Summary of Contents for OMEZ LIGHTING TitanPar 3W-Par64
- Page 1 OMEZ LIGHTING TitanPar™ 36*3w par64 Item #104 User Instructions OMEZ Group Inc 11301 IRIS LN, #B EL MONTE, CA 91731 www.omezlighting.com...
- Page 2 3W-Par64 Specifications Model: 3W-Par64 SPECIFICATIONS: LED’s: 36 LED’s (12 Red, 12 Green, 12 Blue) Working Position: Any safe working position Current Voltage: AC 90V-240V/60Hz Wattage: 108W Power Draw: 0.2 Amps Weight: 10lbs Dimensions: 12.2” (L) x 9” (W) x 9” (H) Packing Size: 13”...
- Page 3 Set Up Before plugging your unit in, be sure the source voltage in your area matches the required voltage for your OMEZ 3W-Par64. The OMEZ 3W-Par64 is available in a 120v and 220v version. Because line voltage may vary from venue to venue, you should be sure your unit voltages match the wall outlet voltage before attempting to operate you fixture.
- Page 4 Operation 1. Display： A．Function B．UP C．DOWN E．LED DISPLAY Instructions: Press the function key A will activate the cycle of eight different functional effects. In the digital display, the first two digits represent the current function (see menu). The last two digits represent the functions' Address Code. For speed specification. Press B or C key to change its value.
- Page 5 3．DMX512 channels: function Detail function R 、 G 、 B dimming from dark to bright Total dimming Total strobe R、G、B strobe from slow to quick 0 - 50 DMX 7ch control ； 51- 100 jump change ； Function selection 151-200 Gradient, variable pulse; 201—255 ：...
