Touch-Screen User Manual
© 2011 Fisker Automotive, Inc.
All rights reserved. Information contained in this document is based on the latest information available at the time of printing and
is subject to the copyright and other intellectual property rights of Fisker Automotive, Inc. (Fisker), its affiliated companies and its
licensors. All rights are reserved to make changes at any time without notice. No part of this document may be reproduced, stored
in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
nor may these materials be modified or reposted to other sites, without the prior expressed written permission of the publisher.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Karma and is the answer not in the manual?

Questions and answers

Related Manuals for Fisker Karma

Summary of Contents for Fisker Karma

  • Page 1 All rights reserved. Information contained in this document is based on the latest information available at the time of printing and is subject to the copyright and other intellectual property rights of Fisker Automotive, Inc. (Fisker), its affiliated companies and its licensors.

  • Page 3: Table Of Contents

    Touch-Screen User Manual Introduction..........2 Using the Touch-Screen ......3 Climate Control ........... 6 Audio............7 Phone ............16 Navigation ..........20 System ............23 Document Number: C1810ASD0043.01 (July 2011) ©2011 Fisker Automotive, Inc. All rights reserved.

  • Page 4: Introduction

    Because the controls and features that are accessed improvement is a constant goal at Fisker through the touch-screen. Automotive, we reserve the right to make changes at any time, without notice and The information is divided into sections.

  • Page 5: Using The Touch-Screen

    Using the Touch-Screen OVERVIEW Using the Touch-Screen 1. Compass 10. Volume 2. Current operating mode 11. Left-hand front heated seat 3. Secondary time zone 12. Windshield defogger 4. Primary time zone 13. Rear window heater 5. Climate 14. Electronic Stability Control (ESC) 6.
  • Page 6 Using the Touch-Screen Using the Touch-Screen USING THE TOUCH-SCREEN To activate a feature, touch its respective icon with your finger. Ensure that only one WARNING: Only operate, adjust or finger at a time is in contact with the screen, view the touch-screen when it is safe to prevent incorrect entries.
  • Page 7 Using the Touch-Screen The following pages explain in detail how to use all of the touch-screen features except the Climate Control system. For detailed information on the Climate control system, please refer to the “Owner’s Manual”. Note: For your convenience, you can change between the touch-screen features using the voice command system.

  • Page 8: Climate Control

    Climate Control Climate Control CLIMATE CONTROL Climate Control 1. Temperature/blower speed adjustment 7. Blower speed Touch and drag the indicators to Touch to adjust blower speed increase or decrease the setting. 8. Air conditioning 2. Interior temperature zone settings Touch to switch on/off air conditioning 3.

  • Page 9: Audio

    Audio TUNER Audio 1. Tuner 11. Presets 2. Satellite radio 12. Choose preset bank 3. USB connected audio device Three banks each with six presets. 4. Bluetooth connected audio device 13. Auto store 5. Auxiliary input device 14. Scan button 6.
  • Page 10 Audio Audio AM/FM TUNER Manually storing stations To manually store a radio station, Touch the TUNER icon to access the search for the station using the seek AM/FM tuner. (up or down) icons. Auto storing stations When the desired station is found, The tuner has two wavebands;...
  • Page 11 Audio AUDIO SETTINGS Adjusting the sound settings The following sound settings can be Adjusting the volume adjusted: Touch the AUDIO SETTINGS button • Bass on the touch-screen to access the • Treble audio settings. • Fader To adjust the volume of the audio system, •...
  • Page 12 Audio Audio TUNER SETTINGS Touch the TUNER SETTINGS button on the touch-screen to access the tuner settings. Set the RDS option to ON or OFF as required. Radio Data System (RDS) is a system which allows digital data to be sent to radio receivers at the same time as the FM audio signal.

  • Page 13: Satellite Radio

    Audio SATELLITE RADIO Presets A total of eighteen preset stations are Satellite radio is a direct broadcast radio available in three banks of six. To service, which provides digitally encoded change between the banks of preset audio signals. The signals can be received stations, touch the bank icon.
  • Page 14 Audio Audio Direct channel input Parental lock To select a channel by entering the Select a channel, either using the catergory channel number, touch the channel menu or the direct channel input. icon. To lock the channel, press the LOCK button and enter the parental lock code.
  • Page 15 Audio USB MODE You can connect an auxiliary device and a USB device simultaneously to the audio system and switch between them using the touch-screen. The device docked first will remain the active device until you choose to change. If, after changing to the newly-docked device, you change back to the first device, play will resume at the point you left it.
  • Page 16 Audio Audio 1. Track information Touch the first track in the playlist, to commence play. When the selected song is 2. Browser finished, the media player will play the next 3. Next/previous track track on the album that the song was taken 4.
  • Page 17 Audio BLUETOOTH AUXILIARY MODE You can connect a portable media player or mobile phone with bluetooth capability to the vehicle’s audio system, see the phone section for further information. Ensure that a device is paired to the vehicle and touch the BT AUDIO button on the touch-screen.

  • Page 18: Phone

    (AVRCP) 1.0; • Phone Book Access Profile (PBAP) Touch the CONNECT icon. 1.0. Ensure your Bluetooth enabled Note: Please see your Fisker Retailer for phone is in search mode. more information on compatible Touch the ADD PHONE icon. phones. Select Fisker_Karma displayed Note: Your Service Provider and/or among the devices on your phone.
  • Page 19 Phone CALLING A CONTACT USING THE DIALLING A NUMBER ADDRESS BOOK To initiate a call to a number not contained in the address book: Select the PHONE menu. Select the PHONE menu. The PHONE menu can also be accessed from the switch on the steering wheel. The PHONE menu can also be accessed from the switch on the steering wheel.
  • Page 20 Phone Phone REDIALLING A NUMBER CALL HISTORY To redial the last dialled number: To view the call history: Select the PHONE menu. Select the PHONE menu. The PHONE menu can also be accessed The PHONE menu can also be accessed from the switch on the steering wheel.
  • Page 21 Phone RECEIVING A CALL To answer a call, touch the CALL icon on the touch-screen. To hang up the call, touch the call end icon on the touch-screen or touch the phone switch on the steering wheel. UNPAIRING A PHONE Press CONNECT button to see the list of devices paired to the touch-screen.

  • Page 22: Navigation

    Navigation Navigation NAVIGATION Navigation WARNING: Only operate, adjust or view the system when it is safe to do so. If necessary, stop the vehicle to check current location and/or make any navigation adjustments. WARNING: The requirements of national Road Traffic Regulations always apply.
  • Page 23 Navigation Touch the confirm icon to calculate your To cancel the current navigation, touch the route. Your route is displayed. MENU icon and select STOP ROUTE GUIDE. Your route is cancelled. Touch the confirm icon again to begin navigating to the selected destination. Route settings •...
  • Page 24 Navigation Navigation Points of interest (POI) search There are 9 special destination categories available each containing a list of POIs. The special destination catergories are: • Car and driving • Emergency • Financial • Hotel and catering • Public facilities •...

  • Page 25: System

    System Traffic Message Channel You will be informed of a traffic event as follows: Traffic Message Channel (TMC) is a feature that announces traffic delays in the nearby • A TMC icon shown on the map at the area and along your route. It uses radio location of the event.
  • Page 26 System System DIAGNOSTICS Fault detected If a fault with the vehicle is detected during driving, the following screen will be displayed: Touch the CLOSE button to close the window. If no faults are detected, or all faults have been rectified, the touch-screen will display the following screen.
  • Page 27 System SOLAR ROOF ENERGY Touch the SOLR ENRG icon to access the solar energy screen. Your vehicle is equipped with a solar paneled roof. The solar roof not only helps to recharge the battery but also aids the cabin climate control system. The solar roof is capable of generating a half kilowatt-hour a day and is estimated to provide up to 200 miles (321km) of...
  • Page 28 System System ENERGY FLOW INFORMATION Touch the ENERGY FLOW INFORMATION icon to show the energy consumption and generation.
  • Page 29 System SETTINGS A number of the vehicle settings can be configured to you personal preferences. To access the vehicle settings: Touch the SYSTEM icon on the touch-screen. Touch the SETTINGS icon to access the vehicle settings area. Use the up (or down) arrows to change the currently displayed settings to required setting.
  • Page 30 System System Settings overview EXTERIOR AUTO FOLD Automatic folding/unfolding of the exterior mirrors when the vehicle is locked/unlocked with the key fob. ON, OFF DOOR AUTO LOCK Automatic locking of the vehicle doors: LOCK OUT OF PARK, AT 5 MPH REMOTE LOCK Confirmation when the vehicle is locked using the key fob: PARK LAMPS AND HORN, PARK LAMPS...
  • Page 31 System INTERIOR DIMMING Control the illumination level of the instruments, touch-screen and switches. PARADE, 00 - 09 EASY ENTRY/EXIT Automatic movement of the driver’s seat and steering wheel to provide easier access into and out of the vehicle. ENABLE, DISABLE GLOBAL RESET Clear all user defined settings and revert back to the factory defaults.
  • Page 32 System System TIME TIME ZONE Specify the time zone for your Primary (1) REGION and Secondary (2) locality. LANGUAGE Specify the language that you want the vehicle to use for information on the touch-screen and instrument cluster. Changing the language setting will also change the voice-recognition settings.
