Prestigio PMR-701(TV)
User's Manual
PRESTIGIO PMR-701 (TV)
1

Advertisement

Table of Contents
loading

Related Manuals for Prestigio PMR-701

Summary of Contents for Prestigio PMR-701

  • Page 1 Prestigio PMR-701(TV) User’s Manual PRESTIGIO PMR-701 (TV)
  • Page 2 Thanks for purchasing the device. Please read this manual carefully before using your product. This manual is subject to change for the purpose of performance improvement without prior notice. PRESTIGIO PMR-701 (TV)

  • Page 3: Table Of Contents

    Using One Click TransC ......27 TV (Option) ........14 One Click TransC Options ......28 Indoor and Outdoor use ......14 Channel Setup ..........15 Troubleshooting guide ..... 29 Recording from TV ........15 Product Specifications ...... 30 PRESTIGIO PMR-701 (TV)

  • Page 4: Safety Precaution

    14. Do not put the product in heating devices such as microwave ovens or ovens. 15. Do not use sharp devices and tools such as gimlet and knife against PMR. 16. Due to accidents risk, do not use the product while driving a car or walking). PRESTIGIO PMR-701 (TV)

  • Page 5: Features

    B grade device This product is registered and approved for home and office use. It can be safely used in all areas including your living place. PRESTIGIO PMR-701 (TV)

  • Page 6: Package Components, Controls And Connections

    1. PMR 7. INDOOR TV CABLE CONNECTOR 2. AC ADAPTER 8. PMR BODY HOLDER 3. USB CABLE 9. EARPHONE 4. USB HOST CABLE Others : User’s Manual, CD, etc 5. AV CABLE 6. OUTDOOR ANTENNA(TV) PRESTIGIO PMR-701 (TV)

  • Page 7: Description Of Controls

    * If the battery charge is insufficient, the battery indicator will flicker, and the power will be automatically turned off after a while. Battery charge indicator Fully charged (connected to outlet) Fully charged Half-charged Battery low Battery discharged PRESTIGIO PMR-701 (TV)

  • Page 8: Connections

    Connection with PC - Use USB cable supplied to Connect with PC. Connection with USB device - Connect the USB Host cable supplied between the USB Host port and other USB storage device. PRESTIGIO PMR-701 (TV)

  • Page 9: Usb Driver Installation (Windows 98 Se)

    Insert CD supplied with device in the CD-ROM and select “PMR Win98 Driver” . Install the driver by clicking NEXT button Press Finish button. If the USB driver is not installed properly or device inaccessible, delete the installed USB driver and reinstall it. PRESTIGIO PMR-701 (TV)

  • Page 10: Connecting To Pc

    * Choose the hardware you want to remove and click on the [Stop] button * When prompted by Windows, detach the USB cable If the USB cable is disconnected accidentally, some data may be lost and device may need maintenance PRESTIGIO PMR-701 (TV)

  • Page 11: Operating The Device

    Connect external USB storage devices (digital camera, card reader, USB Flash drive) RECORD Record voice or other sounds through built-in microphone MOVIE Playback video files MUSIC Playback audio files ALBUM Watch photos or other images e-BOOK View text file SETUP Setup various PMR options PRESTIGIO PMR-701 (TV)

  • Page 12: Power On/Off And Key Hold/Release

    * Select the file to delete and press ^ button, the file deleting popup menu will appear. * Select ‘Yes’ to delete the file and return to the search window. <Select the file> <Confirm the deletion> The file will not be deleted during playback. PRESTIGIO PMR-701 (TV)

  • Page 13: Add To Playlist

    Go to “FUNCTION” in “SETUP” menu to select video/audio section repeat mode, then select desired option as follows: All files playback in the folder The current file Repeated playback of the current file repeat Random file playback Return to the search window after playback the current file PRESTIGIO PMR-701 (TV)

  • Page 14: Tv (Option)

    NTSC supports outdoor and indoor mode. Indoor enables the reception of cable broadcasting programs, while outdoor mode allows receiving air TV programs, but not cable TV channels. PAL TV system enables 4 areas to use both indoor and out- door as the above. PRESTIGIO PMR-701 (TV)

  • Page 15: Channel Setup

    Press “REC” to save the current channel into video (ASF) file or image (JPEG) file. Recorded files are saved in the following file name pattern in “Record Folder/Video” (or “RecordFolder/Image”) folder: * Air TV Channels > A_011_050101105142.ASF/JPG (A_Channel_Y/M/D/H/M/S) * Cable Channels > C_030_050101106345.ASF/JPG (C_Channel_Y/M/D/H/M/S) * TV programmed recording > R_005_050101114215.ASF (R_Channel_Y/M/D/H/M/S) PRESTIGIO PMR-701 (TV)

  • Page 16: Input

    Please use Setup menu (see below) for advanced recording settings. Radio Select (Radio) icon and press jog button to select FM radio function. FM Radio will not work with earphones not connected to the jack of PMR <RADIO Icon> <RADIO> PRESTIGIO PMR-701 (TV)

  • Page 17: Channel Setup

    * Select “Save channel” and press ( button to save the channel. <Auto program> <Manual program> Recording from Radio Press REC button to save current program into MP3 file. Recorded files are saved in the following file name pattern in “RecordFolder/Audio” folder: Radio > RADIO_050101062122.MP3 (RADIO_Y/M/D/H/M/S) PRESTIGIO PMR-701 (TV)

  • Page 18: Usb Host

    Select (Record) icon and press jog button to enter Record Window. <RECORD Icon> <RECORD> You can choose the recording time between 5 minutes and 24 hours using jog button. Recorded files are saved in the following file name pattern in “RecordFolder/Audio” folder: Voice Recording > VOICE_050101055903.MP3 (VOICE_Y/M/D/H/M/S) PRESTIGIO PMR-701 (TV)

  • Page 19: Movie

    Select the file you want to play and use ( or press jog button to play. During playback the following information can be displayed on the screen: * To zoom video (2x/4x) press REC buttonduring playback. * Subtitle appears when enabled and language selected in SETUP menu (see below) PRESTIGIO PMR-701 (TV)

  • Page 20: Music

    Select the file you want to play and use >> or press jog button to play. Pressing jog button during music playback will open current music information/ navigation window: ID3 tag information will appear if contained in MP3 file. Recorded radio/voice files doesn’t contain such data. PRESTIGIO PMR-701 (TV)

  • Page 21: Album

    Select the file you want to display and use >> or press jog button to start playback. To set Slide Show delay, please use “Slide Show Time” option in Setup menu: E-Book Select e-BOOK icon and press jog button to search and open e-book file list. <e-BOOK Icon> <e-BOOK> PRESTIGIO PMR-701 (TV)

  • Page 22: Setup

    Select SETUP icon and press jog button to open SETUP menu. <SETUP Icon> <SETUP Menu> Display Select DISPLAY icon and press jog button to open DISPLAY Menu Window. < DISPLAY Menu > < DISPAY Menu Window > PRESTIGIO PMR-701 (TV)

  • Page 23: Sound

    Select FUNCTION Icon and press jog button to open FUNCTION Menu Window. < FUNCTION Menu > < FUNCTION Menu Window > Output Color System: setup NTSC or PAL according to external display equipment. Input Color System (Option): setup NTSC or PAL according to the external video signal. PRESTIGIO PMR-701 (TV)

  • Page 24: Device

    (this option has no effect in TV or Video mode) HDD Power Management: when on, this function saves battery power by putting hard disk into power saving mode. PRESTIGIO PMR-701 (TV)

  • Page 25: Time

    Auto sleep: allows turning off device if there is no signal at TV/AV input, no file is being played and no keys pressed for time period specified in Sleep Timer option. Sleep timer: sets timeout for Auto sleep function. PRESTIGIO PMR-701 (TV)

  • Page 26: Firmware Update

    5. Disconnect PMR from PC using “Safe Removal” procedure (see above). 6. Upon disconnect your PMR will start updating process automatically. DO NOT TURN DEVICE OFF DURING UPDATE – IT MAY LEAD TO PERMANENT UNIT MALFUNCTION AND WILL VOID THE WARRANTY PRESTIGIO PMR-701 (TV)

  • Page 27: One Click Transc Software

    Run PMRtransc_setup.exe file from CD supplied with the product to install the soft- ware. Then follow Installation Wizard instructions Using One Click TransC 1. Run installed One Click TransC software. Main program screen will appear: 2. Select the file you want to convert by clicking on Add Files: PRESTIGIO PMR-701 (TV)

  • Page 28: One Click Transc Options

    “Setup File Format” button: Allows setting specific file encoding options. “Resolution and Framerate” button: Changes the file resolution and the framerate for target file. “Setup Watermark”: Allows selecting BMP file to embed into target file as watermark. PRESTIGIO PMR-701 (TV)

  • Page 29: Troubleshooting Guide

    A. Check to see if the earphone is fixed correctly into the jack Q. The buttons do not work A1. Check the battery charge. A2. Check the power button to see if it is not in HOLD position. PRESTIGIO PMR-701 (TV)

  • Page 30: Product Specifications

    Video: DivX, XviD, WMV Li-polymer Battery (QPEL/GMC options not supported) Audio: AC3, MPEG 1/2/2.5 Layer 3, WMA 3.5”TFT LCD Image: JPEG Encoding Video: ASF (640X480, 320X240, 192X144) Audio: MP3 Image: JPEG (720X480, 640X480, 352X240) ID3 V1 Tag PRESTIGIO PMR-701 (TV)
