NIGHT STORAGE HEATERS
SH6M
SH9M/ A
SH12M / A
SH15M / A
SH18M / A
SH24M / A
Please read these instructions before installing or using this appliance for the first time.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SH6M and is the answer not in the manual?

Questions and answers

Summary of Contents for Mathius SH6M

  • Page 1 NIGHT STORAGE HEATERS SH6M SH9M/ A SH12M / A SH15M / A SH18M / A SH24M / A INSTALLATION INSTRUCTIONS AND USER GUIDE Please read these instructions before installing or using this appliance for the first time.
  • Page 2 The input control operates a highly sensitive thermostat which regulates the amount of heat stored. The discharge is by convection heat which can be partially controlled by use of the output control. Please note that Type SH6M is fully automatic with no output control.
  • Page 3: Installation Instructions

    2.- INSTALLATION INSTRUCTIONS 1.- Chose the right place to install the heater. It is necessary that a minimum clearance of 50 cm is allowed to ensure the best heating resu lts. Always maintain a minimum clearance of 50 cm from the heater to any combustible materials such as furniture and curtains. 2.- Open the carton at the indicated side and fix the feet without removing the heater casing (fig 1).
  • Page 4 The stored heat will be delivered to the room by both radiant and convected methods. The convected heat can be regulated by using the output control (OUTPUT) This control governs the continuous flow of convected heat from the outlet grill. Type SH6M is completely automatic and has no output control.
  • Page 5: Wiring Diagram

    WIRING DIAGRAM R1, R2, R3, R4 Main heating elements WIRING SH6M SH12M/A SH18M/A SH24M/A 850W 850W 850W 850W Accelerating Resistance 850W 850W 850W Control thermostat Safety 850W 850W Earth 850W Live Neutral...
  • Page 6 El símbolo en el producto indica que el mismo no se debe cubrir. The symbol on the product indicates that this appliance should not be covered. O simbolo no producto indica que este aparelho nâo se deve cobrir. El símbolo en el producto o en su embalaje indica que este producto no se puede tratar como desperdicio normales del hogar. Este producto se debe entregar al punto de recolección de equipos eléctricos y electrónicos para reciclaje.
