teleloop amplifier
Your local representative:
GB user gui de
International: +45 3917 7101 • germany (kostenlose Rufnummer): 0800/1844736
u.s.: 800.227.0735, then press 7 • canada: 800.263.8700 • website: www.phonicear.dk
o t h e r r es o u r c e s o n l i n e a t w w w. p h o n i c e a r. d k
© 2005 Phonic Ear A/S
921-21-110-00/Rev.
Advertisement
Summary of Contents for PhonicEar LOOP
- Page 1 International: +45 3917 7101 • germany (kostenlose Rufnummer): 0800/1844736 u.s.: 800.227.0735, then press 7 • canada: 800.263.8700 • website: www.phonicear.dk o t h e r r es o u r c e s o n l i n e a t w w w. p h o n i c e a r. d k ©...
-
Page 2: Table Of Contents
LOOP instructions ........ -
Page 3: Loop Function
function is the P system’s teleloop amplifier. L transfers the sound from TV and radio UZZLE directly to your hearing aid (or telemagnetic receiver) and you receive the sound loud and clear. can also receive alarms from the P system’s alerting transmitters (D and/or UZZLE ETECT... -
Page 4: Loop Features
1 channel tuner To set personal code for use with other P systems UZZLE 2 loop connection To connect teleloop cable 3 12V AC/18V DC connection back To connect 12volt power transformer 4 radio/TV connections To connect radio, television, etc. -
Page 5: Loop Accessories
(not included, sold separately) microphone 16 Clip Placed in front of source loudspeaker if sound source cannot be attached to teleloop amplifer by an output connection. Can also be used to amplify conversations. boundary microphone (not shown) cusion loop (not shown) -
Page 6: Loop Instructions
If cable is too long, shorten it to fit room size. Cushion L (sold separately) Place cushion loop pad under a cush- ion in the seat where you are listening to the sound source. The cushion loop limits the range of the teleloop and possible “interference ability”. - Page 7 instructions connect to TV and radio TV connection Plug one end of the cable (from connector set) into one of the Radio/TV connections on back of L Then plug other end of the cable into Line Out or SCART connection on TV. Radio connection Plug one end of the cable (from connec- tor set) into one of the Radio/TV...
- Page 8 instructions connecting transformer Plug transformer cord into 12V AC 18V DC connec- tion on back of L Plug transformer into wall socket. Red light on front of L should go on. selecting personal code Use Channel tuner on back of to set personal code.
-
Page 9: Adjusting Volume
instructions Channel type X and Y Dip switch on underside of L should be in “X” position as stan- dard to use channels 0-F. (16) adjusting volume Use volume control on front of to adjust volume level: Min = Lowest volume Max = Highest volume NOTE: As a general rule, the volume should be adjusted so that... - Page 10 instructions adjusting bass and treble Turn left control on bottom of L clockwise to increase bass level and counterclockwise to reduce bass level. Turn right control on bottom of L clockwise to increase treble level and counterclockwise to reduce treble level. NOTE: Use the screwdriver included with L to adjust...
-
Page 11: Troubleshooting
troubleshooting Should your L teleloop amplifier not function satisfactorily, please check the list below: The red light on the front of L unit does not come on • Check to see that the wall contact is switched on. • Switch off the wall contact for 10 seconds and then switch it on again. The red light on the front of L comes on, but there is no signal when the TV or radio is turned on... -
Page 12: Warranty
warranty one-year limited warranty is issued to the original consumer of this product(s) by Phonic Ear (two years inside the EU). time period of warranty This warranty will go into effect upon the date of original purchase of this equipment, and will remain in effect for one calendar year (two years inside the EU) from that date as long as the instru- ment remains the property of the original consumer.
