- Page 1 User/Installation Manual PROXIMITY 2000 MODEL 23-006(I) trol” “Your Partner in Access Con www.americanaccess.com...
- Page 2 AAS 2Year Limited Warranty What item(s) this warranty applies to: American Access Systems “Prox 2000 (23-XXX series)” access controls. What is covered: Any defect in materials or workmanship. For how long: Two years from date of purchase. What we will do: If your AAS product is defective and returned within 2 years of the date of purchase, we will repair it or, at our option, replace it at no charge to you.
-
Page 3: Parts Checklist
PARTS CHECKLIST Enclosed with this box you should have the following items. Description Post Mount reader Station Hardware Package If any of the above items are missing from this box, contact American Access Systems Tools Needed For Basic Installation • • Wire nuts or appropriate connectors •... - Page 4 STEP 1-MOUNTING THE UNIT Mounting the unit to your own pedestal Your slave units come with a square mounting flange found in the bottom of the box along with four carriage bolts and four hex nuts. The square mounting flange may be welded to your pedestal and the flange bolt pattern will align with the back of the unit.
-
Page 5: Wiring Instructions
WIRING INSTRUCTIONS The 23-013 Prox Point is a standard 26-bit Weigand card reader. Use the table below to install to your 26-bit Weigand controller port. Weigand Clock Data Wire Color Ground Ground Black LED Input Green LED Orange Data 0 Data Green Data 1... -
Page 6: Customer Service And Tech Support
CUSTOMER SERVICE AND TECH SUPPORT Customer Service: 303-799-9757 Customer service is available free of charge. Hours are 8:00 a.m. to 4:30 p.m. MST. If you call, please have your Model and Serial Number to help our Technicians assist you. E-Mail: customerservice@securitybrandsinc.com Technical Support: 303-799-9757 Technical support is available free of charge. - Page 7 NOTES Page 7 American Access Systems / Security Brands, Inc.
