Summary of Contents for ShorePower WU-120
- Page 1 Level One Electric Vehicle Charging Station Wall Mount Product Guide WU-120 Model # ShorePower Technologies 2351 NW York St. Portland, OR 98664 503-892-7345 info@shorepower.com www.shorepower.com...
-
Page 3: Table Of Contents
Table of Contents Warnings Installation & Mounting Usage Maintenance & Cleaning P.10 Troubleshooting P.11 Features & Specifications P.12 Accessories P.13 Warranty P.14 Other ShorePower Products P.15... -
Page 4: Installation & Mounting
Installation & Mounting 1. Using Diagram 1, mark the mounting bolt pattern on your mounting surface 2. Drill Pilot holes into the mounting surface (Follow the fastener recommen- dations as to the depth and diameter of the pilot hole. Different materials will require different fas- teners and pilot holes. - Page 5 4. Locate the wiring conduit knockout at the base of the charging station. Se- lect which knockout to punch by sizing against your conduit diameter. 5. Remove the selected knockout. 6. Insert the conduit pass through hardware into the knockout hole...
- Page 6 7. Attach the conduit hard- ware nut to the protrud- ing conduit. 8. Tighten to the recom- mended specifications...
- Page 7 9. Run the 4 conductor ser- vice cable through con- duit into the charging sta- tion 10.Connect each of the 4 leads to the appropriate distribution lugs as shown 11.Torque the allen head lug screws to the recom- mended specifications G L1 N...
- Page 8 Mounting Bolt Pattern is a 18.5” x 14.5” Rectangle as seen Below Diagram 1...
-
Page 9: Usage
Usage Shorepower Level 1 Charging Stations work like any standard 120 volt oulet with one exception. We recommend that the circuit breaker for the specific outlet you intend to use, be shut off prior to plugging in. Once plugged in, you can then switch the circuit breaker back on and commence charging. -
Page 10: Maintenance & Cleaning
Maintenance & Cleaning Regular maintenance is not generally required on ShorePower Charging Stations. However you may find the need to replace the illumination bulb within the Unit. To do so, follow these simple steps: 1. Shut off main power service to Charging Station 2. -
Page 11: Troubleshooting
Troubleshooting Problem: Charging Station Does not Light Up Shut power to station off Open charging station with the included door key Verify that the lighting circuit breaker mounted on the back panel is switched to the on position Remove the light bulb and test it a known good standard light fixture such as a table lamp Problem: Charging Station does not charge Vehicle (No Power Output) Verify all Circuit Breakers are in the on position... -
Page 12: Features & Specifications
Outdoor Rating NEMA Dimensions H20” x W16” x D9” Weight 40 Pnds apx. Visibility Backlit Outlets and ShorePower Logo for Nighttime Visibility Upgradability Fully Upgradable to future Level 2, SAE J1772 Stan- dards, with corded Connector Warranty Full 10 Year Warranty against Defects in workman- ship and materials. -
Page 13: Accessories
Switch Power ports on and off via our web interface Meter power usage per individual power out- let and access Statistical data via our web in- terface Call ShorePower Technologies for Pricing and detailed information 503-892-7345... -
Page 14: Warranty
To obtain warranty service the purchaser should return the prod- uct to the place of purchase or deliver the product prepaid to ShorePower Technologies at the address set forth below. Proof of purchase in the form of a receipt or invoice, which is evidence that the unit is within the warranty period, must be presented to obtain warranty service. -
Page 15: Other Shorepower Products
Other ShorePower Products Level 1 & 2 Free Standing EV Charging Stations Truck Stop Electrification Pedestals...
