Proudly Distributed By
ROBAND AUSTRALIA PTY LTD
OPERATING INSTRUCTIONS
DOUBLE-SKINNED HOT WATER URNS
Models: UDS10VP, UDS20VP, UDS30VP
Version 1 Machines
Includes
International Models: ...-F, -UK, -M
These instructions cover the models of Robatherm Hot Water Urns listed above. Although there
are slight variances between them, the installation, care and maintenance procedure is the same
for all. The Operation Procedure differs slightly between the Fixed thermostat and Variable
Thermostat Versions.
19/11/2014
Advertisement
Table of Contents
Related Manuals for robatherm UDS10VP
Summary of Contents for robatherm UDS10VP
-
Page 1: Operating Instructions
Includes International Models: …-F, -UK, -M These instructions cover the models of Robatherm Hot Water Urns listed above. Although there are slight variances between them, the installation, care and maintenance procedure is the same for all. The Operation Procedure differs slightly between the Fixed thermostat and Variable Thermostat Versions. - Page 2 ® ® ®...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ..................... 1 GENERAL PRECAUTIONS ..................1 PACKAGING ......................2 COMPLIANCE ......................2 INSTALLATION ....................... 3 OPERATION......................4 BOIL DRY SAFETY PROTECTION ................. 6 GENERAL SAFETY ....................7 CLEANING, CARE & MAINTENANCE ..............8 TROUBLESHOOTING ..................... 9 SPECIFICATIONS ....................10 SPARE PARTS LIST ..................... -
Page 4: Introduction
INTRODUCTION Congratulations on your purchase of this quality Robatherm product. With proper care and management your new purchase will give you years of trouble free service. By reading these instructions carefully you can ensure that this machine is used and maintained properly, helping your new investment to perform well for you now, and to continue performing in the many years to come. -
Page 5: Packaging
Company and to the agent responsible for the dispatch of said unit within three (3) days of receipt. No claims will be accepted or entertained after this period. COMPLIANCE Robatherm products have been designed and manufactured to comply with any and all specifications set out by the Australian Communications and Media Authority (ACMA) in regards to Electromagnetic Compatibility. -
Page 6: Installation
INSTALLATION Place the urn on a solid, flat level surface with the tap facing the user. It is highly recommended to position the urn with the tap away from the edge of the bench in order that small children do not reach up and accidentally burn themselves. -
Page 7: Operation
OPERATION These Urns are primarily intended for heating clean pure water to a pre-set temperature & maintaining that temperature. The Urns allow easy dispensing of hot water into a cup for tea or coffee. If using liquids other than pure water, then daily cleaning is a requirement (see Cleaning). - Page 8 operator safety in lifting the machines, Urns should never be moved when more than ½ full. Never move the Urn whilst hot. Ensure the wall power outlet is on. Switch the urn on by pushing the Power switch to the “On” position (marked on the switch as “1”. The green pilot light will be illuminated, indicating that the machine is “On”...
-
Page 9: Boil Dry Safety Protection
Special Notes for using Variable mode: Set the Thermostat to the desired temperature setting using the dial indicator on the control knob. WARNING: If the control is set above 100°C then the urn will boil continuously until the setting is changed or until the water boils dry. We recommend only using settings above 100°C when maximum water temperatures are required and only for short periods. -
Page 10: General Safety
SAFETY GENERAL SAFETY This machine contains no user-serviceable parts. Roband Australia, one of our agents, or a similarly qualified person(s) should carry out any repairs. Any repair person(s) should be instructed to read the Safety warnings within this manual before commencing work on these units. -
Page 11: Cleaning, Care & Maintenance
CLEANING, CARE & MAINTENANCE Attention to regular care and maintenance will ensure long and trouble free operation of your Hot Water Urn. Although scheduled servicing is not required we do recommend you adopt a program of regular cleaning to ensure that the Urn remains functional. -
Page 12: Troubleshooting
TROUBLESHOOTING If the Urn is not heating then: Check that the machine is plugged into the power point correctly and the power is switched on. Check that the electrical circuit supplying the power point has not tripped. This could occur if: o The circuit breaker has tripped. -
Page 13: Specifications
SPECIFICATIONS Model UDS10VP UDS20VP UDS30VP Power Source 220-240 Volts AC / 50-60Hz Power Consumption 2300 Watts 2300 Watts 2300 Watts Nominal Volume 10 L 20 L 30 L Capacity (160ml Cup) 50 Cups 120 Cups 160 Cups Diameter 240 mm... -
Page 14: Spare Parts List
Pilot Light Amber TS0022 Boil Dry Cutout Assembly EC0407 ON-OFF Switch TS0023 Variable Thermostat & Knob EC0457 MODE Selection Switch MS0506 Tap Assembly PARTS FOR UDS10VP PARTS FOR UDS20VP Part Part Description Description Number Number MS0458 Sight Glass Assembly 10L MS0460... -
Page 15: Circuit Diagram
CIRCUIT DIAGRAM UDS10VP, UDS20VP, UDS30VP NOTE: This circuit diagram has been provided for reference and to assist qualified service and repair agents only. Under no circumstances should person’s not suitably qualified attempt repairs to any electrical equipment. Page: 12... - Page 16 NOTES Page: 13...
- Page 17 NOTES Page: 14...
-
Page 18: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Roband Australia 1 Inman Rd Manufacturer Cromer NSW, 2099 Australia Model Type Robatherm Double Skin Urns Description Water Urn Date first January 2013 Marking UDS10VP, UDS20VP, UDS30VP Specific Models Includes export model: -UK, -F, -M STANDARDS: This machine is designed in compliance with ... -
Page 19: Warranty
WARRANTY Every care is taken to ensure that no defective equipment leaves our factory and all goods manufactured by us are guaranteed against defective workmanship and materials for a period of 12 months from the date of purchase. Roband Australia’s obligations pursuant to this express warranty being limited to the repair or replacement of the defective goods or materials, at is option and subject to the terms contained within this Warranty statement. - Page 20 OTHER LEADING PRODUCTS AVAILABLE: -PLUS DRINK MIXERS PIE & FOOD WARMERS HIGH PERFORMANCE DEEP FRYERS VITAMIX BLENDERS NOAW Slicers GRILLMAX TOASTERS Manufactured/Imported in Australia by: Authorised Distributor/Agent...
