Summary of Contents for Magewell XI100XUSB-PRO
- Page 1 XI100XUSB-PRO All in One HD USB3.0 Capture Box User’s Guide Rev 1.0 2013/3/20 Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co.
-
Page 2: Table Of Contents
Content Preface ............................... 1 Minimum Hardware Configuration ......................1 Recommended Hardware Configuration....................1 System Requirements ..........................1 Hardware and Driver Installation ......................2 Connection of Video Input......................... 2 SDI Signal ............................2 DVI-D/DVI-I Signal ..........................3 HDMI Signal ............................3 VGA Signal ............................ - Page 3 10.2 Windows Vista, Windows 7, Windows 2008, Windows 2008 R2 ............14 11 Compatible Software Instruction ......................15...
-
Page 5: Preface
1 Preface Thank you for purchasing XI100XUSB-PRO USB3.0 capture box! The XI100XUSB-PRO capture box has a small size and is easy to carry, superior performance and flexible characteristics. The XI100XUSB can capture one High- Definition video signal or one Standard Definition video signal and one stereo analog audio signal. -
Page 6: Hardware And Driver Installation
Microsoft Windows Server 2008 Microsoft Windows 7 Microsoft Windows Server 2008 R2 5 Hardware and Driver Installation Please refer to "XI100XUSB-PRO Installation Guide" to install the hardware and the driver. 6 Connection of Video Input SDI Signal... -
Page 7: Dvi-D/Dvi-I Signal
DVI-D/DVI-I Signal Figure 2, 6.2 DVI-D/DVI-I signal connection sketch map HDMI Signal Figure 3, HDMI signal connection sketch map VGA Signal Figure 4, VGA signal connection sketch map... -
Page 8: Ypbpr Signal
YpbPr Signal Figure5, first YpbPr signal connection sketch map Figure6, second YpbPr signal connection sketch map Note: Second YpbPr signal should be chosen manually. CVBS signal 4/14 Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co. -
Page 9: S-Video Signal
Figure7, CVBS signal connection sketch map S-Video signal Figure8, S-video signal connection sketch map 7. Connection of Audio Signal Figure 9, audio line in signal connection sketch map Notes: The audio signal input is up to" Line in" level standard, if you need to connect microphone , must connect microphone with microphone input of "microphone amplifier"... -
Page 10: Video Capture Device Instruction
HD Video (XI100XUSB-Pro Box 1) XI100XUSB-PRO not only offers basic options, such as image brightness, contrast, hue, saturation, Gamma and so on, but also provides additional options for setting function. - Page 11 Figure 10 Device Properties tab Device Number: display serial of card, the number should be accorded with the barcode on the card. Version: display related version number; versions include hardware version, firmware version, driver version, and device serial. You may request user to provide relevant version number when you solve problems.
-
Page 12: Advanced Settings" Instruction
XI100XUSB will not work. You have to return back to factory for being repaired. "Advanced Settings" Instruction Figure 11, "Advanced Settings" page 8/14 Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co. -
Page 13: Input Signal
8.3.1 Input Signal 8.3.1.1 Input Interface By default, check “ Auto Select Input Interface ”, supporting input interface includes: DVI / HDMI input, YPbPr input, CVBS input, S-Video input. Notes: when “ Auto Select Input Interface ” is selected, if SDI, HDMI and YPbPr input interfaces all have signal access, then SDI input is preferred. -
Page 14: Image Output
Image clipping: Through adjust image width, height, left margin and top margin to achieve desired requirement. Increasing/reducing width of image starts from right; increasing/reducing height of image starts from below. Skills of image clipping as follows: 1. -
Page 15: Color Adjustment" Instruction
Scale: if image size is not unified with user setting, we provide three ways, full output image and keep aspect ratio, fill border to black and keep aspect ratio, clip border. Full output image and keep aspect ratio is default. ... -
Page 16: Video Formats Setting
9.1 Display "Filter Output Pin" In Common Software AMCAP: Double click "AmCap.exe", choose HD video device " HD Video (XI100XUSB-PRO Box 1)" in "Devices" menu, then click “Video Capture Pin ...”in "Settings" menu, pop-up " Filter Output Pin ". -
Page 17: Audio Capture Device Instruction
10 Audio Capture Device Instruction XI100XUSB-PRO support embedded HDMI and SDI in LPCM audio, based on the Microsoft DirectShow interface. After installation in operating system, the relevant audio devices will be added on. Any software which is compatible with DirectSound, DirectShow can use the recording device for capturing sound. - Page 18 Figure 15, Windows XP/2003“VolumeControl”-“Properties” dialogue 10.2 Windows Vista, Windows 7, Windows 2008, Windows 2008 HDMI In (XI100XUSB-PRO Box 1) , digital audio devices, embedded SDI or HDMI audio signal. Line In (XI100XUSB-PRO Box 1 , analog audio equipment Through system "Volume Control"...
- Page 19 Figure16 Windows Vista/7 dialogue 11 Compatible Software Instruction XI100XUSB-PRO can be compatible with variety of audio and video capture software which is based DirectShow interface, and audio capture software which is based DirectSound interface, such as: Windows Media Encoder ...
- Page 20 VideoLAN for Windows 16/14 Copyright © 2009-2010 All Rights Reserved. Nanjing Universal Networks Co.
