Adsys QR1-1600 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QR1-1600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adsys QR1-1600

  • Page 3 Regional EMC Compliance Information FCC Verification Notice (USA only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 Preface VCCI (Japan only) この装置は情報処理装置等電波障害自主規制協議会（VCCI）の基準に基づくクラス A 情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こすことがあり ます。この場合には使用者が適切な対策を講ずるよう要求されることがあります。 The English translation of the notice above is as follows: This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI) for information technology equipment. If this equipment is used in a domestic environment, radio disturbance may arise.
  • Page 5 Preface BSMI (Taiwan only) The following BSMI EMC Warning is marked on the product: a BSMI ID No and EMC Warning are required for Class A products. 这是甲类的信息产品，在居住的环境中使用时，可能会造成射频干扰, 在这种 情况下，使用者会被要求采取某些适当对策。 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved.

  • Page 6: Safety Information

    Preface Safety Information Read this important safety information section. Retain this manual for reference. Read this section before servicing the product. To reduce the risk of electric shock, this server should only be serviced by qualified service personnel. Caution RTC Battery Danger of explosion if battery is incorrectly replaced.
  • Page 7 Preface Always load the rack from the bottom up, and load the heaviest item in the rack first. Make sure that the rack is level and stable before extending a component from the rack. Caution Do not overload the AC supply branch circuit that provides power to the rack.
  • Page 8 Preface Always load the rack from the bottom up, and load the heaviest item in the rack first. Make sure that the rack is level and stable before extending a component from the rack Do not overload the AC supply branch circuit that provides power to the rack.

  • Page 9: Table Of Contents

    Preface Chapter 1 introduction..................1 Checklists ........................ 1 A Tour of the Motherboard ..................2 A Tour of the System....................4 Chapter 2 Motherboard Hardware Installation Guide ........7 Installing the CPU Heatsink.................. 10 Chapter 3 System Installation Guide..............11 Safety Measures ....................
  • Page 10 Preface Main Menu ......................41 Advanced Menu..................... 42 Boot Menu ......................55 Server Menu ......................58 Security Menu ....................... 62 Exit Menu ......................63 Chapter 4 Using the Java Interface ..............65 Setting the KVM TCP Port on Network..............65 Logging into the Web User Interface ..............
  • Page 11 Preface Appendix A Support .....................115 Before you Begin ....................115 Installing the Rack Brackets................116 Troubleshooting Sequence .................. 118 Appendix B Updating the BMC Firmware ............119 BMC Firmware Update Utility................119 Appendix C Specifications ..................121 Motherboard Specification.................. 121 System Specification:................... 123...
  • Page 12 Preface...

  • Page 13: Chapter 1 Introduction

    4 to 6 SATAII/4 SAS optional ports (depending on different SKU) provide maximum flexibility for installing hard drives. The QR1-1600 has a full range of I/O ports, including four USB ports, two Gigabit Ethernet LAN ports, one 10/100M LAN port from the AST2000, one PS2 mouse port, one PS2 keyboard port, one 9-pin serial port, and one 15-pin VGA port.

  • Page 14: A Tour Of The Motherboard

    Error! Style not defined. Introduction A Tour of the Motherboard QMA-1000S Figure 1 : I/O ports Input/Output Ports PORT FUNCTION PS/2 Mouse and Keyboard Connect a PS/2 pointing device and a keyboard to these ports. USB Ports Use the USB ports to connect USB devices. Serial and VGA Ports Use the serial port COM1 to connect serial devices such as mice or fax/modems.
  • Page 15 Error! Style not defined. Introduction Fan Connector Pin Assignment Item Description Pin Location 6.9.10 CPU FAN Pin1: GND (J4C1, J7J1, J7J2) Pin2: +12V Pin3: FAN_TACH Pin4: FAN_PWM SYS FAN Pin1: GND (J4J1) Pin2: +12V Pin3: FAN_TACH Pin4: FAN_PWM Front Panel Connector Pin Assignment Item Pin Location Pin Number...

  • Page 16: A Tour Of The System

    Error! Style not defined. Introduction A Tour of the System The following sections describe the external features of the QR1-1600 server. QR1-1600 Front View Figure 2 : QR1-1600 Front View HDD bay Open to install a hard drive. DVD-ROM LED Lights when the DVD-ROM is being accessed.
  • Page 17 Error! Style not defined. Introduction QR1-1600 Rear View* Figure 3 : QR1-1600 Rear View Power Module Connect the power cable to this socket. PS/2 mouse Connect a PS/2 pointing device to this port. Serial port Connect serial devices to this port.
  • Page 18 Error! Style not defined. Introduction...
  • Page 19 Chapter 2 QMA-1000S Item Label Components CPU PWR 12V power connector for CPU VRM. CPU socket. DIMM 1-4 DDR2-DIMM slots x 4. CPU Fans 1, 2 & 3 CPU Fan headers. MAIN_PWR Main power connector. SYS_FAN 2 System Fan connector. HDD LED SAS Backplane HDD LED Connector.

  • Page 20: Motherboard Hardware Installation Guide

    Error! Style not defined. Motherboard Hardware Installation Guide QMA-1000A Item Label Components CPU PWR 12V power connector for CPU VRM. CPU socket. DIMM 1-4 DDR2-DIMM slots x 4. CPU Fans 1, 2 & 3 CPU Fan headers. MAIN_PWR Main power connector. SYS_FAN 2 System Fan connector.
  • Page 21 Error! Style not defined. Motherboard Hardware Installation Guide QMA-1000V Item Label Components CPU PWR 12V power connector for CPU VRM. CPU socket. DIMM 1-4 DDR2-DIMM slots x 4. CPU Fans 1, 2 & 3 CPU Fan headers. MAIN_PWR Main power connector. SYS_FAN 2 System Fan connector.

  • Page 22: Installing The Cpu Heatsink

    Error! Style not defined. Motherboard Hardware Installation Guide Installing the CPU Heatsink Once the CPU has been installed see Installing the CPU page 18 the heaksink fan unit must be attached. Spread a layer of silicone heatsink paste over the top of the CPU. Remove the protective layer from the bottom of the heatsink.

  • Page 23: System Installation Guide

    Chapter 3 Safety Measures Computer components and electronic circuit boards can be damaged by discharges of static electricity. Working on computers that are still connected to a power supply can be extremely dangerous. Follow the simple guidelines below to avoid damage to your computer or injury to yourself.

  • Page 24: Qr1-1600S Mainboard Components

    Error! Style not defined. System Installation Guide QR1-1600S Mainboard Components The following illustration displays the most important QR1-1600 mainboard compo- nents. QR1-1600S-MB Figure 4 : Mainboard diagram Item Label Components CPU_PWR 12V power connector for CPU VRM. CPU socket. DIMM 1-4 DDR2-DIMM slots x 4.
  • Page 25 Error! Style not defined. System Installation Guide Item Label Components J2A1_BMC UPDATE BMC update connector PCI-E x 16 slot. PCI-E x 16 slot. CPU Fan 1 CPU fan header. Heat sink holes Holes for CPU Heatsink mounting pins (4 per CPU) NIC 1 &...

  • Page 26: Installing An Hdd

    Error! Style not defined. System Installation Guide Installing an HDD Follow these instructions to install an HDD: Push the locking latch in the direction of the arrow The HDD tray-locking lever springs open Pull the locking lever to remove the HDD tray.
  • Page 27 Error! Style not defined. System Installation Guide Secure the hard drive to the tray with four screws as shown. Do not over tighten the screws. Replace the HDD tray and push the assembly in the direction of the arrow to connect the hard drive with the port.
  • Page 28 Error! Style not defined. System Installation Guide Close the locking lever and ensure that the locking latch is secure. HDD Security Lock The HDD bays incorporate a security screw to prevent accidental HDD release. To engage the lock, turn the security screw clockwise toward the Lock symbol. To disengage the lock, turn the security screw counterclockwise toward the Unlock sym- bol as shown.

  • Page 29: Removing The Chassis Cover

    Error! Style not defined. System Installation Guide Removing the Chassis Cover Refer to the following illustrations for instructions on removing the chassis cover: Loosen the securing screw on the top of the server. Press down the lock- ing button as shown and slide the cover in the direction of the arrow using the traction pad.

  • Page 30: Installing The Cpu

    Error! Style not defined. System Installation Guide Installing the CPU When installing the CPU it must be installed in the CPU socket (Refer to QR1-1600S Mainboard Components on page 12 for location). Important Follow these instructions to install the CPU: Remove the CPU dust cover by lifting the tab marked Remove.
  • Page 31 CPU has notches that fit into the socket. The QR1-1600 uses an LGA 775 socket (Zero Insertion Force socket), which is designed for trouble-free insertion of the CPU. After placing the CPU into the socket, press the lever down and lock it in place. If you...
  • Page 32 Error! Style not defined. System Installation Guide Align the pin-1 corner and the notches and drop the processor into the socket. Replace the CPU bracket and locking lever to lock the processor in place.

  • Page 33: Installing The Heatsink

    Error! Style not defined. System Installation Guide Installing the Heatsink (Refer to QR1-1600S Mainboard Components on page 12 for location). Follow these instructions to install the heatsink: Apply thermal compound evenly on the top of the CPU. Remove the protective cover from the underside of the heatsink. Place the heatsink on top of the CPU with the four screws over their holes and tighten them to make the connection.
  • Page 34 Error! Style not defined. System Installation Guide Push the airduct over the edge of the heatsink.

  • Page 35: Replacing The Power Supply

    Error! Style not defined. System Installation Guide Replacing the Power Supply In case of a power supply failure, you can quickly replace the power supply unit. Follow these instructions to replace the power supply: Remove the chassis cover. See Removing the Chassis Cover on page 17. Remove the airduct from the chassis by lifting the edge over the heatsink in the direction of the arrow.
  • Page 36 Error! Style not defined. System Installation Guide Remove the two screws securing the power supply to the chassis. Lift the power supply out of the chassis in the direction of the arrow. Insert the replacement power supply and replace the two securing screws.
  • Page 37 Error! Style not defined. System Installation Guide Connect the three power cables to the chassis as shown. Ensure that all the cables are flush with the chassis and do not cause any obstructions. Replace the airduct see Installing the Heatsink on page 21. Replace the chassis cover see Replacing the Chassis Cover on page 35.

  • Page 38: Installing A Pci Card

    Error! Style not defined. System Installation Guide Installing a PCI Card Refer to the following illustrations for instructions on installing a PCI card: Voltages can be present within the server whenever an AC power source is connected. This voltage is present even when the main power is switched off.
  • Page 39 Error! Style not defined. System Installation Guide Lift the PCI riser assembly clear of the chassis in the direction shown. Remove the PCI blanking plate by removing the securing screw as shown.
  • Page 40 Error! Style not defined. System Installation Guide Orient the PCI card with the riser guide slot and push in the direction of the arrow until the PCI card sits in the PCI card connector . Secure the PCI card with the screw as shown Replace the riser assembly and secure the screw to lock the PCI riser...

  • Page 41: Replacing The Dvd-Rom Drive

    Error! Style not defined. System Installation Guide Replacing the DVD-ROM Drive Refer to the following illustrations for instructions on replacing the DVD-ROM unit: Remove chassis cover , see Removing the Chassis Cover on page 17. Remove the eight screws from the top front panel and slide in the direc- tion shown to remove.
  • Page 42 Error! Style not defined. System Installation Guide Remove the two screws securing the DVD-ROM module to the DVD-ROM PCB board. Disconnect the module from the board by pulling in the direc- tion of the arrow. Attach the DVD-ROM PCB board to the replacement DVD-ROM module and secure the two screws.
  • Page 43 Error! Style not defined. System Installation Guide Place the DVD-ROM assembly into the chassis and secure the module using the two screws as shown. Replace the top front panel, front edge first , and secure it to the chassis using the eight screws provided.

  • Page 44: Installing Memory

    Error! Style not defined. System Installation Guide Installing Memory The motherboard has four DDR2-DIMM slots for the installation of up to four DDR2- 667/800MHz DIMMs . Refer to QR1-1600S Mainboard Components on page 12 for the location of the memory modules. Follow these instructions to install memory modules: Pull the locking latches of the DIMM slot outwards.

  • Page 45: Supported Dimm Configurations

    Error! Style not defined. System Installation Guide Supported DIMM Configurations The following DIMM configurations are supported by the QR1-1600 server. DIMM slots are numbered DIMM_A1, DIMM_A2, DIMM_B1, DIMM_B2 and designated by two channels. DIMM_A1, DIMM_A2 belong to channel A while DIMM_B1, DIMM_B2 belong to channel B.
  • Page 46 Error! Style not defined. System Installation Guide Supported Modes The QR1-1600 supports the following modes: • Single Channel Mode • Dual Channel Interleaved Mode • Dual Channel Asymmetric Mode Single Channel Mode: Either channel may be used, and DIMM slots (within the same channel) may be popu- lated in any order.

  • Page 47: Replacing The Chassis Cover

    Error! Style not defined. System Installation Guide Replacing the Chassis Cover Refer to the following illustrations for instructions on replacing the chassis cover: Replace the cover, locating six securing lugs in slots on the chassis. Slide the chassis in the direction of the arrow until the locking button clicks into place.
  • Page 48 Error! Style not defined. System Installation Guide...

  • Page 49: Chapter 4 Bios

    Chapter 4 Setup Menu The computer employs the latest AMI CMOS BIOS, which is stored in flash memory. The flash memory supports the Plug and Play specification, and contains a BIOS setup program, the Power On Self Test (POST) routine, and the PCI auto-configuration util- ity.

  • Page 50: Console Redirection

    Error! Style not defined. BIOS Console Redirection Console redirection allows a remote user to diagnose and fix problems on a server which has not successfully booted the OS. The centerpiece of console redirection is the BIOS Console. The BIOS Console is a flash ROM-resident utility that redirects input and output over a serial or modem connection.

  • Page 51: Configuring Special Keys

    There are no function keys, arrow keys or control keys in this character set. However, the QR1-1600 BIOS software requires the use of function keys and control keys for ordinary functions. You can emulate a function key or control key by using a special key sequence called an escape sequence to represent a specific key.

  • Page 52: The Legend Bar

    Error! Style not defined. BIOS The Legend Bar The legend bar is at the side of the Setup screen. The keys in the legend bar allow you to navigate through the various setup menus. The following table lists the keys found in the legend bar with their corresponding alternates and functions.

  • Page 53: Main Menu

    Error! Style not defined. BIOS Main Menu The main menu displays information about your mainboard and BIOS. BIOS Setup Utility Main Advanced Boot Server Security Exit System Overview Use [ENTER], [TAB] Or [SHIFT-TAB] to AMIBIOS Select a field. Version : S48B2A05 Build Date :11/09/07 Use [+] or [-] to...

  • Page 54: Advanced Menu

    Error! Style not defined. BIOS Advanced Menu This option displays a table of items that define advanced information about your sys- tem. Making incorrect settings to items on these pages may cause the system to malfunction. Unless you have experience adjusting these items, we recommend that you leave these settings at the default values.

  • Page 55: Cpu Configuration

    Error! Style not defined. BIOS CPU Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Configure advanced CPU settings Disabled for Windows XP Intel(R) Core(TM)2 Quad CPU Q6600 @ 2.40GHz Frequency :2.40GHz FSB Speed :1066MHz Cache L1...

  • Page 56: Acpi Configuration

    Error! Style not defined. BIOS ACPI Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Advanced ACPI Configuration Enable RSOP pointers to 64-bit Fixed System ACPI Version Features [ACPI v2.0] Description Tables. Different ACPI version has some additions.

  • Page 57: Ide Configuration

    Error! Style not defined. BIOS IDE Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced IDE Configuration Options Disabled SATA#1 Configuration [Compatible] Compatible Configure SATA#1 as [IDE] Enhanced SATA#1 Configuration [Enhanced]] ► SATA Port0 [Not Detected] ►...
  • Page 58 Error! Style not defined. BIOS SATA ports configuration (Note: example is SATA Port0): BIOS SETUP UTILITY Advanced SATA Port0 Select the type Of device connected Device Hard Disk To the system. Vendor ST320410A Size 20.0GB LBA Mode Supported Block Mode 16 Sectors ←→...

  • Page 59: Sata Port

    Error! Style not defined. BIOS SATA Port0 Device: displays the type of device assigned to this channel. Vendor: displays the manufacturer’s name of the device. Size: displays the size of the device (GB). LBA Mode: indicates whether LBA access mode is supported or not supported. Block Mode: indicates whether multi sector transfer is supported.
  • Page 60 Error! Style not defined. BIOS S.M.A.R.T.: (Self Monitoring Analysis and Reporting Technology) reports drive degradation to the operating system to warn you of potential failure. • Auto: automatically sets optimal or default S.M.A.R.T. mode. • Disabled: disables S.M.A.R.T.. • Enabled: enables S.M.A.R.T.. 32Bit Data Transfer: enables 32-bit data transfer for improved performance.

  • Page 61: Super Io Configuration

    Error! Style not defined. BIOS Super IO Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Configure Win627DHG Super IO Chipset Allows BIOS to Select Serial Port1 Base Serial Port1 Address [3F8/IRQ4] Adderesses.

  • Page 62: Trusted Computing

    Error! Style not defined. BIOS Trusted Computing Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced Trusted Computing Enable/Disable TPM TCG (TPM 1.1/1.2) support in BIOS TCG/TPM SUPPORT [No] Select Screen ←→ Select Item ↑↓...

  • Page 63: Usb Configuration

    Error! Style not defined. BIOS USB Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced USB Configuration Enables support for legacy USB. AUTO Module Version – 2.24.3-13.4 Option disables legacy support if USB Devices Enabled: no USB devices are 1 Keyboard, 1 Mouse...
  • Page 64 Error! Style not defined. BIOS BIOS SETUP UTILITY Advanced USB Mass Storage Device Configuration Number of seconds POST waits for the USB Mass Storage Reset Delay [20 sec] USB mass storage Device#1 MITSUMI USB FDD device after start Emulation Type [Auto] unit command.

  • Page 65: Pci Configuration

    Error! Style not defined. BIOS PCI Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced PCI Configuration Enable or Disable Intel 82566DM. NIC1 Controller [Enabled] NIC1 OptionROM [Enabled] ←→ Select Screen NIC Controller [Enabled] ↑↓...

  • Page 66: Mps Configuration

    Error! Style not defined. BIOS MPS Configuration Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Advanced MPS Configuration Select MPS Revision. MPS Revision [1.4] ←→ Select Screen ↑↓ Select Item Change Option General Help Save and Exit Exit v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.

  • Page 67: Boot Menu

    Error! Style not defined. BIOS Boot Menu This page enables you to set POST boot parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Boot Settings Configure Settings during System Boots.

  • Page 68: Boot Settings Configuration

    Error! Style not defined. BIOS Boot Settings Configuration Select this item and press Enter to view the following submenu items: BIOS SETUP UTILITY Boot Boot Settings Configuration Certain tests while booting. This will decrease the time needed Quick Boot [Enabled] to boot the System.

  • Page 69: Boot Device Priority

    Error! Style not defined. BIOS Boot Device Priority Select this item and press Enter to view the following submenu items: BIOS SETUP UTILITY Boot Boot Device Priority Specifies the boot sequence from the 1st Boot Device [HDD:3M-ST320410A] available devices. 2nd Boot Device [CD/DVD:3S-CRD-8483] 3rd Boot Device [Network:IBA GB Slo]...

  • Page 70: Server Menu

    Error! Style not defined. BIOS Server Menu This page enables you to configure server parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Server Configuration Configure Remote Access. Status of BMC Working IPMI Specification Version...
  • Page 71 Error! Style not defined. BIOS Set AST2000 LAN Configuration These pages enable you to configure the AST2000 LAN parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Server LAN Configuration Enter for IP Address Configuration.
  • Page 72 Error! Style not defined. BIOS Set MAC Address BIOS SETUP UTILITY Server MAC Address Configuration. Parameter Selector [05] Current MAC address in BMC: xx.xx.xx.xx.xx.xx Select Screen ←→ Select Item ↑↓ General Help Save and Exit Exit v02.61 (C)Copyright 1985-2006, American Megatrends, Inc. Set Subnet Mask Configuration BIOS SETUP UTILITY Server...

  • Page 73: Remote Access Configuration

    Error! Style not defined. BIOS Remote Access Configuration Select Remote Access Configuration to view the following submenu: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Configure Remote Access Type and parameters Select Remote Access type. Remote Access [Enabled] Serial port number [COM1] Base Address, IRQ [3F8h,4]...

  • Page 74: Security Menu

    Error! Style not defined. BIOS Security Menu This page enables you to set the security parameters. Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Security Settings Install or Change the password.

  • Page 75: Exit Menu

    Error! Style not defined. BIOS Exit Menu Scroll to this item and press Enter to view the following screen: BIOS SETUP UTILITY Main Advanced Boot Server Security Exit Exit Options Exit system setup After saving the Save Changes and Exit changes.
  • Page 76 Error! Style not defined. BIOS The default values for optimal settings are quite demanding and your system might not function properly if you are using slower memory chips or other kinds of low- performance components. Load Failsafe Defaults: if you highlight this item and press Enter, a dialog box asks if you want to install fail-safe settings for all the items in the Setup utility.

  • Page 77: Using The Java Interface

    Chapter 4 The AST2000 firmware features an embedded web server, allowing you to connect to the AST2000 using an Internet browser (Microsoft Internet Explorer) without install- ing KVM and Virtual Storage software on the remote console side PC. The following web browsers are supported: •...

  • Page 78: Chapter 4 Using The Java Interface

    Error! Style not defined. Using the Java Interface The following figure displays the user authentication web page. The default username is root. The default password is changeme. After passing authentication, the following web page appears.

  • Page 79: System Information

    Error! Style not defined. Using the Java Interface System Information The System Information tab enables you to view version information, enable session timeouts and intervals and view Components options. Click the System Information tab to view the following web page. Version Click the Server Board Information tab to view Server Board information including: BIOS, manufacturer, date, product name, P/N and S/N.

  • Page 80: Session Time-Out

    Error! Style not defined. Using the Java Interface Click the BMC version tab to view BMC information including: the device ID, de- vice revision, firmware revision, and IPMI revision numbers. Session Time-Out Click the Session Time-Out tab. Click Enable Timeout and select a timeout value from the drop-down list.
  • Page 81 Error! Style not defined. Using the Java Interface Components Click the Components tab to view CPU and memory information. Click the CPU tab to view the CPU model, status, socket, manufacturer, frequency, and number. Memory Click the Memory tab to view memory model, size, DIMM slot status, frequency, status and slot location.

  • Page 82: System Monitoring

    Error! Style not defined. Using the Java Interface System Monitoring The System Monitoring tab enables the administrator to view data about the system, including LED, system, fan, temperature and voltage status and event logs. You can also enable LED blinking for the server on the Locator Indicator page to identify a particular server.
  • Page 83 Error! Style not defined. Using the Java Interface Summary Click the Summary tab to display a brief overview of system hardware status. • Fault LED Status: indicates whether the fault LED on the server is on or off. • System Status: indicates whether the server system is powered on or off. •...
  • Page 84 Error! Style not defined. Using the Java Interface Click the Fan tab to view the status of system fans with such information as: thresh- olds, sensor readings and status. Temperature Click the Temperature tab to view system component temperature information such as minimum and maximum thresholds, sensor readings and temperature sensor read- ings.
  • Page 85 Error! Style not defined. Using the Java Interface Voltage Click the Voltage tab to view system voltage information such as maximum and minimum thresholds, sensor readings and the status of the voltage sensor. Click the hyperlinks at the top of the screen to view associated information.

  • Page 86: Event Logs

    Error! Style not defined. Using the Java Interface Event Logs Click the Event Logs tab to view reports about system events. View Event Logs Click View Event Logs to view specific event information. • Severity: indicates the nature of the event (unspecified, information, critical, etc).
  • Page 87 Error! Style not defined. Using the Java Interface Save Event Logs Click the Save Event Logs tab to view the following screen. Click Save Event Logs to save the log to disk. You are prompted to save the event log text file to disk. Click Save to save the log file to your hard drive.
  • Page 88 Error! Style not defined. Using the Java Interface Locator Indicator 1. Click the Locator Indicator tab to view the following screen. Click on the desired setting. • Turn on system indicator LED blink: set the ID LED on the remote server to blink.

  • Page 89: Configuration

    Error! Style not defined. Using the Java Interface Configuration The Configuration tab enables you to set Front Panel Lockout options: network pa- rameters, e-mail notification, platform event filter, SSL certification and time. Click the Configuration tab to view the following web page. Network Click the Network tab to set network parameters.
  • Page 90 Error! Style not defined. Using the Java Interface E-mail Notification The E-mail Notification tab enables you to configure an e-mail SMTP server to send and receive details for system event notification. Click the E-mail Notification tab to display the following web page. Enter server, sender and receiver details and click Submit.
  • Page 91 Error! Style not defined. Using the Java Interface Platform Event Filter (PEF) The Platform Event Filter tab allows you to modify the Trap Receiver Destination Address, PEF control and event filter. Click the Platform Event Filter tab to display the following web page. Only administrators can enable and disable the PEF.
  • Page 92 Error! Style not defined. Using the Java Interface Clock Settings The Clock Settings page enables the administrator to show the time for the server. Click the Clock Settings tab to view the following web page. Remote server time is showing as year, month, day and time (hours:minutes:seconds).
  • Page 93 Error! Style not defined. Using the Java Interface formation specific to your company and domain name. You can generate a CSR or up- load a manually created CSR. The following information is required: • Common Name (CN): the domain name for which you are requesting the SSL certificate.
  • Page 94 Error! Style not defined. Using the Java Interface Uploading a Manually Created CSR Click the Browse button next to Certificate Upload, and browse to the loca- tion of the saved key (using the .pem file extension). Click Upload to upload the key. Once the upload is completed, close the browser.

  • Page 95: User Management

    Error! Style not defined. Using the Java Interface User Management The User Management web page enables the administrator to change the administra- tive account password and to add, modify, and delete users and set user privileges. Click the User Management tab to view the following web page. Changing the Administrative Password Follow these instructions to change the administrative password.

  • Page 96: Adding A User

    Error! Style not defined. Using the Java Interface Adding a User Click Add User. Type the Username in the text box. Type the Password in the text box and type it again for confirmation. Select the privilege to assign to a user. •...
  • Page 97 Error! Style not defined. Using the Java Interface ADS Configuration The Active Directory Server (ADS) configuration allows administrators to configure the AST2000 by using certificates from a Domain Name Server, active directory server, CA server. From the AD and CA servers, find the certificate in C:/*.crt and left click on it to reveal the details.

  • Page 98: Remote Control

    Error! Style not defined. Using the Java Interface Remote Control By using the included Java client, users have access to robust remote control features. Refer to the next chapter for more information on remote control · features. Notice Ensure that you have Java Virtual Machine (JVM) version 1.5 or ·...
  • Page 99 Error! Style not defined. Using the Java Interface Redirection Launch Redirection enables you to control the server through your local PC. Follow these instructions to use Launch Redirection. Click the Redirect tab. Click the Launch Redirection button. The following warning screen appears. Click Close and then right-click the Information Bar to open the following screen.
  • Page 100 Error! Style not defined. Using the Java Interface Click Download File. The following screen appears. Click Run. You may see several security screens during installation of the remote application. On each screen, click Yes to continue. Notice The Java Remote KVM application appears. Click OK.
  • Page 101 Error! Style not defined. Using the Java Interface Using the Java Remote KVM The Java Remote KVM interface has several buttons that provide different functional- ity. • Video Quality: enables you to select video quality: low, medium, or high. • High: least video loss and biggest size image transmitted.
  • Page 102 Error! Style not defined. Using the Java Interface Remote Power Control This feature enables the administrator to power on or power down the system remotely. The IPMI connector must be connected to enable this function. Notice Click the Remote Power Control tab to view the following web page. •...
  • Page 103 Error! Style not defined. Using the Java Interface Hotkey Setup This page enables the administrator to create user profiles that include control modes, KVM settings, hot key settings and storage settings. These settings are loaded after the Java Remote KVM is launched. Click the Hotkey Setup tab to view the following web page.

  • Page 104: Maintenance

    Error! Style not defined. Using the Java Interface Maintenance The Maintenance web page enables you to upgrade the firmware and reset the BMC. Firmware Upgrade Use the Firmware Update feature to upgrade to the latest firmware version. Click the Firmware Update tab to view the following web page. Browse to the location of the firmware file and click Update to update the firmware to the latest version.

  • Page 105: Chapter 5 Using The Client

    Error! Style not defined. Using the Java Interface Reset BMC Use the Reset BMC web page to reset the BMC to the factory default configuration. Click the Reset BMC tab to view the following web page. Click Reset BMC to restore the default values. This concludes this chapter.
  • Page 106 Error! Style not defined. Using the Java Interface...

  • Page 107: Using The Client

    Chapter 5 KVM stands for Keyboard, Video and Mouse. KVM over IP redirects server video screen, keyboard and mouse data to or from a remote console PC via a network so that the administrator can monitor the server and use a keyboard and a mouse to operate the server remotely.
  • Page 108 Error! Style not defined. Using the Client The following image displays the video quality options.

  • Page 109: Usb Keyboard And Mouse Emulation

    Error! Style not defined. Using the Client USB Keyboard and Mouse Emulation Once the AST2000 KVM over IP function is launched, the AST2000 emulates USB 1.1 keyboard and mouse devices. As a result, the managed server’s BIOS or OS will detect the USB keyboard and mouse attached and load its drivers to service them.

  • Page 110: Mouse Synchronization On Console Side

    Error! Style not defined. Using the Client Mouse Synchronization on Console Side When the Java remote KVM application is launched on the console PC, the mouse po- sition of the remote server and the console are automatically synchronized. However, once the managed server’s mouse is moved locally, the console PC mouse position will be different from the redirected managed server mouse.

  • Page 111: Hardware Cursor Mode

    Error! Style not defined. Using the Client Hide Console Side Mouse You can hide or show the console side (local) mouse by clicking the Local Cursor button on the toolbar or by clicking Control on the main menu and selecting Local Cursor.

  • Page 112: Hotkey Simulation

    Error! Style not defined. Using the Client Hotkey Simulation Since Windows or other application programs have priority in using hotkeys before the remote server, (for example Ctrl-Alt-Del), the Java remote KVM ignores these keys and does not send them. However, you can assign hotkeys in the Java remote KVM application (see Hotkey Setup on page 91) and these hotkeys are available as buttons on the menu bar so that the user can select hotkeys to send to the AST2000 and the managed server directly.
  • Page 113 Error! Style not defined. Using the Client The following screen displays the Hotkey menu.

  • Page 114: Full Screen Display On Console Pc

    Error! Style not defined. Using the Client Full Screen Display on Console PC The Java Remote KVM enables you to display the redirected video image in full screen mode as seen on the local side server in place of the window on the remote server side.

  • Page 115: Dynamic Scaling Video Resolution

    Error! Style not defined. Using the Client Dynamic Scaling Video Resolution From managed server power on to entering the Operating System, the video output resolution changes frequently. The AST2000 detects these changes and adjusts the display window automatically. In addition, the user can adjust the display window to the size required by clicking and dragging the bottom right-hand corner of the inner window.

  • Page 116: Color Text Adjust

    Error! Style not defined. Using the Client Color Text Adjust The AST2000 has blurred color text in some conditions; you need to adjust the pa- rameters to make the text clear.

  • Page 117: Encryption Mode

    Error! Style not defined. Using the Client Encryption Mode Encryption includes the following modes. • No encryption • Keyboard and mouse encryption: Uses AES method for encryption. • Video Only encryption: Uses RC4 method for encryption. • Encryption All: Encrypts the Keyboard/Mouse and Video. The client side can only view encryption mode;...

  • Page 118: Virtual Storage

    Error! Style not defined. Using the Client Virtual Storage Through the USB storage emulation functions of the AST2000, users can install an operating system, device drivers or application software conveniently from the remote side. Mounting a Device This section describes how to set up virtual storage for the QSSC K9168. Follow these instructions to configure a storage device.
  • Page 119 Error! Style not defined. Using the Client The following screen appears. Select the storage device or ISO image from the drop-down list. When a storage device is mounted, Mounted the status bar displays an icon: device If you select ISO-Image, you will be prompted to browse to the lo- cation of the ISO file.
  • Page 120 Error! Style not defined. Using the Client Supported Devices Device Action Legacy Floppy Read and Write USB Floppy (Floppy supports Media Change) USB Flash Device Action USB CD/DVD ROM Read only (Supports Media Change) IDE CD/DVD ROM ISO Image USB DVD Emulation When the DVD Emulation function is enabled, the managed server will find a USB DVD drive.
  • Page 121 Error! Style not defined. Using the Client USB Floppy Emulation When the Floppy Emulation function is enabled, the managed server will find a USB floppy drive. As shown in the image below the user puts a target diskette into the re- mote console PC floppy drive.
  • Page 122 Error! Style not defined. Using the Client USB CD-ROM Emulation When the CD-ROM Emulation function is enabled, the managed server will find a USB CD-ROM drive. The user puts the target CD into the remote console PC CD- ROM drive. The managed server accesses this virtual attached USB CD-ROM, the AST2000 redirects to the CD in the console PC and Java Remote KVM accesses the target CD.
  • Page 123 Error! Style not defined. Using the Client Remote Boot Users can remotely boot an OS using the Virtual Storage and BIOS setting. This func- tion only supports ISO 9660 images of an OS and IDE/USB CD/DVD ROM. Mount ISO 9660 image of the OS or IDE/USB CD/DVDROM to a remote host.
  • Page 124 Error! Style not defined. Using the Client Multidevice Configuration Use the procedure below to configure OS-specific managed devices on the server. Redhat AS4.0 You are required to rebuild an initial ramdisk. In /etc/modprobe.conf add the line below: options scsi_mod max_luns=xxx (add the number of LUNs to support in place of xxx) Build the initial ramdisk to implement the change: mkinitrd -f /boot/newimage-2.6.xx 2.6.xx...
  • Page 125 Error! Style not defined. Using the Client Virtual Storage Configuration (Linux Kernel 2.4) Use the procedure below to configure your OS (Linux kernel 2.4) on your local com- puter. After configuring the system, mount a local IDE CD/DVD ROM to the remote server.
  • Page 126 Error! Style not defined. Using the Client Using GRUB If using GRUB to boot, add the line at the end of kernel line of /etc/grub.conf xxx=scsi (add the “id” of the IDE CD/DVDROM in place of xxx) For example: ---grub.conf--- default=0 timeout=10 splashimage=(hd0,0)/grub/splash.xpm.gz...

  • Page 127: Appendix A Support

    Appendix A Before you Begin Before removing the server cover, disconnect all power. Unplug the AC power cord and disconnect all peripherals and all LAN lines. Caution Make sure you have a stable, clean working environment. Dust and dirt can get into computer components and cause a malfunction.

  • Page 128: Installing The Rack Brackets

    Error! Style not defined. Support Installing the Rack Brackets When the server is to be installed into a rack, it is necessary to install two rack mount brackets onto the server chassis prior to installing the server into the rack. Follow the procedures below to install your rack mount brackets onto your server.
  • Page 129 Error! Style not defined. Support Align the slide rail with the inner rail and push toward the front of the server until the locking latch clicks into place. Slide Rail To remove the slide rail, press the locking lever inward before sliding the inner rail clear Notice...

  • Page 130: Troubleshooting Sequence

    Error! Style not defined. Support Troubleshooting Sequence Installation Problems Perform the following checks if you are troubleshooting an installation problem: Check all cable and power connections (including all rack cable connections). Unplug the power cord, and wait one minute. Then reconnect the power cord and try again.

  • Page 131: Updating The Bmc Firmware

    Appendix B BMC Firmware Update Utility The BMC (Baseboard Management Controller) firmware update utility is a DOS- based program used to update BMC firmware code. This utility should only be run if new firmware code is necessary. BMC Firmware Update Procedure Before proceeding, read the BMC firmware release notes to determine which update utility version is appropriate for the new firmware version.
  • Page 132 Error! Style not defined. Updating the BMC Firmware...

  • Page 133: Appendix C Specifications

    Appendix C Motherboard Specification FEATURE COMMENT Single Socket-T Support Intel Xeon 3000/3200/3100/3300 processors LGA775 pins Socket Chipset North bridge: 1. 800/1066/1333 MT/s Front Side Bus (FSB) Intel Bigby-A MCH: 2. DDR2 – 667/800 MHz (2 DIMMs/Ch) 8 GB Max (512Mb, QMA-1000S/A SKU 1Gb) Intel Bigby-V MCH:...
  • Page 134 Error! Style not defined. Specifications FEATURE COMMENT Flash BIOS FWH 8M bit ACPI ACPI compliance, S0, NO S3 (STR) S1, S5 support Front panel USB 2.0 x 2, Power Button x 1, Power LED x 1, HDD Status LED x 1, LAN LED x 2, System Status LED x1 Monitor On board AST2000 : Main Logic Board Sensors:...

  • Page 135: System Specification

    Error! Style not defined. Specifications System Specification FEATURE COMMENT Single Socket-T Support Intel Xeon 3000/3200/3100/3300 processors LGA775 pins Socket Chipset North bridge: 1. 800/1066/1333 MT/s Front Side Bus (FSB) Intel Bigby-P MCH: 2. DDR2 – 667/800 MHz (2 DIMMs/Ch) 8 GB Max (512Mb, QR1-1000S SKU 1Gb) Intel Bigby-V MCH:...
  • Page 136 Error! Style not defined. Specifications FEATURE COMMENT Rear IO RS232 Serial x 1, USB 2.0 x 2, VGA x 1, KB/MS x 1, RJ45 x 2 Monitor On board AST2000 : Main Logic Board Sensors: VGA, BMC, (BMC) 1. Voltage Power Good Detection KVM Over IP 2.
