AstroJet 5000
Quick Start Guide
Step 1
Unpack Printer and Accessories
Place Printer on a stable surface.
Assemble: Adjustable Side Guide [1], Envelope/Media
Side Guide [2], Rear Media Support [3], Rear Media
Guide [4] and Exit Roller Guide Plate [5].
Save packaging material.
Step 2
Connect Power to Printer
1. Main power switch
[3] is turned OFF.
2. Plug power cord
from power adapter
into receptacle [4]
on rear of Printer.
Power Adapter
3. Plug AC power
cord into power
adapter. Plug
other end of
power cord into
115-220 Volt AC,
50/60 Hz
grounded outlet.
Using a surge
protector is
recommended.
DO NOT POWER UP PRINTER YET
Page 1
Connect Power Adapter
to Printer
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Astro Machine AstroJet 5000
Summary of Contents for Astro Machine AstroJet 5000
- Page 1 AstroJet 5000 Quick Start Guide Step 1 Unpack Printer and Accessories Step 2 Place Printer on a stable surface. Assemble: Adjustable Side Guide [1], Envelope/Media Connect Power to Printer Side Guide [2], Rear Media Support [3], Rear Media 1. Main power switch Guide [4] and Exit Roller Guide Plate [5].
- Page 2 NOTE: Refer to Section 3 – Operating the Step 3 AstroJet 5000 for information on how to align printheads when installing new cartridges. Install Inkjet Cartridges AJ-5000 uses two ink cartridges. (HP57 Color cartridge and HP56 or HP58 Black cartridge.) HP56 Black cartridge is for everyday printing and HP58 Black Cartridge is for photos and high quality printing.
- Page 3 Step 5 Load “AJ5000 AMC50 3. Window shown below appears, then “Hardware Printer Driver Disk” into Installation” window appears. computer's CD/DVD drive. Click Continue Anyway to load driver software from CD. If “Drive Installation CD” launch window appears, you can ignore it. DO NOT TURN PRINTER POWER ON YET USB Port Installation 1.
- Page 4 3. “Welcome to the Add Printer Wizard” window. 6. When “Found New Hardware Wizard” appears, click “Install the software Click Next>. automatically (Recommended)” button. Click Next>. 4. “Local or Network Printer” window. Click “Local printer attached to the computer” and 7.
- Page 5 12. Restart computer to complete installation. Step 6 630 Lively Blvd. To install Accessories and/or for Printer set-up or Elk Grove Village, IL 60007 operation, please refer to “AstroJet 5000 Shuttle Phone: (847) 364-6363 Printer Operator Manual” supplied with Printer. Fax: (847) 364 9898 www.astromachine.com ©...
