Time Machine Boost
Thank you and congratulations on your decision to
purchase the LegendaryTones Time Machine
Boost®. This unique two-channel tri-mode booster
for guitar enables you to obtain a wide range of
boosted sounds to help inspire you to play or c
your music. From its two select vintage booster
tones inspired by those made famous in the 1960s
and 1970s, to its modern, ultra-transparent clean
boost, the Time Machine Boost aims to satisfy
even the most discriminating players.
Built as a no-compromise design, the Time
Machine Boost features a completely hand-wired
circuit with top grade components that are
optimized for the best tone possible as well as low
noise.
Your complete satisfaction is our goal. If you have any questions or comments, please contact us at
tmb@legendarytones.com.
The Team: The Time Machine Boost was born out of an initial vision and desire for this type of product by
Legendary Tones (www.legendarytones.com) president David Szabados. By partnering with Robert
Keeley, president of Keeley Electronics (www.robertkeeley.com), the two worked together on the various
aspects of the design where each person's talents were best suited. Every element from inside the finely
detailed and crafted point-to-point layout, to the exterior design and layout, was carefully planned and
executed over the course of a year. This collaborative project between Szabados and Keeley is what
ultimately became the Time Machine Boost. Joining Szabados and Keeley for production TMB's is
technician and builder Tom Lindenstruth. Tom's attention to detail, perfection, and quality inspection and
assembly goes into every TMB built. The partnership between Szabados and Keeley and the fine work of
Lindenstruth have created something that can be called more than just a success and future collaborations
are planned. But with that said...
Thanks are in order! Many ears and eyes helped the team with the creation of the Time Machine Boost –
it's always good to get an outside perspective especially when valid criticisms surface as they often lead to
breakthroughs and even better ideas! So with that thanks are in order to the following people for their
insight and input: Gary Holladay, Yamini Huigoil, Tiffany Keeley, Victor Mason, Steve McCampbell,
Mike Mullen, Jack Orman, Scott Smith, Alicia Szabados and Anna Szabados.

Basic Unit Features

Two independent channels of operation (Vintage and Modern) with three modes of boosts
("1966", "1973", and "Modern") and separate level controls per each of the Time Machine
Boost's two independent channels
Intensity control for Vintage channel to control harmonic level and shape tone
True bypass with individual LED indicators for On/Off, Vintage, and Modern channel selection
LegendaryTones
®
2004 Model – User Guide
www.timemachineboost.com
reate

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LegendaryTones and is the answer not in the manual?

Questions and answers

Summary of Contents for Time Machine Boost LegendaryTones

  • Page 1 Your complete satisfaction is our goal. If you have any questions or comments, please contact us at tmb@legendarytones.com. The Team: The Time Machine Boost was born out of an initial vision and desire for this type of product by Legendary Tones (www.legendarytones.com) president David Szabados. By partnering with Robert Keeley, president of Keeley Electronics (www.robertkeeley.com), the two worked together on the various...
  • Page 2 1973 – Custom modified treble boost effect with more enhanced mids as well as fuller bottom end 9v DC input –The 2004 model Time Machine Boost operates from a standard 9v battery or 9-9.6v DC and may be used with standard power supplies and with multi-effect systems that utilize a positive sleeve connection.
  • Page 3 The Time Machine Boost may also be used for a wide range of other purposes such as a clean preamp to strengthen the tone and body of guitars that use lower output pickups. It can be used creatively to alternate between its two boost modes using different level settings for each channel so you can use it for unique rhythm and lead tone applications.
  • Page 4 Your complete satisfaction is our goal as is our desire for you to have a lifetime of enjoyable musical use with your Time Machine Boost. As a result, The Time Machine Boost itself is covered by a limited Lifetime warranty to the original owner. This includes a lifetime of assurance that the craftsmanship and non-mechanical components will be covered free of charge in the event of a component failure.
