COHU 3230 series Installation Manual

Analog environmental camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3230 SERIES ANALOG
ENVIRONMENTAL CAMERA
INSTALLATION MANUAL
RS-232
RS-422
Technical Manual 6X-1086
Figure 1. Model 3230 NTSC or PAL Camera
March 21, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3230 series and is the answer not in the manual?

Questions and answers

Related Manuals for COHU 3230 series

Summary of Contents for COHU 3230 series

  • Page 1 3230 SERIES ANALOG ENVIRONMENTAL CAMERA INSTALLATION MANUAL RS-232 RS-422 Figure 1. Model 3230 NTSC or PAL Camera Technical Manual 6X-1086 March 21, 2008...
  • Page 2 INSTALLATION MANUAL 3230 CAMERA Two other manuals related to this camera are available: 1. Manual 6X-1084. The setup GUI - for configuring camera characteristics 2. Manual 6X-1085. The protocol - for use by programmers to write software for controlling camera functions CAUTION Do not power the 24 V ac version of this camera directly from a Variac.

  • Page 3: General Description

    3230 CAMERA INSTALLATION MANUAL 1.0 GENERAL DESCRIPTION for the presssurization. Dry desiccant packs are placed inside the camera during during the sealing This introduction briefly describes overall process. characteristics of the Model 3230 Camera (figure An integral sun shield over the camera housing 1) related to its installation.
  • Page 4 INSTALLATION MANUAL 3230 CAMERA 323 x — x 0 0 0    xxxx SERIES Camera in IP67 Rated 3.5-inch Diameter Assigned Pressurized Housing VIDEO MOUNT FORMAT NONE (No Mount Provided) 3 NTSC PEDD (Pedestal Mount) POWER CEIL (Ceiling Mount) 7 PAL POLE (Pole Mount) 2 12 V dc MAST (Mast Mount) 4 24 V ac/dc HDWM (Heavy Duty Wall Mount)
  • Page 5 3230 CAMERA INSTALLATION MANUAL Table 1. Mounting Configurations ITEMS SUPPLIED MOUNT MOUNT 3230 PEDESTAL CEILING POLE MAST HEAVY DUTY DESIGNATION DESCRIPTION CAMERA MOUNT MOUNT MOUNT MOUNT WALL MOUNT • None Supplied NONE • • Pedestal Mount PEDD • • Ceiling Mount CEIL •...

  • Page 6: Cabling Requirements

    If any confusion exists it is best to contact the Coaxial cable must be 75 ohm RG-59/U and Customer Support department at Cohu or your local not have any iron used in the conductors. Belden Cohu representative. 8241F is a typical good coax.
  • Page 7 3230 CAMERA INSTALLATION MANUAL Camera Sunshield Dimensions Figure 5. Dimensions, Model 3230 Camera 6X-1086...

  • Page 8: Mounting Requirements

    CAUTION percent; Do not power the 24 V ac version of this camera directly from a Variac. It will blow up the power supply. (Available from Cohu as Part Number 3010100-001) sales@bb-elec.com POWER TYPICALLY www.bb-elec.com NOT REQUIRED 2.8 Mounting Requirements B &...

  • Page 9: Item Description

    ITEM DESCRIPTION CHARACTERIS- TICS ITEM DESCRIPTION CHARACTERIS- TICS Camera with sun- Model 3230 series shield Support Base See figure 5 Connector Kit 1310230-011 Power, RS-232 or RS- Cable 422, 75-ohm Coax Note: See figure 9 for the kit. This kit contains items to con-...
  • Page 10 INSTALLATION MANUAL 3230 CAMERA Table 5. 24 V ac/dc Pin Functions Table 4. 12 V dc Pin Functions FUNCTION FUNCTION Video Ground Video Ground 24 V ac High / +24 V dc no connection no connection no connection RS-232 Tx RS-232 Tx RS-232 Rx RS-232 Rx...

  • Page 11: Camera Setup

    Table 7. 18-pin Camera Connector & Table 6. 115 V ac Pin Functions Mating System Cable Plug FUNCTION CONNECTOR CAMERA MATING SYSTEM SOURCE CONNECTOR CABLE PLUG Video Ground Cohu P.N 1310230-017 1310230-011 no connection MS P.N. MS3111F-124-18P MS3116F-14-18S no connection Amp/Bendix P.N. PT01E-14-18P(SR) PT06E-14-18S(SR)

  • Page 12: Mast Mount

    INSTALLATION MANUAL 3230 CAMERA The hole pattern on the moveable head aligns with the threaded holes on the bottom of the camera. 4.2 Ceiling (CEIL) Mount (same as pedestal mount) The ceiling mount (figure 10) has a round plate for securing to the ceiling with four fasteners and a repositionable head at the bottom end to which the camera can be bolted for movement up/down and right/left.
  • Page 13 3230 CAMERA INSTALLATION MANUAL Connector (Plug) for the System Cable that Connects to Camera Connector Front Side - Mating Sockets Wiring Side - Solder Cups Kit as Typically Packaged Connector Kit Contents Figure 9. Type 1310230-011 System Cable 18-pin MS Type Connector Kit 6X-1086...

  • Page 14: Static Discharge Protection

    CAUTION following address: This 3230 contains sensitive devices that can be damaged by static discharge. Use appropriate static Cohu Electronics control methods when working inside the 3230. 3912 Calle Fortunada San Diego, CA 92123-1827 Components used in modern electronic equip-...
  • Page 15 3230 CAMERA INSTALLATION MANUAL Figure 10. Dimensions, PEDD and CEIL Mounts Figure 11. Dimensions, POLE Mount 6X-1086...
  • Page 16 INSTALLATION MANUAL 3230 CAMERA Figure 12. Dimensions, MAST Mount Figure 13. Dimensions, HDWM Mount 6X-1086...
  • Page 17 3230 CAMERA INSTALLATION MANUAL Table 8. System Interconnection Cable Characteristics FIGURE CABLE DATA VIDEO POWER DATA TYPE TYPE CONNECTION CONNECTION CONNECTION 12 V dc CA-253A stripped leads stripped leads stripped leads RS-232 CA-253B stripped leads D9 female CA-254A stripped leads stripped leads stripped leads CA-254B...
  • Page 18 INSTALLATION MANUAL 3230 CAMERA Figure 15. Type CA-253B System Interconnection Cable Figure 16. Type CA-254A System Interconnection Cable 6X-1086...
  • Page 19 3230 CAMERA INSTALLATION MANUAL Figure 17. Type CA-254B System Interconnection Cable Figure 18. Type CA-254M System Interconnection Cable 6X-1086...
  • Page 20 INSTALLATION MANUAL 3230 CAMERA Figure 19. Type CA-292A System Interconnection Cable Figure 20. Type CA-292B System Interconnection Cable 6X-1086...
  • Page 21 3230 CAMERA INSTALLATION MANUAL Figure 21. Type CA-293A System Interconnection Cable Figure 22. Type CA-293B System Interconnection Cable 6X-1086...
  • Page 22 INSTALLATION MANUAL 3230 CAMERA Figure 23. Type CA-293M System Interconnection Cable Figure 24. Type CA-295E System Interconnection Cable 6X-1086...
  • Page 23 3230 CAMERA INSTALLATION MANUAL Figure 25. Type CA-295F System Interconnection Cable Figure 26. Type CA-295G System Interconnection Cable 6X-1086...
  • Page 24 INSTALLATION MANUAL 3230 CAMERA Figure 27. Type CA-295M System Interconnection Cable Figure 28. Type CA-296A System Interconnection Cable 6X-1086...
  • Page 25 3230 CAMERA INSTALLATION MANUAL Figure 29. Type CA-296B System Interconnection Cable Figure 30. Type CA-296C System Interconnection Cable 6X-1086...
  • Page 26 INSTALLATION MANUAL 3230 CAMERA Table 9. Specifications CAMERA Image Sensor 1/4 inch Sony Super HAD Total Pixels NTSC: 811 X 508; PAL: 795 x 596 Resolution 480 tvl Sync Crystal Sensitivity 1.0 lux at 1/60 shutter (day / color mode (30 IRE) 0.2 lux at 1/60 shutter (night / mono mode) (30 IRE) 0.001 lux at 2 second /128 fields integration (night / mono mode (30 IRE) Video Output...

  • Page 27: Shipping Information

    3230 CAMERA INSTALLATION MANUAL Table 9. Specifications (continued) Mechanical Dimensions Weight 5 lb (2.7 kg) Camea Mount Five 1/4-20 threaded holes Connector 18 pin MS (PT-07C-14-18P) Mating plug included Electrical Input Voltage 12 V dc; or 24 V ac/dc; or 115 V ac Power 4 W (22 W heater on) Communications...
  • Page 28 All warranty repairs will be performed at the Cohu factory or as otherwise authorized by Cohu in writing. Purchaser shall prepay transportation charges to Cohu.
