CONNECTIONS

The box is connected with 3 cables

12V DC - Power supply - 230Volt adapter

HDMI cable that connects to your TV into an available HDMI input

WAN - Network cable that connects to your broadband connection / router / Internet connection

Turn on the TV

Use your remote control for your TV to switch to the entrance where you installed the HDMI cable. This is usually

done via AV / Source / Input button on your TV remote.

Remember that there may be multiple HDMI inputs on your TV. Please take note of the number of the input

you are using (HDMI1 - HDMI2 etc.)

FIG. Correct when in use (2 green lights)

Turn on the BOXTV receiver with the small switch is on the right side of the receiver - here lights should react as

follows:

On the TV screen: LOADING PLEASE WAIT while the three lights on the front panel act as follows:

RED (flashing)

GREEN

RED

Then, the upper light flashes GREEN / RED for approx. 20 seconds.

Table of Contents

Do you have a question about the M55 and is the answer not in the manual?

Page 1 CONNECTIONS The box is connected with 3 cables 12V DC - Power supply - 230Volt adapter HDMI cable that connects to your TV into an available HDMI input WAN - Network cable that connects to your broadband connection / router / Internet connection Turn on the TV Use your remote control for your TV to switch to the entrance where you installed the HDMI cable.
Page 2 GREEN/RED GREEN Now the two top ligths are GREEN: Correct status GREEN GREEN When the box is turned OFF via remote control, the lights act as follows: RED (stable) GREEN (stable) MAIN MENU Now use the remote to the BOXTV receiver. Use the arrows to move from 1) Video (TV Channels) 2) Radio (Radio Channels) 3) Setup •...
Page 3 PLAY-PAUSE, stops the broadcast for at while and resumes playback § By default the receiver has built-in 5-minute memory § PAUSE is also used if your broadband connection for a short period does not send enough data. Here the PAUSE feature is used to shortly enable a little more "buffer" DISPLAY removes the menu from the screen and returns to TV / Radio STANDBY is the red button in the top right corner VOLUME (UP/DOWN arrow keys) controls the sound that BOXTV senda to your TV.
