Gigabit Ethernet Adapter
User's Guide
Version 1.0
PN# 1907GA1200T6380
This User's Guide contains important information
regarding the installation of your adapter card. Please
read it completely before beginning installation.
For future reference, record the serial number
of your network adapter in the space below :
SERIAL number
The serial number is located on the face of the card.
Advertisement
Summary of Contents for Amer 1907GA1200T6380
- Page 1 Gigabit Ethernet Adapter User’s Guide Version 1.0 PN# 1907GA1200T6380 This User's Guide contains important information regarding the installation of your adapter card. Please read it completely before beginning installation. For future reference, record the serial number of your network adapter in the space below : SERIAL number The serial number is located on the face of the card.
- Page 2 Amer.com, as stipulated by the United States Copyright Act of 1976. Amer.com reserves the right to make changes to this document and the products which it describes without notice. Amer.com shall not be liable for technical or editorial errors or omissions made herein;...
- Page 3 This device complies with Part 15 of the FCC rules. Operation subject following conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 4 ．Reorient or relocate the receiving antenna. ．Increase the separation between the equipment and receiver. ．Connect the equipment into an outlet on a circuit different from that to which the receiver is connected to. ．Consult the dealer or an experienced radio/TV technician for help.
- Page 5 N T R O D U C T I O N Thank you for choosing the 10/100/1000Mbps Gigabit Ethernet Card for 32-bit PCI Bus-equipped personal computers. The 32-bit PCI 10/100/1000Mbps Gigabit Ethernet Card is ideal for speeding up data transfers for network servers and other computers, such as those used for video-conferencing, that send and/or receive large amounts of data.
-
Page 6: Gigabit Ethernet Technology
Supports IEEE802.1Q VLAN tagging Supports 10/100/1000Mbps Auto-negotiation operation Full Duplex support for 10/100/1000Mb/s data rates Auto MDI-II/MDI-X crossover for all three speeds Built-in FIFO (8K/64K) buffers reduces overhead of memory transfers 802.3x Full duplex flow control, including automatic transmission of Pause frames based on Rx FIFO thresholds Two LED indicators for easy diagnostic Gigabit Ethernet Technology... - Page 7 provides a straightforward upgrade without wasting a company’s existing investment in hardware, software, and trained personnel. The increased speed and extra bandwidth offered by Gigabit Ethernet is essential to coping with the network bottlenecks that frequently develop as computers and their busses get faster and more users use applications that generate more traffic.
- Page 8 Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks. A number of high-speed LAN technologies have been proposed to provide greater bandwidth and improve client/server response times. Among them, 100BASE-T (Fast Ethernet) provides a non-disruptive, smooth evolution from the current 10BASE-T technology.
- Page 9 N P A C K I N G A N D N S T A L L A T I O N This chapter provides unpacking and installation information for the 32-bit PCI 10/100/1000Mbps Gigabit Ethernet Card. Unpacking CAUTION: Under ordinary circumstances, the 32-bit PCI 10/100/1000Mbps NWay Gigabit Ethernet Card will not be affected by static charge as may be received through...
-
Page 10: Installing The Gigabit Ethernet Card
One 32-bit PCI 10/100/1000Mbps Gigabit Ethernet Card. One Driver Diskette This User’s Guide. If any item is found missing or damaged, please contact your local reseller for replacement. Installing the Gigabit Ethernet Card 1. Shut down the computer, unplugs its power cord, and remove the chassis cover. - Page 11 5. Switch computer power on. If the BIOS section of your computer’s boot program is Plug-and-Play compliant, then at power-up the BIOS will automatically configure any newly installed the Gigabit Ethernet Card. NOTE: Due to a fault in some Plug-n-Play BIOS programs, it happens occasionally that a newly installed adapter is assigned an Interrupt Number which is already assigned to another...
-
Page 12: Software Installation
Software Installation Before you connect the 32-bit PCI 10/100/1000Mbps Gigabit Ethernet Card to the network, you have to install the network driver first. The driver for each networking operating system is under a separate directory. A HELPME.COM file under root directory lists the information and detailed installation procedure of all the available drivers. - Page 13 L ED I N D I C A T O R S Two LED indicators: Link, Activity. Link Indicator This indicator lights green when the Gigabit Card is connects to 10/100/1000Mbps Gigabit Ethernet Network. Activity Indicator (ACT) This indicator blinking green will be transmitting or received data on the network.
- Page 14 E C H N I C A L P E C I F I C A T I O N S General Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3x Flow Control Protocol CSMA/CD Ethernet: 10Mbps (half), 20Mbps (full)
- Page 15 Amer.com Warranty Policy Limited Lifetime Warranty In the event of a defect in quality or workmanship, Amer.com will repair or replace any hardware product sold Amer.com with reconditioned parts free of charge in North America for a limited lifetime period unless otherwise specified on the sales invoice from the date of original purchase.
- Page 16 Adapters & Fans, after the 1 year a cost for replacement is applied to all products requiring such parts. Amer.com is not responsible for any type of data loss on hard drive or other storage devices. Warranty Service can be obtained during the warranty period by shipping, freight prepaid, or delivering the product to Amer.com in either the...
- Page 17 Limits and Expectations There are no express warranties except as listed above. Network products by Amer.com shall not be liable for incidental or consequential damages resulting from the use of this product. Any future upgrades, including (but not limited to) hardware and software are not covered by this limited warranty.
