ENERGYCATCHER

INSTALLATION AND SERVICING INSTRUCTIONS

TO BE LEFT WITH THE USER

Technical and illustrative data are not binding and can be modiﬁ ed without prior notice.

The descriptions and illustrations in the present booklet are for guideline purposes only.

RAVENHEAT MANUFACTURING LTD, CHARTISTS WAY, MORLEY, LEEDS, LS27 9ET

TEL. 0044( 0)113 252 7007

Website : www.ravenheat.co.uk - E-mail : sales@ravenheat.co.uk

Supplied By www.heating spares.co Tel. 0161 620 6677

This is an energy saving product

SAP RECOGNISED

CERT ACCREDITATION

FAX: 0044 (0)113 238 0229

Table of Contents

Need help?

Do you have a question about the Energycatcher and is the answer not in the manual?

Questions and answers

Summary of Contents for Ravenheat Energycatcher

Page 1 Technical and illustrative data are not binding and can be modiﬁ ed without prior notice. The descriptions and illustrations in the present booklet are for guideline purposes only. RAVENHEAT MANUFACTURING LTD, CHARTISTS WAY, MORLEY, LEEDS, LS27 9ET TEL. 0044( 0)113 252 7007 FAX: 0044 (0)113 238 0229 Website : www.ravenheat.co.uk - E-mail : sales@ravenheat.co.uk...
Page 2 Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 3 Thank you for purchasing Energycatcher combiplus or combistore patented energy saving system which when used in conjunction with the arrangement listed below will save substantial amounts of energy along with meaningful carbon reductions. Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 4 (item 11 page 20). Note: Energycatcher is designed to ﬁ t Ravenheat 120/150 models only. It can be ﬁ tted to any Band A condensing combi though the installer must have written approval from manufacturer of the boiler and the manufacturer of Energycatcher.
Page 5: Table Of Contents
TABLE OF CONTENTS SECTIONS PAGE INTRODUCTION GENERAL LAYOUT TECHNICAL DATA OPERATING DELIVERY INSTALLATION ENERGYCATCHER FIXING WATER CONNECTIONS ENERGYCATCHER WITH REMOTE TANK STORE ENERGYCATCHER PIPEWORK SERVICING ALTERNATIVE ENERGYCATCHER SYSTEMS LIST OF SPARE PARTS COMBIPLUS COMBISTORE PFGHRD FGHRS A0-1 B1-1 System System...
Page 6: Introduction
91 % efﬁ cient in converting gas to heat. When - CO2 saving - Pluming is almost eliminated due to operation Energycatcher is ﬁ tted to a boiler, it adds up to 7 % to the boiler efﬁ ciency and thereby an overall 7% saving (thermal gain).
Page 7: General Layout
Section 2 GENERAL LAYOUT Fig. 1 Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 8: Technical Data
The preheated hot water runs directly from straight outside at around 60 °C, the ﬂ ue gases Energycatcher and/or storage tank through are fed into the Energycatcher, where they ﬂ ow the boiler (combi type) to the tap, this over a heat exchanger. This otherwise wasted...
Page 9: Delivery
Energycatcher main unit. (2) Long rectangular box containing accessories: a) stand off wall bracket for boiler and Energycatcher consisting of 1 left and 1 right hand painted side bracket. b) 1 upper cross member and 1 lower T shaped cross member.
Page 10: Installation
Section 6 INSTALLATION WHEN INSTALLING ENERGYCATCHER Attach the template to the wall making sure that IT MUST BE FITTED IN CONJUNCTION the centre line is vertical using adhesive tape. WITH RAVENHEAT 120/150 CONDENSING BOILER THEREFORE ITS - mark the holes for the side ﬁ xing brackets to IMPORTANT TO FAMILIARISE the wall as well as the centre ﬂ...
Page 11 6.5.1 Locate the 4 boiler/Energycatcher ﬁ xing bolts and You may wish to run cold feed/preheat pipes into the nuts into the upper studs of the secured backframe, backframe. leave them slightly loose of the frame. It is best to use 15 mm plastic pipe as this should bend when located in plastic clips, otherwise put offset bends on feed pipes.
Page 12 6.5.2 Take out from the Energycatcher valve pack the blue Remove the straight exhaust white header and isolation valve and connect it to a 15 mm pipework gasket from the top of the boiler by removing the 4 (not supplied) making sure compression connection screws located on the top of the boiler itself.
Page 13: Energycatcher Fixing
“ silikon spray” (Arexons) or similar product. Fit desired ﬂ ue as set out in main boiler installation Taking Energycatcher, lift it up on the top of the manual. boiler while at the same time ensuring that the 2 Note : If the ﬂ...
Page 14: Water Connections
ﬁ bre washer provided to the 1/2” BSP outlet from the - Immediately above energycatcher ﬁ x a 15 mm T with braided pipe , this will act as a drain down discharge the junction pointing horizontally forward and point if this is required.
Page 15 10.4 ENERGYCATCHER STAND ALONE UNIT Fig. 11 Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 16 10.5 WITH REMOTE STORAGE TANK Fig. 12 Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 17 Fig. 13 Supplied By www.heating spares.co Tel. 0161 620 6677...
Page 18: Servicing
Section 11 SERVICING Energycatcher is a simple designed unit, no maintenance is required. The unit contains no mechanical, electrical or serviceable parts. It is recommended that the Energycatcher should be subjected to a general condition and ﬂ ue inspection with boiler maintenance by a competent person.
Page 19: Alternative Energycatcher
Energycatcher comes into its own whenever the boiler is used to heat the home or provide DHW. Energycatcher is a good investment to install in conjunction with solar panels, and offers immediate returns.
Page 20 Section 13 LIST OF SPARE PARTS Pos. Ravenheat part nr. G.C. part nr. Description 1002SCA12010/0 Heat exchanger 0019PRO12005/0 Flue extension 0010TUB12015/0 Flow pipe 0010TUB12005/0 Return pipe 0019ATT12005/0 Flue adapter 0014GUA11020/0 Flue gasket 0014RAC06005/0 Condensing trap 0013GUA01025/0 Gasket 24x15x2 0010TUB12010/1 Flex hose 0013GUA01020/0 Gasket 18.5x11.5x2...
