Safety information

For the Safety information, visit the Web site www.yotadevices.com/safety/.

Overview of the router

1. LED indicator status (Illustration #1):
Lit in blue: the router is connected to LTE network and transmitting data
(LED will turn off automatically when device is not transmitting to save
power)
Lit in orange: the router is connected to GSM or UMTS network and
transmitting data (LED will turn off automatically when device is not
transmitting to safe power)
2. Swivel USB-connector for connecting the router to the USB-port of the
computer or charging (Illustration #2)
3. MicroUSB-connector for connecting the router to the PC using the USB-
cable. (Illustration #3)
4. MicroSIM-cards slot. (Illustration #4)
10/80
