AETOOL BSA-12 User Manual

BATTERY & STARTER ANALYSER (BSA-12)

Introduction

BSA-12 Battery Starter Analyser does not carry internal batteries but is powered up from external DC
source ranging from 9V to 15V DC. It is meant for operating on 12V flooded lead acid, sealed lead
acid, and VRLA, Gel or AGM batteries. No maintenance is required during its lifetime service. Testing
Operation is quick (less than 7 sec) and does not create sparks when clipped on or drain the battery
during the test.

Specifications:

Operating Voltage:
Analysing Capacity (Amps):
DC Volts Accuracy:
Battery analysing time:
Working Temperature:
Working Humidity:

Safety precautions:

•
When the engine is running, it produces carbon monoxide, a toxic and poisonous gas. Always
operate the vehicle in a well ventilated area. Do not breathe exhaust gases – they are
hazardous that can lead to death.
•
To protect your eyes from propellant object such as caustic liquids, always wear safety eye
protection.
•
Fuel and battery vapors are highly flammable. DO NOT SMOKE NEAR THE VEHICLE DURING
TESTING.
User Manual
9V ~ 15V DC (max)
CCA: 100 ~ 1700A
IEC: 100 ~ 1000A
JIS#: 100 ~ 1700A
CA: 100 ~ 1700A
± 2% Reading
Less than 7 seconds.
0ºC ~ 50ºC.
10 ~ 80 %
EN: 100 ~ 1700A
DIN: 100 ~ 1000A
SAE: 100 ~ 1700A
