1.8. Specifications of appendix

System parameters
CPU
Main Frequency
Inner memory
Memory
SD card reader
Operating system
Interface definitions and specifications
USB
SD card
HDMI
Voltage parameters
Appearance description
Display
Dimensions

2. Mini Wireless 2.4 GHz RF Keyboard

2.1 Touchpad

The touchpad can be used in horizontal or vertical position.
To switch between horizontal and vertical mode, please
hold the "Fn" key and hit the "Alt" key.

2.2 Connecting the receiver

Slide the receiver out from the bottom of keyboard, and
insert to the devices with a standard USB port. Once
connected, slide the power switch to the "ON" position to
establish the connection.

2.3 Auto sleep and wake feature

If there is a long period of inactivity, the keyboard will automatically go into a sleep mode. During the
sleep mode, the user can wake it up by pressing any key. The 2.4 GHz receiver and keyboard's RF
indicator will continue to flash and will not power down.

2.4 Switching off the keyboard after use

After finishing using the keyboard, push the switch to the off position. The USB receiver should be
plugged out from the PC and then inserted back in the keyboard so it is being kept safely.
RK3066
Cortex-A9, Up to 1.6GHZ
1G DDR3
4G
Up to 32 GB
Android 4.0
USB HOST 2.0
MINI SD card
1.3
5V-1.5A
Through the HDMI output display
90 x 40 x 13 mm (L x W x H)
Point of view HDMI Smart TV dongle Mini RF Keyboard
