Summary of Contents for Zerotech MPC-0811 Series
- Page 1 User Manual MPC-0811 Series Thin Client Computer Preliminary Revision 1.0 July 1,2010 Zerotech Technology Inc.
- Page 2 1. Features Fan/Fan-less Design and 0.45-Liter Compact Sized VIA Eden/Nano Processor VX800U Chipset Support DDR2 533 SODIMM up to 2GB 9 COM + 6 USB + Touch controller (option) 8G SSD + Micro SD + 2.5” HDD space VGA + LAN + WIFI (option) 2.
-
Page 3: Product Specifications
3. Product Specifications MPC-0811 Type - 0 Construction Aluminum extrusion System Board Proprietary MB, VIA Eden/NanoProcessor + VX800U Memory DDR2 533 SO-DIMM up to 2GB I/O Panel Front I/O panel 1x Push button for power on/off 1x POWER LED 1x HDD LED 2x RS-232 1x USB2.0 Rear I/O panel... - Page 4 Product Specifications (continued) MPC-0811 Type – 1/2 Construction Aluminum extrusion System Board Proprietary MB, VIA Eden/NanoProcessor + VX800U Memory DDR2 533 SO-DIMM up to 2GB I/O Panel Front I/O panel 1x Phone Jack for Line-Out 1x Phone Jack for MIC-In 1x Push button for power on/off 1x POWER LED 1x HDD LED...
- Page 5 Eden 1GHz + VX800U 16 W Nano 1GHz + VX800U Nano 1.3GHz + VX800U 18 W Note: MPC-0811 series can support Eden 500M/1G, Nano 1G/1.3G p rocessor. However for thermal consideration, CPU grade with FAN combination should be confirmed by Zerotech technology.
-
Page 6: System Outlook
4. System outlook Refer to the diagrams below to identify the components of the system. Front Panel – MPC-0811 Basic model (Type 0) Note: Temporary picture Front Panel – MPC-0811 Basic model (Type 1/2) - Page 7 Rear Panel –MPC-0811 Basic model (Type 0) Note: Temporary picture Rear Panel –MPC-0811 Basic model (Type 1/2)
- Page 8 Front Panel – MPC-0811 Extension model (Type 0) Note: Temporary picture Front Panel – MPC-0811 Extension model (Type 1/2)
- Page 9 Rear Panel –MPC-0811 Extension model (Type 0) Note: Temporary picture Rear Panel –MPC-0811 Extension model (Type 1/2) Note: (1) Reserve “ON/OFF”, “Reset” connector inside can wire out to external switch through Expansion I/O slot (2) Extension RS-232 number are labeled on the cable connector.
- Page 10 5. Extension COM port definition I/O TYPE COM Port number TYPE 0/1 COM2, COM3, COM4, COM5, COM6, COM7, COM8, COM9, COM10 TYPE 2 COM3, COM7, COM8, COM9 Note: COM1 occupied by touch controller (option) COM3/COM7/COM8/COM9 Those DB-9 male connectors support RS-232 12V Level Signal DCD, Data carrier detect RXD, Receive data...
-
Page 11: Mechanical Dimensions
6. Mechanical Dimensions MPC-0811 type0 Dimensions in millimeters... - Page 12 Mechanical Dimensions – MPC-0811 type1/2 Dimensions in millimeters...
-
Page 13: Mounting Your Pc To A Monitor
7. Mounting your PC to a monitor VESA Mounting Kit Dimension... - Page 14 Install your DIN-Rail Mounting Kit DIN-Rail Mounting Kit Dimension...
- Page 15 8. AWARD BIOS Setting COM port Main Menu The BIOS Setup is accessed by pressing the “DEL” key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins. Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen.
- Page 16 Super IO Device Sub-Menu From this menu, Use the “UP”, “Down” cursor keys and “Enter” key to select COM port “ADDRESS” with IRQ number. The default value was setting as following picture.
