Summary of Contents for SmartLine AKG2
- Page 1 Smartline Gas cooking appliance Table-top unit AKG2 Built-in unit BKG2 Installation and Operating Instructions SALVIS AG Nordstrasse 15 CH-4665 Oftringen www.salvis.ch...
- Page 2 2 / 13...
- Page 3 Dear customer, Before you operate the gas cooking appliance, please read the Installation and Operating Instructions carefully. These instructions contain important information about proper installation and operation. Any documents supplied with the appliance should always be kept readily available and should be handed on with the appliance.
-
Page 4: Table Of Contents
CONTENTS Hints on operational safety....................5 Daily operation ......................5 Risk of injury ......................5 Fire hazard....................... 5 Risk of damage ......................5 Connection, changeover, maintenance ..............5 Swiss regulations..................... 6 Setting up, connection......................7 Setting up......................... 7 Gas connection ......................7 Commissioning........................ -
Page 5: Hints On Operational Safety
Hints on operational safety Daily operation The appliance must only be operated - by trained staff, - under supervision, - for the purpose specified in the operating instructions. - Outdoors the appliance may only be operated under a cover and with adequate wind protection! Keep the appliance dry! - Do not use the appliance for storage purposes! - Do not use cookware that covers the whole surface! -
Page 6: Swiss Regulations
Safety clearances specified by t manufacturer between inflammable material (fire protection distance): The built-in unit may only be installed in a CNS cover. Table-top unit AKG2 Built-in unit BKG2 Key for safety distance: - to rear panel... -
Page 7: Setting Up, Connection
Setting up, connection During transport by hand: Be aware of the weight of the appliance and wear safety gloves! The relevant local regulations must be followed. The installations must be carried out according to the installation instructions of manufacturer and the generally accepted state of the art. -
Page 8: Commissioning
Commissioning The appliance must be connected properly to ensure proper operation. Setting up and connection see section 2. Before commissioning clean the appliance with a fat-dissolving cleaning agent. Dry cleaned parts and surfaces with a soft cloth. Cleaning see section 5. Establishing readiness for operation Check the correct position of the burner and pilot burner covers. -
Page 9: Notes Regarding Operation
Notes regarding operation Any spillage or boiled over food residue should be removed from the gas cooker immediately! Caution - hot surfaces! The gas cooker is equipped with a thermoelectric safety pilot. If the pilot flame goes out the safety pilot automatically interrupts the gas supply, thereby preventing gas from escaping. The gas cooker is equipped with different burner output levels. -
Page 10: Daily Cleaning
Daily cleaning Push in the gas control knob, turn to Off position (symbol ) and close the gas tap provided by the customer gas tap (main shut-off device). Leave the gas cooker to cool down. - Remove the sliding grate and the burner covers Sliding grate and clean them with fat-dissolving cleaning agents Burner cover... -
Page 11: Technical Data
Technical data Technical data Gas cooker with 2 burners Gas appliance type Rated heat load (total) 8.5 kW Connected load, liquid gas 0.66 kg/h Connected load, natural gas 0.9 m Gas connection diameter T 1/2" (external thread) Cookers 1 x 3.5 kW; 1 x 5 kW Control range Large / small flame External dimensions (W x D x H) -
Page 12: Changeover To Other Gas Type
Changeover to other gas type Please follow the operational safety instructions, see section 1. The gas cooker factory-set to natural gas H. Only use original nozzles for changeover to other gas types. After changeover to another gas type and after maintenance work check all gas-carrying parts for leaks (leak spray). -
Page 13: Replacing The External Nozzle
Replacing the external nozzle Unscrew the set screw until the connecting Set screw piece can be removed. Remove the connecting piece. Replacing the external nozzle, see table in section 8.1. Fully push in the connecting piece and lock with a set screw. Connecting Check all gas-carrying parts for leaks. - Page 16 SALVIS AG Nordstrasse 15 CH-4665 Oftringen Phone +41 62 788 1818 +41 62 788 1895 www.salvis.ch info@salvis.ch...
