INSTALLATION AND OPERATING INSTRUCTIONS
LEAVE THIS DOCUMENT WITH THE HOUSEHOLDER!
All Portway Stoves exceed the safety and performance requirements of European Standards
Intermittent burning solid fuel roomheaters for installation with a single dedicated chimney.
Nominal Heat
Output kW
Room Water
DeepWood
11.0
-
No2 *
DeepWood
14.8
-
No3
Read these instructions! Use only recommended fuels!
This document, when completed by the installer, constitutes part of a 'Hearth Notice' for purposes of
Building Law. It must be left with the householder and placed where it can easily be found.
INSTALLED AT LOCATION:
BY:
EMERGENCY CONTACT:
I definitively assert that this installation is safe, has been lit and demonstrated to the
householder, conforms with current building regulations and with these instructions
SIGNED:
PRODUCTION NUMBER
Portway DeepWood No2 and No3 stoves may be used in Smoky Fuel Ban areas of the Republic of Ireland when burning Wood logs
or peat briquettes, but not petroleum coke (Control of Atmospheric Pollution Regulations, 1970)
The Portway DeepWood No2 stove only may be used in smoke control areas of the United Kingdom when operated strictly in
accordance with these instructions and with Soliftec Smoke Advice Sheet No1 (www.soliftec.com/smokeadvice.htm) when burning
Flue
gas
Efficiency
Fuel
temp.
(Net) %
rise°C
CO %
Wood
76.3 339 0.1
Logs
Wood
74.4 339 0.1
Logs
untreated wood logs (Exempted from s20 of the Clean Air Act 1993)
SOLID FUEL HEATING STOVES
Emissions at nominal output
related to 13% O
2
Gas
Smoke NOx CxHy
Flow
mg/m³ mg/m³ mg/m³
g/sec
72 98 8.2 85
c130
- -
DATE:
TO FIND A QUALIFIED INSTALLER, FUEL SUPPLIER or CHIMNEY
UK: The Solid Fuel Association, 7 Swanwick Court, Alfreton, Derbyshire
DE55 7AS Tel:0845-601-4406 www.solidfuel.co.uk
RoI: Irish Nationwide Fireplace Organisation, 162 Capel Street, Dublin 1
Tel:01-801-5959 www.fireplace.ie
Trentham Lakes, Stoke on Trent, Staffordshire, England ST4 4TJ
www.bfm-europe.com Tel 01782 339000 Fax 01782 339009
1
Wood Fuel Stoves Manual v1. Issued - 04/02/2014 (25)
WOOD-BURNING MODELS
Tested to
Min. Safe
Standard or to
Distance to
Technical
Combustibles
Document
EN
400mm 13240:2001+
A2 2004
EN
- 400mm 13240:2001+
A2 2004
Flue Draught
measured on
commissioning:
Fuel used on
commissioning
SWEEP, CONTACT:
Tested when and
by (name and
number if a
notified body)
SGS Nederland
BV No0608
June 2013
EN13240 family
clause 9.2.2
Pa
WG
