Hoffmann 906 series Installation & Operating Instructions

Hoffman
Installation & Operating Installation & Operating
Instructions

Thermostat Hardware

• Thermostat cover
• Thermostat base
• Electrical box cover (for a 2" X 4" electrical box).

Mounting Hardware

• Two #6 x 1/2" painted screws (secures electrical box
cover to electrical box).
• Two #6 x 1" phillips screws (secures Thermostat base to
electrical box cover).
• Three Wire nuts (secures stat wiring to field wiring).
• Two Wall anchors (for direct to wall mounting).

Electrical Mounting

All 906 Series Thermostats – Figure 1
(Miniature & standard sizes)
1. Remove Thermostat cover from Thermostat base. (See
Figure 3.)
2. Insert wires from Thermostat base through the 1/2"
hole in the electrical box cover.
3. Wire Thermostat to field Thermostat cable using wire
nuts. (Color-coded to assure proper connection.)
4. Mount electrical box cover to the electrical box with
two #6 x 1/2" painted head screws. (See Figure 1.)
Be sure the Thermostat base is centered on electrical
box cover. If incorrectly installed, the Thermostat base
will not symmetrically align with the electrical box
cover.
5. Attach Thermostat base to electrical box cover with the
two premounted #6 x 1" phillips screws. Do Not Remove
nylon shims. The Thermostat base can be mounted with
less than 1/16" clearance to the electrical box cover.
Clearance is required to allow the Thermostat cover to
snap onto the base.
| | |
Controls
NOTE
NOTE
Electronic Thermostats
CAUTION
Thermostat base should be firmly secured to the elec-
trical box cover. Do not over tighten!
6. Place Thermostat cover onto Thermostat base, securing
the left side first, then push right side until it "snaps"
securely into place.

Description

Direct To Wall Mounting – Figure 2
Miniature size, horizontal Thermostats
906-13 Series: 13AW, 13ADRW, 19CDRW, 19DDRW, 23W,
and 23ADRW only
1. Remove Thermostat cover from Thermostat base. (See
Figure 3.)
2. Wire Thermostat base to field Thermostat cable using
wire nuts. (Color coded to assure proper connection.)
3. Place the Thermostat base on the wall at the proposed
mounting location. Use the two premounted #6 x 1"
phillips screws (in the Thermostat base) as a template to
mark the location for the wall anchoring hole location.
4. Drill holes at markings for plastic wall anchors. Do Not
Remove nylon shims (holding the pre-mounted screws
in the Thermostat base).
5. Install wall anchors. Attach Thermostat base directly
to the wall with the two premounted #6 x 1" phillips
screws. Thermostat base will mount with less than 1/16"
clearance to wall.
6. Place Thermostat cover onto Thermostat base, secur-
ing left side first, then push right side until it "snaps"
securely into place.

Thermostat Release Cover

(Miniature size, horizontal Thermostats) Figure 3.
906-13 Series: 13AW, 13ADRW, 19CDRW, 19DDRW, 23W,
and 23 ADRW only
The Thermostat assembly should be held against a
solid surface, if it is not mounted on the wall.
1. When facing the Thermostat cover, place a small screw-
driver between the 4th and 5th ribbed openings on the
right side of the Thermostat cover.
906 Series
NOTE
