INSTALLATION INSTRUCTIONS
UNI-SPKR/UNI-SPKRB
On-Wall Speakers
NORTH AMERICA
EUROPE
3130 East Miraloma Avenue
Swallow House,
Anaheim, CA 92806 USA
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
USA and Canada
Phone: +44 (0) 2476 614700
Phone: 1.800.368.9700
Fax: 1.800.832.4888
Fax: +44 (0) 2476 614710
Other Locations
Phone: (001).714.632.7100
Fax: (001).714.632.1044
9533-034-001-05
Advertisement
Table of Contents
Summary of Contents for Premier Mounts UNI-SPKR
-
Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS UNI-SPKR/UNI-SPKRB On-Wall Speakers NORTH AMERICA EUROPE 3130 East Miraloma Avenue Swallow House, Anaheim, CA 92806 USA Shilton Industrial Estate, Shilton, Coventry, England CV79JY USA and Canada Phone: +44 (0) 2476 614700 Phone: 1.800.368.9700 Fax: 1.800.832.4888 Fax: +44 (0) 2476 614710 Other Locations Phone: (001).714.632.7100... -
Page 2: Table Of Contents
Premier Mounts does not warrant against damage caused by the use of any Premier Mounts product for purposes other than those for which it was designed or damage caused by unauthorized attachments or... -
Page 3: Installation Tools
Tape Measure Pencil Parts List Make sure your Premier Mounts product has the following hardware and components before beginning installation. If there are parts missing and/or damaged, stop the installation and call Premier Mounts at (800) 368-9700. Speaker Hardware On-Wall Speaker (Qty 2) -
Page 4: Features
UNI-SPKR/UNI-SPKRB Features The UNI-SPKR bundle provides the perfect audio solution for a classroom or meeting room environment. With 5.25” woofers and directional tweeters, the two 80/100W speakers deliver clear, dynamic sound for all purposes, including lectures and multimedia presentations. The on-wall speaker enclosures are tuned and ported before they leave the factory. -
Page 5: Installing The On-Wall Speakers
Installing the On-Wall Speakers Introduction The Premier Mounts On-Wall Speakers are designed for use with Premier Mounts’ Universal Short-Throw Projector Arm Mounts, Universal Digital Signage Mounts and GearBox™ Audio Mounts. All parts, metal plates, screws, and bolts required to complete the assembly are provided with the speakers. Please read through the safety instructions before installation. - Page 6 UNI-SPKR/UNI-SPKRB Step 2 The UNI-SPKR kit comes with 18 AWG speaker wires pre-installed. If you would like to replace the wires, follow these instructions. Remove the six (6) 4-40 x 1/4” Phillips flathead screws from each back cover of the speakers.
-
Page 7: Installing The Power Amp (Sold Separately)
The holes are for attaching M5 drywall anchors. ® Remove the speakers. ¯ Drill the drywall using a 3/8” drill bit where you made the marks. Proceed to Step 3 on page 8. Installation Instructions Page 7 Visit Premier Mounts website at http://www.premiermounts.com... -
Page 8: Aiming The Speakers (Optional)
Is the sound unclear from the sides of the room? If Yes, slightly pan the tweeters outward. If No, continue to step 9. µ When you are satisfied with the sound, re-attach the speaker grills. Page 8 Installation Instructions Visit the Premier Mounts website at http://www.premiermounts.com... -
Page 9: Technical Specifications
UNI-SPKR/UNI-SPKRB Technical Specifications All measurements are in inches [mm]. 3.39 19.41 86.04 492.99 3.60 91.49 19.41 3.60 492.99 91.49 8.44 6.90 214.43 175.26 10.38 263.53 Installation Instructions Page 9 Visit Premier Mounts website at http://www.premiermounts.com... -
Page 10: Warranty
What Premier Mounts Will Do At the sole option of Premier Mounts, Premier Mounts will repair or replace any product or product part that is defective. If Premier Mounts chooses to replace a defective product or part, a replacement product or part will be shipped to you at no charge, but you must pay any labor costs.
