Summary of Contents for Work Pro NEO S8 A
- Page 1 NEO S 8A 75 Hz 125 Hz User Manual / Manual de Uso Rev 5.0...
- Page 2 NEO S8 A is the perfect complement for the loudspeakers from the NEO S 8A. This self-powered subwoofer with balanced inputs can be used as an element of decoration in an installation. It can hung to walls vertically or horizontally...
-
Page 3: Specifications
Positioning THE NEO S8 A Subwoofer Your new subwoofer will work well in a variety of locations. However, placement in your listening room will affect its performance. Since the wavelengths of sound reproduced by your subwoofer are large compared to its size, those sounds are omni-directional in nature. -
Page 4: Connection Examples
Connection Examples 1. HI LEVEL input 5.1. channel system. NEO S8A as subwoofer front output reinforcement. The signal from FRONT speakers is driven inside subwoofer through HI LEVEL IN terminals. FRONT LEFT FRONT RIGHT 75 Hz 125 Hz FRONT CENTRE REAR REAR LEFT REAR RIGHT... - Page 5 NEO S8 A es el complemento perfecto para la gama de altavoces de la serie NEO. Este subwoofer autoamplificado con entradas balanceadas puede ser usado también como un elemento decorativo más. Su soporte trasero permite su colocación tanto en vertical como en horizontal...
- Page 6 Situando el subwoofer NEO S 8A Su nuevo subwoofer funcionará bien en una gran variedad de localizaciones. De todas formas, la ubicación dentro del recinto o sala afectará a su rendimiento. dado que la amplitud de onda del sonido reproducido por el subwoofer es mayor comparado con su tamaño, este sonido será...
- Page 7 Ejemplos de Conexionado 1. Entrada HI LEVEL Sistema 5.1.NEO S8A como subwoofer de refuerzo para la salida frontal. La señal proveniente de los altavoces FRONT es dirigida dentro del subwoofer a través de los terminales HI LEVEL. FRONT LEFT FRONT RIGHT 75 Hz 125 Hz FRONT...
- Page 8 This symbol on the product or on its packaging indicates that this product This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to shall not be treated as household waste.
