User's installation and operation Manual
Important Safeguards and Warding
Do not place heavy objects on the DVR.
Do not let any solid or liquid fall into or infiltrate the DVR
Please brush printed circuit boards,connectors,fans,machine box and so on regularly.Before the dust
cleaning please switch off the power and unplug it.
Do not disassemble or repair the DVR by yourself.Do not replace the components by yourself.
Environment
Please place and use the DVR between 0 and 40 .Avoid direct sunlight.Stay away from heat source.
Do not install the DVR in the damp environment.
Do not use the DVR in smoky or dusty environment.
Avoid collision or strong fall.
Please insure the DVR level installation in a stable workplace.
Please install in ventilated place.Keep the vent clean.
Use within the rating input and output scope.
1 Production Introduction ........................................................................................................................................ 4
1.1 Product overview ....................................................................................................................................... 4
1.2 Main functions ............................................................................................................................................ 4
2 Open-package check and cable connections ................................................................................................... 5
2.1 Open-package check ................................................................................................................................ 5
2.2 Hard disk installation ................................................................................................................................. 6
2.3 Shelf installation.......................................................................................................................................... 7
2.4 Front panel................................................................................................................................................. 7
2.5 Rear panel ................................................................................................................................................ 11
Manual de Instalación y uso HDVR Starligh
Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas
mail:
ventas@starligh.com www.starligh.com
Directory
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCVR5204 and is the answer not in the manual?

Questions and answers

Summary of Contents for Starligh HCVR5204

  • Page 1: Table Of Contents

    2.2 Hard disk installation ..........................6 2.3 Shelf installation............................7 2.4 Front panel..............................7 2.5 Rear panel ..............................11 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 2 4.3.6 Abnormal ............................56 4.3.7 Intelligent analysis ........................57 4.4 System setup ............................61 4.4.1 General ............................62 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 3 Appendix 1.Remote controller operation ......................113 Appendix 2.Mouse operation ..........................114 Appendix 3.Hard disk capability calculation ..................... 115 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 4: Production Introduction

    ·special storage format which insures the data safety Compression ·real-time compression by individual hard disk which insures the audio and video signal stable synchronization Backup Manual de Instalación HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 5: Open-Package Check And Cable Connections

    First, please check whether there is any visible damage to the package appearance.he protective materials used for the package of the DVR can protect most accidental clashes during transportation. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 6: Hard Disk Installation

    Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 7: Shelf Installation

    (2) Record indicator light (3)Alarm indicator light (4) ESC (5) Menu (6)Direction &Enter The front panel of A series Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 8 (18) Backwards Pause (19) (20) Play Previous Frame (21) ESC (22) Power switch (23) USB The front panel of E series Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 9 (5) Playback stop/9 Record Power switch (8) USB (9) Main Menu/0 Screen switch/1 Record search/2 (C) PTZ control/3 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 10 (H)Screen Switch (J) PTZ (K) Main Menu (L) shift (M) Power Switch The front panel of D series Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 11: Rear Panel

    2.5 Rear panel The rear panel of T series Video Input Video Audio Output Output Audio Input Network Power Input Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 12 Network RS485 Power 5008A-B *this model of device's interface is the same as 5004A-B's,just four more video input Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 13 5004C-S Video Input Video 12V Output Output Audio Input *other interface of this model are similar as 5004C-B Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 14 5008C-S 5008C-C 5016C-S 5016C-C The rear panel of E series Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 15 Power Supply Switch Video Output Audio Output 12V Input *other model 's interface are same as 5004E-S 5008E-S Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 16 Audio Input Network External Interface Power Supply Switch Video Output Audio Output The rear panel of K series Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 17 The rear panel of D series Video Input Audio Input HDMI Network External Power Supply Interface Power Switch Video Audio Output Output Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 18: Audio And Video Input And Output Connections

    The video signal must be accorded with the state standard which has the high signal to noise ratio, low aberration and low interference. The image must be clear and has natural color in the appropriate brightness. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 19: Video Output Connections And Options

    TV can lead to the damage of other equipments. 2.6.3 SDI video input Only part models of 6000 series support SDI encode for 1080P Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 20: Audio Signal Input

    2.Alarm output Alarm output can not be connected with high-power load(no more than 1A).When forming the Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
  • Page 21 (1) alarm input 1,2,3,4 (2) ground (3) RS232 (4) RS485 (5) alarm input 5,6,7,8 (6) ground (7) alarm output Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 22: Alarm Input Port Specification

    The NC port of the alarm sensor must be connected with the DVR alarm input port. The grounding of the power supply and the alarm sensor must be shared when used in external power supply. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 23: Alarm Output Port Specification

    2.8 Speed dome connections 1.Connect the 485 lines of the speed dome with the DVR 485 interface. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 24: Basic Operation

    There are two methods to turn off the DVR. Entering [main menu] and choosing [turn off] in the [turn off the system] option is called soft switch. Pressing the power supply switch is called hard switch. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 25: System Login

    Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 26: Preview

    Alarm Output, color Setting, Output adjust, Logout, view mode shift ,spot. *Only partial model of 6000 series support Spot Shortcut menu in full analog(DVR)/Hybrid(HVR) mode Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 27: Main Menu

    3.5.1 Main menu When you login, the system main menu is shown as below. Picture3.3 Main Menu Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 28: Playback

    【Playback control】See detail in below chart Function Function Play/Pause Backward play Slow forward Fast forward Previous frame Next frame Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 29: Record Control

    You can use desktop shortcut menu or click [main menu]> [recording function]> [recording set] to enter the recording control interface. Picture 3.8 Record Mode 【Schedule】Record according to the configuration. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 30: Alarm Output

    *PTZ control is a little different between hybrid mode & full digital mode: Digital channel – the digital channel need link PTZ, the remote device should connect with PTZ Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 31 Left press mouse and then rotate the mouse to adjust the zoom multiple of the camera. 【Set】Enter the function operation menu. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 32 In Picture 3.10, click Page Shift button, enter PTZ control interface as shown in Picture 3.12. In the input blank, write the preset points, then click Preset button, PTZ turn to the corresponding preset point. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
  • Page 33 Remove Cruise Line：Input the number of cruise line, click Remove Cruise Lines button, then remove the cruise lines set。 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
  • Page 34 Zoom,Focus,Aperture,Direction and so on. Click Setup button to go back Picture 3.14 Step4: Click End button to complete setup。Click the right button of the mouse to exit. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 35 Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
  • Page 36 In Picture 3.12, click Page Shift button into Picture3.16, setting auxiliary function. Auxiliary number auxiliary switch on the decoder. corresponding to Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 37: Color Setting

    You can use the desktop shortcut menu and enter the interface. The image parameters include: tonality, brightness, contrast, saturation. You can set different parameters at different time sections. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 38: Output Adjust

    Picture 3.19 Output Adjust Note: The black margin vertical & horizontal at output adjust of hybrid mode is only effect to analog channel. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...

  • Page 39: Logout

    T series logout 3.5.9 Window switch Preview in single window/four windows/eight windows/nine windows/sixteen windows according to your choice. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 40: Spot

    Preview in single window/four windows/sixteen windows according to your choice. Note：Different video input number have different preview screen. Manual de Instalación y uso HDVR Starligh Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 41: Main Menu

    Exception No HDD, HDD error, HDD capacity not enough, network cut, IP handling Conflict, linkage parameters, screen hint or buzz. Manual de Instalación HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...
  • Page 42 algorithm rule: trajectory display、sensitivity、minimum pixel、alert mode，and setting linkage parameters:period、alarm Intelligent output、the screen analysis prompt、record、PTZ、tour、buzzer、EMAIL、FTP upload. Note: 6000 series support this function General Set system time, data format, language, hard disk full time operation, configuration machine number, video format, output mode, summertime, stay time Set main (extra) coding parameter: code mode, resolving ability, frame rate, code stream control, image quality type, code stream value, Encode...

  • Page 43: Record

    Hard disk Set appointed hard disk as read-write disc, read-only disc or management redundant disc, clear data, resume date and so on User Modify user, team or password. Add user or team. Delete user or management team. Break the connection with the already login user. Lock the account Online user after break until booting up again.
  • Page 44 Set the recording parameters in the surveillance channel. The system is set 24 hours consecutive recording in the first startup. You can enter [main menu]> [recording function]> [recording setup] to set. Note:There is at least one read-write hard disk.（refer to chapter 4.5.1） Picture 4.1 Record Configuration 【Channel】Choose the corresponding channel number to set the channel.

  • Page 45: Playback

    Regular:Perform the regular recording in the set time section. The video file type is “R”. Detect:Trigger the “motion detect”, “camera mask” or “video loss” signal. When above alarm is set as opening recording, the “detection recording” state is on. The video file type is “M”.
  • Page 46 【Detect】Detect the storage connected with the DVR such as hard disk or universal disk. 【Backup】Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time. Picture 4.3 Backup Remove：Clear the file information.
  • Page 47 Setup snapshot parameters for different channels.At first time it's set for 24hours snapshot continuously,please go to Main Menu--Record--Snapshot Storage for appropriate setting. Note:If normal snapshot storage,please setup snap at Main Mend--advanced--snapshot(please refer to chapter 4.5.1 HDD Manager) Picture 4.2 snapshot storage 【Channel】Select the related channel to set,click"all"to set all channels.

  • Page 48: Alarm Function

    Alarm：snapshot at set period when alarm in which is preset for snapshot enable. Note:for related alarm function,please refer to chapter 4.3. 4.3 Alarm Function Alarm functions include: motion detect,video blind, video loss, alarm input and alarm output, abnormality、intelligent analysis. 4.3.1 Motion Detect When system detects the motion signal that reaches the set sensitivity, the motion detect alarm is on and the linkage function is turned on.
  • Page 49 Video detect in full digital(NVR) mode Pic 4.4 【Channel】Choose the set motion detect channel. 【Enable】■ means that the motion detect function is on. 【Sensitivity】Choose in the six options according to the sensitivity. Note: Only the motion detect under hybrid mode/ full analog mode have this function of setting sensitivity, and also only the analog channel can set region.
  • Page 50 Picture 4.5 Region 【Period】Trigger the motion detect signal in the set time section. You can set according to week or set uniformly. Each day is divided into four time sections.■ means the set valid. Picture 4.6 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval.

  • Page 51: Video Blind

    Note:Set in the [recording setup] and perform the linkage recording. Start detecting video files in the corresponding time section. 【Tour】■ means that the selective channel is single window alternate patrol preview. The interval is set in the [Main Menu]>[System] > [Tour]. 【PTZ Activation】Set the PTZ activation when the alarm is turned on.
  • Page 52 *Same as motion detect function, video blind is different between Hybrid mode & Full digital mode: Digital channel: not only to enable video blind function at local side, but also to enable the remote device that was connected. when remote device with video blind, local side will start alarm recording, otherwise this function is not enable.

  • Page 53: Video Loss

    Video blind in full digital(NVR) mode Pic 4.8 Video blind Set method: refer to chapter 4.3.1. Motion detect 4.3.3 Video Loss When the equipment can not obtain the channel video signal, the video loss alarm is turned on and the linkage function is turned on. *Same as motion detect function, video loss is different between Hybrid mode &...
  • Page 54 Video loss in Hybrid(HVR) mode Video loss in full digital(NVR) mode Pic 4.9 Video loss Set method: refer to chapter 4.3.1. Motion detect...

  • Page 55: Alarm Input

    4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. *Alarm input is the same between hybrid mode & full digital mode, function enable, when it was set normal, only need to connect alarm sensor at alarm input port on local side, the alarm information is occurring, and will link to related setting functions at the same time Note: "Advanced"...

  • Page 56: Alarm Output

    Alarm input in NVR mode Pic 4.10 Alarm input Set method: refer to chapter 4.3.1. Motion detect 4.3.5 Alarm output Refer to chapter 3.5.4. 4.3.6 Abnormal Analysing and inspecting current software and hardware of the device: When some abnormal events happen,the device will make a relative answer such as show message and buzzer.

  • Page 57: Intelligent Analysis

    Picture 4.11 Abnormal 【Event Type】 selecting abnormity you want to inspect 【Enable】 Select it to make sure abnormal function workable 【Show message】 Automatically alarm cue dialog box come out of the main screen 【Buzzer】 Device will have one long nosie “di” while alarm is happening 4.3.7 Intelligent analysis *Note: only part of product support this function at present。...
  • Page 58 Pic 4.12 Intelligent analysis setting page 【Channel No.】only shows by “1”，at present, only the 1 channel with maximum resolution of 1080P in the full analog(DVR) mode and hybrid(HVR) mode 【Enable】tick it to enable the video analysis function, then can go for further setting, 【Algorithm rule】at drop-down box to choose the algorithm rule of detection, 【Rule】choose different algorithm rules, the related setting page is different.
  • Page 59 alarm will be triggered; Warning area: can set 3 kinds of prohibited directions: bidirectional prohibited, enter and leave, when the moving object meet preset warning area rules, alarm will be triggered.  Rules click setting，enter rule setting page, right click mouse, choose add, use mouse to fix two or more point, and then connect them to form a line or a irregular region, after that a box of prohibited direction options will come out, choose one of them, right click mouse, click Yes, return to previous page, click Yes, alarm rules setting is finished.
  • Page 60 similar with Items stranded.  Rules click setting,enter the setting page of rule, right click mouse, choose add, use mouse to fix several points and then connect them to form a irregular region, right click mouse, click Yes, return to previous page, click Yes, alarm rule setting if finished. Pic 4.14 rule setting - items care Video diagnosis: ...

  • Page 61: System Setup

    Pic 4.15 rule setting page of video diagnosis The setting way of set / withdraw garrison time period and linkage parameter, please refer to chapter“4.3.1 motion detection” For example：enable video analysis function, algorithm rules is PEA, the alert way in the rule is Cordon, prohibited direction is bidirectional, when a moving object across this warning line, alarm is triggered, see below pic4.16 Pic 4.16 the alarm image regarding one of the video analysis...

  • Page 62: General

    mode）、Network, Net service、GUI display、PTZ configure/RS485 device、RS232、Tour setup、Spot and digital。 4.4.1 General Picture 4.17 General setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY. 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour. 【Language】support 29 language at present: Arabic,Czech,English,Finnish,Greek,Indonesian,Italian,,Japanese,Portuguese,Russian,Thai,T-...

  • Page 63: Encode Setup

    【Video Standard】PAL or NTSC. 【Auto Logout】Set the latency time in 0-60. 0 means no latency time. 【Machine Name】Can setting the device's name. 【DST】Choose the summer time option and pop the dialog box as followed. Picture 4.18 DST (week) Picture 4.19 DST (date) 4.4.2 Encode setup *only 6000 series and HVR (other products only have analog channel) under Hybrid mode/full analog mode ,it has encode setup function,encode settings is for analog channel only.
  • Page 64 Picture 4.20 Encode setup Independent channel code setting 【Channel】Choose the channel number. 【Compression】Standard H.264 main profile. 【Resolution】Resolution type:1080P/720P/960H/D1/ HD1/CIF / QCIF. 【Frame Rate】P:1 frame/s~25 frame/s; N: 1 frame/s~30 frame/s 【Bit Rate Type】You can choose limited code stream or variable code stream. When you choose the variable code stream there are six image quality options.under the limited code stream，you can choose the code stream manually；...

  • Page 65: Network Setup

    resolution, frame rate, bit rate type settings is the same as main stream. 4.4.3 Network setup Picture4.21 Network 【Net Card】You can choose cable network card or wireless network card. 【DHCP Enable】Obtain IP address automatically(not suggested) Note：DHCP server is preinstalled. 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code.

  • Page 66: Netservice

    the image quality precedence and fluency precedence. Fluency precedence and self-adaption are valid only when the assistant code stream is turned on. Otherwise image quality precedence is valid. 4.4.4 NetService Choose the network service option and click the set button to configure the advanced network functions or double click the service button to configure the parameters.
  • Page 67 Input the user name and password that ISP（Internet service provider）provides. After saving it reboot up your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done. Operation：After PPPoE dialing successfully look up the IP address in the [IP address] and obtain the current IP address.
  • Page 68 Picture 4.25 EMAIL SMTP server:Email server address. It could be an IP address or domain name. Domain name can be translated only it is the correct DNS configuration. Port:Email server port number. SSL:Decide whether using Secure Socket Layer protocol to login. User Name:Apply the email server user name.
  • Page 69 precedence is higher. Picture 4.26 IP FILTER 【DDNS】 Picture 4.27 DDNS setup It is the abbreviation of dynamic domain name server. Local domain name：Provide the domain name registered by DDNS. User name：Provide the account registered by DDNS. Password：Provide the password registered by DDNS. When the DDNS is successfully configured and start, you can connect the domain name in the IE address column to visit.

  • Page 70: Enable】Click Enable,Then All Settings Will Be Available

    【FTP setup】 FTP is available only when alarm happens,or alarm activates record and snapshot,it will upload related record and snapshot pictures to FTP server. Picture 4.28 FTP setup 【Enable】Click Enable,then all settings will be available 【Server IP】 IP address for FTP server 【Port】...
  • Page 71 Picture 4.29 ARSP [Type] choose "DNS" [Enable]: ■ means it is chosen [Sever IP]: IP address of DDNS server [Port]: Port No. of device, related DDNS server listen port [User name] the user name that device can log in DDNS server [Password] the password related to the user name.
  • Page 72 【Server IP】IP address of Alarm Server 【Port】Device Port No. 【Alarm Report】Tick it means to report alarm information to server. 【Log Report】Tick it, means to report log to server. 【Wireless Config】 ADSL through 3G net card,use CMS to visit and config the device Picture 4.31 Wireless Config 【Enable】Choose Enable to make all settings available 【Type】Dial type,default AUTO...
  • Page 73 Picture 4.32 Mobile Monitor Setup 【Enable】 Select it to make sure abnormal function workable 【Port】 It’s a port of mobile monitoring which you need to make a router mapping of if want to visit it by mobile 【UPNP】 UPNP protocol is to realize auto port forwarding on router, precondition of using this function is to make sure the UPNP function of router is enabled.
  • Page 74 need this port. 【WIFI】 DVR connect to wireless router via WIFI module, then to visit it through IP address, the precondition of using this function is to make sure the DVR have connected with WIFI modern. Pic 4.34 WIFI configure 【Search】：click【search】to search all the available wireless device in current range.

  • Page 75: Gui Display

    Pic 4.35 RTSP setting 【Enable】：■ means enable, tick it firstly before setting. 【Port】：the default port is 554 4.4.5 GUI Display Configure the video output parameters including the front output mode and encode output mode. Front output：In the local preview mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover.
  • Page 76 The GUI display page under full digital(NVR) channel Pic 4.36 output mode 【Channel Title】Click the channel name modify button and enter the channel name menu. Modify the channel name. The 16 Chinese characters and 25 letters are supportive. 【Time Display】means the selective state. Display the system data and time in the surveillance window.

  • Page 77: Ptz Device /Rs485 Device

    【Time display】and 【Channel display】 set the display position of channel title and time title. *the channel no., region cover, time title and channel title setting function exist at output mode only when the device is under hybrid(HVR) mode or full analog(DVR) mode. 4.4.6 PTZ device /RS485 device * when under hybrid mode/full digital mode, it shows with PTZ device and RS485 device, Pic 4.37 PTZ configure...

  • Page 78: Rs232

    4.38 RS485 device 【Protocol】choose related protocol of brand model( for example: DaHua)； 【Address】set with corresponding address, default is 1； 【Baud rate】choose bard rate that related device use, default is 115200； 【Data bits】including 5-8 options，default is 8； 【Stop bits】including 2 options, default is 1； 【Parity】Include odd check, even check, sign check, blank check.

  • Page 79: Tour

    Pic 4.39 serial port setting 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options. 【Parity】Include odd, even, mark, space, default is none. 4.4.8 Tour Set the patrol display.

  • Page 80: Spot Configure

    Pic 4.40 tour configure 【interval】Set the patrol switch interval. The set range is 5-120 seconds. 【alarm tour】set the interval to shift alarm tour, range is 5-120 seconds, choose return when alarm ends, when alarm link to tour, system will auto shift to six-view after alarm finished. Remark：at preview mode, click upper right icon can turn on / off tour（...

  • Page 81: Channel Manage

    Pic 4.41 Spot configure 【interval】Set the patrol switch interval. The set range is 5-120 seconds. 4.5.0 Channel manage *Remark：only HVR and 6000 series product support this function. Digital manage including digital channel, channel status, and channel mode (Remark: there is only analog mode if device is under full analog mode): Channel manage page under all analog(DVR) mode...
  • Page 82 Channel manage page under Hybrid(HVR) mode / full digital(NVR) mode Pic 4.42 channel manage interface Digital channel: Single link page of digital channel...
  • Page 83 Multi-linkage page of Digital channel Pic 4.43 digital channel interface 【Channel】select channel title 【Enable】Open digital channel, tick enable, then can do related settings 【Time Synchronization】Tick it means the time of this channel and device is the same. 【Connection Mode】can be singe connect or multi-ink, multi-link modes can connect to several devices, device will be tour displayed one by one, tour interval can be set, no less then 10s;...
  • Page 84 Pic 4.44 remote channel configure page 【Configure Name】device is with default configure title, user can revise it if necessary； 【Device Type】3 types: IPC、DVR、HVR，user can choose as what you like, default is IPC； 【Protocol】Default is TCP 【Remote channel】User can input remote channel title from the device that you want to connect remotely 【Stream】Default is main stream, do not support extra-stream at present；...
  • Page 85 Pic 4.45 the device list searched under remote channel setting Channel Status: channel status is to show the status of all the digital channel When there is what existing, status including Max Resolution, This Resolution, Connection Status. For example: The channel status for 4+2 mode is as below: When a channel is added with device but it is not enable, you will see as below:...
  • Page 86 Channel status interface under full digital(NVR) mode (One of the channel without device) Remark: when the current resolution is over the max resolution that the channel supported, then a red “X” will be shown on the preview image, for example: Under full digital channel mode, Max resolution of channel 3 is D1, if it was connected to a device with resolution over D1 ( such as 960H), you will see below pic: Channel mode:...

  • Page 87: Advanced

    Remark: this series of product with full analog channel mode, hybrid mode and full digital mode, and different model with different channel mode, user can shift the mode freely if necessary. 4.5 Advanced Manage tools menu including: HDD manage, account manage, online user, output adjust, auto maintain, upgrade.

  • Page 88: Account

    Pic 4.46 HDD manage 4.5.2 Account Manage the user purview. Note：1. The character length is 8 bytes at most for the following user and user team name. The blank ahead or behind the character string is invalid.The middle blank in the character string is valid. Legal characters include: letter, number, underline, subtraction sign, dot.
  • Page 89 Pic 4.47 account management 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed team attribute. 【Modify Password】Modify the user password. You can set 1-6 bit password. The blank ahead or behind the char string is invalid. The middle blank in the char string is valid. Note：The user who possess the user control purview can modify his/her own or other users password Pic 4.48 modify password...
  • Page 90 means that the account can be used by multiple users at the same time. Once choose the team the user purview is the subclass of the team. We recommend that the common user’s purview is lower than the advanced user. Pic 4.49 Add User 【Add Group】Add a user group and set the purview.

  • Page 91: Online User

    【Delete User】Delete the current user. Choose the user and click delete user button. 【Delete Group】Delete the current group. Choose the group and click delete group button. Pic 4.51 Delete Group 4.5.3 Online user To check the information of network user that connected with local device, also can tick the selected user to break up connection,（make √...

  • Page 92: Tv Adjust

    4.5.4 TV adjust Refer to chapter 3.5.7 . 4.5.5 Auto Maintain The user can set the time to auto reboot and auto delete file. Picture 4.39 Auto maintain 4.5.6 Restore The system restore to the default . You can choose the items according to the menu. Pic 4.54 restore to default...

  • Page 93: Upgrade

    4.5.7 Upgrade Upgrade Pic 4.55 【Upgrade】choose USB interface. 【Upgrade file】choose the upgrade file. 4.5.8 Device Info Provide device interface info like audio in,alarm in/out to be conveniently used for user. Pic 4.56 device info 4.5.9 Import / Export Users can export the log info and the configure file from device to connected flash stick, and also can import related configure file from flash stick to settings, which greatly bring convenience to the...

  • Page 94: Info

    customers. 4.57 Import / Export interface 4.6 Info Display the hard disk information, including HDD info, code stream statistic, log info, version info 4.6.1 HDD info Display the hard disk state: hard disk type, overall capability, residual capability, the recording time and so on.

  • Page 95: Bps

    Pic 4.58 HDD info Tips：○ means that the hard disk is normal. X means that the hard disk is broken-down.- means that there is no hard disk. If the user need to change the damaged hard disk, you must shut down the DVR and take up all the damaged hard disks,then install a new one.

  • Page 96: Log

    Pic 4.59 BPS 4.6.3 LOG To search log information base on the set search mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, user management, file management and so on. Set the time section to look up and click the look up button.

  • Page 97: Version

    Pic: 4.60 Log information 4.6.4 Version Display the basic information such as hardware information, software version, issue date, serial number , NAT status and so on. Pic 4.61 version information...

  • Page 98: Shut Down System

    4.7 Shut down system Refer to chapter 3.5.8. Chapter 5: Cloud Technology Basic Operation Cloud technology monitor Cloud technology make the device one step on net, greatly bring convenience for customer to monitor via wide area network, this technology is using the serial no to visit device. *Remark：the device that using cloud technology should be in the WAN( Wide Area Network )firstly.
  • Page 99 Connect failed interface successfully connect interface Pic 5.1 cloud technology server connection status  Log in cloud server Visit http://xmeye.net to see below log in page, it devided into two mode: by user and by device, user can base on their need to log in freely. *Remark: to log in “by user”, the user need to register at the first time.
  • Page 100  Log in by user Customer use their registered user name and password to log in, will see below interface Pic 5.3 cloud technology operation interface Device manage Mainly use to add device, click “add”to add the serial number of device to be monitored. Pic 5.4 device manage interface...
  • Page 101 Pic 5.5 add interface at device manage *Remark：in pic 5.5, the user name means the user name of monitored device, password means the password of related user. My Device Mainly show all the added device here, click the on-line device name, can access to control this device accordingly.
  • Page 102 Pic 5.6 monitor page - log in by user *Remark：the icon of“ ” means offline, the device do not connect to server successfully.  Log in by device...
  • Page 103 Pic 5.7 interface of log in by device Input the serial number of device and the verify code to monitor and control the device directly. Pic: 5.8 monitor page - log in by device...

  • Page 105: Faq And Maintenance

    The hard disk power supply line is not connected. The cables of the hard disk are damaged. The hard disk is damaged. Manual de Instalación HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
  • Page 106 The SATA port of main board is damaged. 4、 There are no video outputs in single channel, multiple channels and all channels. Possible reasons are as followed: The program is not matched. Please update the program. The image brightness is all 0. Please restore the default setup. There is no video input signal or the signal is too weak.
  • Page 107 The hard disk is damaged. The hardware of the DVR is damaged. 8、 There is no audio signal in the surveillance window. Possible reasons are as followed: It is not an active tone arm. It is not an active sound box. The audio lines are damaged.
  • Page 108 The distance is too far. 12、 The motion detect is not working, Possible reasons are as followed: The time range set is not correct. The motion detect area set is not correct. The sensitivity is too low. Limited by some hardware edition. 13、...
  • Page 109 IP address is conflicted. MAC address is conflicted. The net card of the DVR is bad. 16、 There is something wrong with the USB backup or writing a CD. Possible reasons are as followed: The rewritable machine and the hard disk are shared the same data lines. The data is too much.
  • Page 110 20、 The remote controller is not working, Possible reasons are as followed: The remote control address is not correct. The remote control distance is too far or the angle is too large. The battery is used up. The remote controller or the front panel of the recording machine is damaged. 21、...

  • Page 111: Maintenance

    6 Stream for remote channel was set by extra stream. 7 User name & password not matched 8 directly input with IP address or port No. incorrectly when adding device. 9. The resolution of added device is too large to display by the monitor. 25、...
  • Page 112 Do not use the TV in the local video output port(VOUT) of DVR. It will damage the video output circuit easily. Do not turn off the switch directly. Please use the turn-off function in the menu or press the turn-off button in the panel (3 seconds or longer) to protect the hard disk. Please keep the DVR away from heat resource.

  • Page 113: Appendix 1.Remote Controller Operation

    Control the record Record mode Same function as “Record mode” Input the number of DVR to control it Assistant function Manual de Instalación HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 114: Appendix 2.Mouse Operation

    Choose the widget or move the item in the widget Set the motion detect area Drag mouse Set the cover area Manual de Instalación HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail: ventas@starligh.com www.starligh.com...

  • Page 115: Appendix 3.Hard Disk Capability Calculation

    For one piece 500G HDD,real time CIF for recording,it will keep recording for about 25 days.HDD spaces per channel is 200M/H,if 4channels real time CIF at 24hours recording uninterrupted,it can last:500G/(200M/H*24H*4ch)=26 days Manual de HDVR STARLIGH Santa Rosa 1501 (X5000ETE) Bº Alberdi. Córdoba. Tel/fax 54(0351) 4809210 y rotativas mail:...
