1.Exchange the data with PC by MINI USB Cable. 2.Charge the GPS device by connecting AC adaptor or car charger Reset: Press this key to reset the system Speaker External Power supply: Connected with outside power supply like GPS storage battery.
  • Page 4 2. Take 4pcs screws &4pcs nuts out from the bag. 3. In accordance with the direction of the arrow shown, put the nut into the screw of the external power The direction shown by the arrow. Put the screw into the screw jack of the fixed-disk mount Finally fixed the external power backup &...
  • Page 5 L direction, until it is fixed with machine C) Install the mount to the motorbike handlebar 1. Place the mount in proper position. 2. And then take it off from the U-shape mount 3. As shown, At last fixed U-shape mount & handlebar with screws Note: when the user install, need to consider the location of installation to make sure safety, also need pay attention &...
  • Page 6 End line of the external power Connecting devices(CAR) Power Supply The device has three ways of power supply: battery supply , AC Adapter and car adapter (1)Lithium battery When the device doesn't connect with the adaptor, it is supplied by the lithium battery. (2)AC adapter (usually optional) When the device connects with the adaptor, it is supplied by the outer power supply.
  • Page 7 3) CAR adapter Connect the Car adapter to USB port on the device and plug the other end to cigarette jack. Notice (1)Charge the battery fully before initial use. (2)Charging time is normally about 3 hours. Charge 1.Install the GPS to bracket and make sure there is a well connection between host and bracket power connector 2.Make sure the device connector has been locked in order to avoid the water entering and lead short-circuit.
  • Page 8 unplugged from the power supply before you attempt to connect the unit to any external device. The Device comes with an USB port for connecting to a PC with the supplied USB cable. Caution:Plase remove the USB line after finishing the data transmission(just operate it as the USB flash disk) Connect to Bluetooth earphone(usually optional) 1.
  • Page 9 Music , Enter Music interface. Play Playing Time Pause Item name Stop Playing Progress...
  • Page 10 Previous Volume Adjustment Next Return Circle play Close Random play Video , Enter Video interface. Play Playing Progress Pause Volume Adjustment Stop Return...
  • Page 11 Previous Close Next EBook , Enter EBook interface. Item name & format Load book mark Previous Next Current page/Total page Return...
  • Page 12 Close Photo , Enter Photo interface. Previous Return Next Close Full screen Rotation Zoom in Zoom Out...
  • Page 13 . When you initially orient, you had better to go tto a open place without upper shelter and wait for patiently . Setting , Enter Setting interface.
  • Page 14 Bluetooth , Enter Bluetooth interface. 1.Enter Bluetooth and tap “setting” 2. Enter Setting and tap “search Device” 3.Search Bluetooth earphone, link the device 4. link success, it shows:...
  • Page 15 1. Only support Bluetooth earphone (which can search the phone, but can not connect) 2. According to instructions ,after successfully connected,, you can enjoy a personal listening. Tip: When connected the Bluetooth earphone, the speaker of the host will auto turn off Volume Date Click...
  • Page 16 Click to adjust lightness. Enter this interface to see the power situation. Language Theme Enter this interface select language. You can choose different colour for background according to your like...
  • Page 17 NaviPath click to adjust the navigation path. choose the connection way to GPS once. System You can see relevant information from left picture entering the interface...
  • Page 18 tap it,GPS search star test. tap it,it gets back to original setting. When you tap the menu or operate the device, touch panel isn't sensitive, you need to adjust the touch panel. Specification ○ Weight: 190 G ○ product size: 105mmX88.7mmX23mm ○...
  • Page 19 ○ Cold Start: <=45sec (Open Sky,-130dBm) ○ Satellite Reacquisition Time Accuracy: 100 Ms ○ Position Accuracy: <5m (Outdoor,-135dBm) ○ GPS frequency 1575.42MHz ○ Sensitivity: -157 dBm ○ GPS Module: High Sensitivity Receiver (NXP GNS7560) ○ Accuracy and velocity < 10 meter, 0.1m/s ○...
