SMA series Touch Monitor

User Manual

Please read this manual very carefully before using your device

and store in a safe place for future reference.

Take down the model number for reference.

Model No.：

Serial No.：___________________

Table of Contents

Need help?

Do you have a question about the SMA serie and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartMedia SMA serie

Page 1 SMA series Touch Monitor User Manual Please read this manual very carefully before using your device and store in a safe place for future reference. Take down the model number for reference. Model No.： Serial No.：___________________...
Page 2: Table Of Contents
Table of Contents Important Notes Accessories Features Control Panel Interface Remote Control Instructions Installing the Wall Mount Installing and Using the Touch Screen Software Specifications - PC Specifications - Touch Screen Specifications - Monitor Toxic & Hazardous Materials...
Page 3: Important Notes
Important Notes For your safety please read this manual very carefully before use and keep it properly for any reference. We will take no responsibilities for any accidents resulting from violation of the safety and usage guidelines in this Manual. Explanation of Signs The signs used in this Manual and which are affixed on the product are listed below.
Page 4  Physical appearance may vary slightly depending on the model. Moving the monitor Two persons or more are required to handle the monitor. Hold the top and bottom frame firmly to move the monitor.
Page 5: Accessories
Accessories  These images are intended for reference only. Refer to actual product. Features  The super speed infrared touch screen allows for smooth writing, stable performance, prompt response and HID. It can support multi-touch (2-point and 4-point) with possibility to zoom in/out, drag and rotate the object selected.
Page 6: Control Panel
Control Panel  PC power indicator lights up in models with built-in PC...
Page 7: Interface
Interface...
Page 8: Remote Control
Remote Control...
Page 9: Instructions
Instructions Turning on the monitor When the power cable is connected, the TV indicator on the front control panel is red. Press the POWER button on the front control panel or the remote control, the TV indicator in red will flash for 5 seconds, then the TV and built-in PC (optional) will be turned on.
Page 10 Select Signal Source Via the buttons on the control panel ① Press SOURCE button on front control panel: the sources will be listed as shown on the right. ② Press P+ or P- to select signal source. ③ Press SOURCE button on front control panel to confirm the signal source selected.
Page 11 Connecting To External PC If necessary, you can connect your monitor to an external PC for interactive operation. ① Connecting to interface on front control panel This monitor has a port on the front control panel for easy operation. Connect the HDMI cable for video and audio signals;...
Page 12 Connecting Other External Equipment to the monitor You can connect other external equipment like a PC or a DVD to the monitor via VGA, HDMI, YPBPR, AV, USB, etc. (see fig.)  The figure is intended for reference only  You may have to prepare some connecting cables.
Page 13: Installing The Wall Mount
Installing the Wall Mount...
Page 14: Installing And Using The Touch Screen Software
Installing and Using the Touch Screen Software （Ⅰ）Setup Load the attached disk into the CD-ROM Double-click to run “TouchDevSetup.exe” in the disc. Complete installation accordingly. Click “Finish” and run touch screen management application “Fitouch.exe”. The installation will be completed when appears on the desktop’s lower right-hand corner.
Page 15 Exit: Closes TouchDev. Calibration: Standard calibration: As shown in the figure on the left, there are “custom” and “advanced” options for calibration. If neither one of the two options is selected, calibration will be standard. Standard calibration is suitable when connecting only one electronic white board.
Page 16 2） Matching between two parts of the screen: When the screen is split in two, with separate performance on both parts at the same time and both parts requiring touch functionality, carry out positioning on both sides, first on the left, then on the right.
Page 17 （Ⅲ）Basic Operation General The following operations may be performed on the screen: operation Click------object on the screen Double click------click the same object twice quickly on the same screen Drag------press the object and drag it Right key------press the object and remain for 2-3 second...
Page 18 PC Specifications Item Mini ATX PC OPS PC Main Board Intel QM67 chipset Mini ITX，Intel H61 chipset Intel1155 Pentium、I3、I5、I7. The model Intel I3、I5、I7. The model no. is subject to no. is subject to the real products the real products. Graphics Integrated Intel（R）HD Graphics Integrated Intel（R）HD Graphics DDRIII 1333 /2G/4G...
Page 19 Monitor Specifications Size 55 inch 65 inch 70 inch Speakers 8W+8W PAL /SECAM，BG/DK/I Resolution 1920*1080 1920*1080 1920*1080 View Angle 178° Image：JPEG、BMP、PNG Multi-Media Audio：WMA、MP3、M4A、AAC Formats Video：MPEG1、MPEG2、MPEG4、H264、RM、RMVB、MOV、MJPEG、VC1、DivX、 Working 0℃ to 40℃ Temperature Working 10% to 90%, No condensation Humidity Storing -20℃ to 60℃ Temperature Machine Size 1296.5x792.5x81mm...
Page 20: Toxic & Hazardous Materials
Toxic and Hazardous Materials or Elements Toxic and Hazardous Material Hexavalent Polybrominated Item Lead Mercury Chromium Polybrominated Chrome Diphenyl Ethers (PH) (HG) (CD) Biphenyl (PBB) (Cr(VI)) (PBDE) Shell LCD/LED panel Speakers Accessories ○: indicates that content of such material in the parts is below the limit of SJ/T11363-2006. ×: indicates that the content of such material in the parts is above the limit of SJ/T11363-2006.
