Loopcomm LP-8097 User Manual

802.11ac wireless usb 3.0 dongle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
802.11ac Wireless USB 3.0 Dongle
USER MANUAL 1.0
© 2013
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP-8097 and is the answer not in the manual?

Questions and answers

Summary of Contents for Loopcomm LP-8097

  • Page 1 802.11ac Wireless USB 3.0 Dongle USER MANUAL 1.0 © 2013...

  • Page 2: Table Of Contents

    Contents Introduction ......................3 Driver Installation ....................4 Windows 7 ....................4 Wireless Network Configuration ................6 Utility Icon ....................6 Client Mode ....................6 3.2.1 Wireless Device Control ..............6 3.2.2 General Setting ................. 7 3.2.3 Profile Setting ................... 8 3.2.4 Available Network Setting ..............

  • Page 3: Introduction

    Introduction Thank you for your purchase of the WLAN Dongle. Featuring wireless technology, this wireless networking solution has been designed for both large and small businesses, and it is scalable so that you can easily add more users and new network features depending on your business scale.

  • Page 4: Driver Installation

    Driver Installation Windows 7 Notes: The following installation was operated under Windows 7. (Procedures are similar for Windows XP /vista) Step 1: Insert the installation CD into your CD-ROM. Step 2: Welcome Installation dialog prompt shown. Click Next to continue. Click Cancel to close installation.
  • Page 5 Step 3: Click Finish to complete installation.

  • Page 6: Wireless Network Configuration

    Wireless Network Configuration The management software is provided for the WLAN dongle. When you insert the WLAN Adapter into your laptop or desktop, an icon should appear in the Windows System Tray automatically. Utility Icon Client mode utility running but no WLAN Adapter plugged. Client mode utility running and WLAN Adapter scan available network.

  • Page 7: General Setting

    3.2.2 General Setting Once device is set, double click on that icon and the configuration window will pop up as shown. It shows the current connected network. The signal strength and link quality are also displayed. The bar graph displays the quality and strength of the link between the node and its Access Point.

  • Page 8: Profile Setting

    3.2.3 Profile Setting In profile tab, you can Add, Remove, Edit, Duplicate Set Default to manipulate profile content manually. Strongly recommend to use profile after you do Available Network.

  • Page 9: Available Network Setting

    3.2.4 Available Network Setting Click Available Network tab and it will show all available networks that radio can reaches. Select proper SSID & BSSID you want to connect. Click Refresh button to force and rescan available networks currently. Select one of SSIDs, and click Add to Profile to create profile that can be configured more wireless parameters.
  • Page 10 In this page, you can edit your profile name; configure wireless security like WEP, WPA, WPA2, 802.1x …etc. After finishing setup, click button to save configuration.

  • Page 11: Status

    3.2.5 Status In this page, it shows all wireless, networking and device driver version of 2.4GHz in detail. In this page, it shows all wireless, networking and device driver version of 802.11n 5GHz in detail...
  • Page 12 In this page, it shows all wireless, networking and device driver version of 802.11ac 5GHz in detail.

  • Page 13: Statistics Page

    3.2.6 Statistics Page The Tx/Rx status of current wireless connection is shown. A statistic analysis of packet transition is listed.

  • Page 14: Wi-Fi Protected Setup

    3.2.7 Wi-Fi Protected Setup There is an easy and secure setup solution for Wi-Fi network. You can choose PIN Code or Push Button method to connect to an AP.

  • Page 15: Access Point Mode

    Access Point Mode General Page This page provides general information of this AP, including name, MAC address and list of joined stations. 1. SSID: The name of this AP. 2. BSSID: Six two-digital numbers of the MAC address of this AP. 3.
  • Page 16 Network Name (SSID): The name of the AP is searchable by other wireless nodes. The length of SSID should be shorter than 32 characters. Channel: Select the wireless channel within current channel plan. Network Authentication & Data Encryption : Open System: ...
  • Page 17 Advanced Page Users could setup the advanced characteristics of network packet for transmission on this page. 1. Beacon Interval: This filed indicates the interval between each beacon that this AP sends out in unit of TU (1024 micro-seconds). 2. DTIM Period: The DTIM Period field is the number of Beacon intervals between successive DTIMs.
  • Page 18 Statistics Page The Tx/Rx status of current wireless connection is shown. A statistic analysis of packet transition is listed.

  • Page 19: Troubleshooting

    Troubleshooting Symptom : The LED is off. Make sure the PC Card is inserted properly. Otherwise contact your Remedy : vendor. Symptom : The LED is always on not blinking. Make sure that you have installed the driver from attached CD. Remedy : Otherwise contact your vendor.

  • Page 20: Glossary

    Glossary 1. IEEE 802.11 Standard The IEEE 802.11 Wireless LAN standards subcommittee, which is formulating a standard for the industry. 2. Access Point An internetworking device that seamlessly connects wired and wireless networks together. 3. Ad Hoc An Ad Hoc wireless LAN is a group of computers, each with a WLAN adapter, connected as an independent wireless LAN Ad Hoc wireless LAN is applicable at a departmental scale for a branch or SOHO operation.
  • Page 21 wired LAN is called an Infrastructure configuration. Infrastructure is applicable to enterprise scale for wireless access to central database, or wireless 11. ISM Band The FCC and their counterparts outside of the U.S. have set aside bandwidth for unlicensed use in the so-called ISM (Industrial, Scientific and Medical) band. Spectrum in the vicinity of 2.4 GHz, in particular, is being made available (Industrial, Scientific and Medical) band.
  • Page 22 20. Wi-Fi Alliance The Wi-Fi Alliance is a nonprofit international association formed in 1999 to certify interoperability of wireless Local Area Network products based on IEEE 802.11 specification. The goal of the Wi-Fi Alliance’s members is to enhance the user experience through product interoperability.
  • Page 23 RTS/CTS transaction. The IEEE802.11-1997 standard allows for short packets to be transmitted without RTS/CTS transactions. Each station can have a different RTS threshold. RTS/CTS is used when the data packet size exceeds the defined RTS threshold. With the CSMA/CA transmission mechanism, the transmitting station sends out an RTS packet to the receiving station, and waits for the receiving station to send back a CTS (Clear to Send) packet before sending the actual packet data.
