Sanyo VHR-810 Service Manual

FILE NO.
-
SERVICE MANUAL
Video Cassette Recorder
L
CONTENTS
SELF-DIAGNOSIS DISPMY .................................................... 2
1. Disassembly ....................................................................5
2. Electrical ADJusTMENT ..............................................9
3. TEST POINTS FOR TAPE PATH ADJUSTMENT .............12
4. PARTS LIST
Accessories .................................................................. 13
L
PACKING MATERIALS ...................................................... 13
CABINET & CHASSIS PARTS ........................................... 13
MECHANISM PARTS ......................................................... 14
ELECTRICAL PARTS ........................................................ 16
CIRCUIT DIAGRAMS (Refer to the separate volume)
Sqkmiiio
VHR-810
(Product Code :143173 40)
VHR-830
(Product Code :143173 45)
(Australia)
(New Zealand)
Please see other materials with Reference
number given in table below.
Manual
V95 II
Mechanism
MS531 500
I
~
'RODucT 'AFEW 'OT'cE
The components designated by a symbol (~) in this schematic diagram designates components whose value are of special
significance to product safety. Should any component designated by a symbol need to be replaced, use only the part designated
in the parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
NOTE:. 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N.S.P. : Not available as service parts.
F'
,.
.,
Design and specifications are subject to change without notice.
L
AP2NIA, AP2LNIA
REFERENCE No.SM531666
