DX8200 Controller
Reference Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX8200 and is the answer not in the manual?

Questions and answers

Related Manuals for Datalogic DX8200

Summary of Contents for Datalogic DX8200

  • Page 1 DX8200 Controller Reference Manual...
  • Page 3 DX8200 Controller INSTALLATION MANUAL...
  • Page 4 ALL RIGHTS RESERVED Datalogic reserves the right to make modifications or improvements without prior notification. Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

  • Page 5: Table Of Contents

    CONTENTS GUIDE TO INSTALLATION..................v GENERAL VIEW .......................vi SAFETY PRECAUTIONS ..................viii Electrical Safety ......................viii Laser Safety......................viii Power Supply......................ix GENERAL FEATURES ....................1 Introduction .........................1 1.1.1 Indicators ........................3 Model Description .......................3 Accessories ........................3 Applications ........................4 INSTALLATION......................5 Package Contents.......................5 Mechanical Installation....................6 Electrical Connections....................7 2.3.1 Power Supply......................7 2.3.2 Ethernet ........................8 2.3.3 Host Interface ......................8...
  • Page 6 GLOSSARY......................41 INDEX........................44...

  • Page 7: Guide To Installation

    4.4. 3. Make electrical connections to your DX8200 Controller by: correctly wiring the DX8200 Controller to the Host using one of the desired Host interfaces: Ethernet, Main or Aux Serial port communication, see par. 2.3.2 and 2.3.3.

  • Page 8: General View

    GENERAL VIEW DX8200 Controller Figure A - DX8200 Controller General View Control Panel (see Figure B) Laser Warning Label Product Label Mounting Rails Laser Output Windows...
  • Page 9 Figure B – Control Panel Host Interface Connector Presence Sensor LED (N.A.) Reserved Connector Encoder LED Ethernet connector Good Read LED RS232 Debug Connector TX Data LED Lonworks Network Connector Network LED Power ON LED VAC Power Panel (for VAC models only) Fuses, Power Switch, Power Connector,...

  • Page 10: Safety Precautions

    LASER SAFETY The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of the DX8200 Controller scanner. Standard Regulations This scanner utilizes up to 3 low-power laser diodes. Although staring directly at the laser beam momentarily causes no known biological damage, avoid staring at the beam as one would with any very strong light source, such as the sun.

  • Page 11: Power Supply

    20 and 30 VDC, supplied to the Lonworks Network connector, for DX8200 Controller-X0X0 models between 85 and 264 VAC, supplied through the VAC power cable, for DX8200 Controller-X0X1 models. A security system allows the laser to activate only once the motor has reached the correct rotational speed;...

  • Page 13: General Features

    In particular, DX8200 Controller serves as both the Master of the cluster and Controller of the Lonworks bus network where up to 13 scanners can be present to make up the reading station. The major advantage is in eliminating the need for an external Lonworks Controller.
  • Page 14 FLEXIBILITY The high frequency laser diode modulation system guarantees complete immunity to ambient light and allows installation of the DX8200 Controller in any working area. The DX8200 Controller is easily configurable by means of the Windows-based user-friendly Genius utility program provided on CD-ROM.

  • Page 15: Indicators

    (green) Indicates data transmission both on the main and on the auxiliary TX Data: interface. (red) Indicates data transmission on the Lonworks network. Network: 1.2 MODEL DESCRIPTION The DX8200 Controller scanner is available in versions that differ depending on: • number of lasers • optical resolution •...

  • Page 16: Applications

    DX8200 CONTROLLER 1.4 APPLICATIONS The DX8200 Controller barcode reader is specifically designed for industrial applications and for all cases requiring high reading performance such as: • code reconstruction • reading of codes covered by plastic film • reading of codes with a wide depth of field •...

  • Page 17: Installation

    INSTALLATION 2 INSTALLATION 2.1 PACKAGE CONTENTS Verify that the DX8200 Controller and all the parts supplied with the equipment are present and intact when opening the packaging; the list of parts includes: • DX8200 Controller • Installation Manual + barcode test chart •...

  • Page 18: Mechanical Installation

    DX8200 CONTROLLER 2.2 MECHANICAL INSTALLATION DX8200 Controller can be installed to operate in any position. There are 2 mounting rails on the sides of the scanner for installation. The diagram below gives all the information required for installation; refer to par. 4.4 for correct positioning of the scanner with respect to the code passage zone.

  • Page 19: Electrical Connections

    For VDC models, the PWR power supplies (optional), supply the power necessary for the entire network of DX8200 Controller and relative Slaves and allows main power to be used. For VAC models the main AC power connects directly to the DX8200 Controller to power the entire network.

  • Page 20: Ethernet

    DX8200 CONTROLLER 2.3.2 Ethernet RJ45 Modular Connector HUB / SWITCH DX8200 Controller n. c. n. c. n. c. RJ45 Modular Connector n. c. n. c. = not connected 2.3.3 Host Interface 25-pin male D-sub Connector Host Interface Connector Pinout Name...

  • Page 21: Main Interface

    The RTS and CTS signals control data transmission and synchronize the connected devices. If the RTS/CTS hardware protocol is enabled, the DX8200 Controller activates the RTS output to indicate a message can be transmitted. The receiving unit must activate the CTS input to enable the transmission.
  • Page 22 RS485 Full-Duplex Interface Connections RS485 Half-Duplex Interface The RS485 half-duplex interface can be used for multidrop connections with a Datalogic multiplexer or it can also be used for a master/slave layout. The following pins of the 25-pin connector are used for RS485 half-duplex interface...
  • Page 23 INSTALLATION 20 mA Current Loop (INT-60 Accessory Only) When the INT-60 accessory board is installed, the DX8200 Controller is equipped with a 20 mA current loop interface. The INT-60 board supports both active and passive type connections. Active Connections The following pins of the 25-pin output connector are used for the active connections:...

  • Page 24: Auxiliary Interface

    DX8200 CONTROLLER Auxiliary Interface The auxiliary serial interface is equipped with RS232 full-duplex interface connections. The interface type is exclusive and is selectable through the Genius™ configuration program. The following pins of the 25-pin connector are used for RS232 full-duplex interface...

  • Page 25: Rs232 Debug

    5 ms or 500 µs. The electrical features of the inputs are: Maximum voltage 30 V Maximum current 10 mA Input NPN Polarity Insensitive Common Reference DX8200 Controller EXTERNAL TRIGGER/ ENCODER Vext DX8200 Controller EXTERNAL DEVICE + 5V Vext...

  • Page 26: Outputs

    DX8200 CONTROLLER Input PNP Connections Polarity Insensitive Common Reference DX8200 Controller EXTERNAL TRIGGER/ Vext ENCODER Vext DX8200 Controller EXTERNAL DEVICE + 5V IN3A + 5V DX8200 Controller EXTERNAL TRIGGER/ Vext Vext ENCODER IN4A + 5V + 5V INREF 2.3.7 Outputs...

  • Page 27: Layouts

    ** Presence Sensor connected to External Trigger Input The maximum number of scanners on the Lonworks cluster is 6 (1 DX8200 controller + 5 slaves). Positive environmental conditions (i.e reduced number of barcodes, conveyor speed, reading area dimensions…) to be evaluated case by case, may...

  • Page 28: Software Configuration

    After installing the Genius™ software program (see par. 3.1) the following window appears asking the user to choose the desired configuration level: Genius™ Wizard Opening Window For the DX8200 Controller the Wizard is not available and if selected a warning message appears indicating that Advanced Mode will be used.

  • Page 29: Advanced Genius™ Configuration

    SOFTWARE CONFIGURATION 3.3 ADVANCED GENIUS™ CONFIGURATION The ADVANCED selection available when starting the Genius™ program is addressed to expert users being able to complete a detailed scanner configuration. By choosing this option it is possible either to start a new scanner configuration or to open and modify an old one. The desired parameters can be defined in the following window, similar to the MS Explorer: Genius™...

  • Page 30: Parameter Default Values

    DX8200 CONTROLLER 3.4 PARAMETER DEFAULT VALUES The following table contains the list of the factory default settings for the DX8200 Controller. Genius™ also allows checking the parameter default values by selecting the "Compare parameters" option available in the Tools menu and comparing the current scanner configuration to the default one.
  • Page 31 SOFTWARE CONFIGURATION Parameter Default Setting Data Communication Settings Host Application Protocol Type Standard Data Format Termination After No Read Message Enabled Parameters Header String <STX> Code Identifier Disabled Termination String <CR><LF> Data Packet Separators <CR><LF> Code Field Length Setting Variable Length Main Serial Port Data Tx Enabled (checked)
  • Page 32 DX8200 CONTROLLER Parameter Default Setting Output 1 Line State Normally Open Activation Event Complete Read Alternative Activation Event Multiple Read Deactivation Event Timeout Alternative Deactivation Event None Deactivation Timeout (ms) Output 2 Line State Normally Open Activation Event No Read...

  • Page 33: Reading Features

    With just a set of partial scans on the label (obtained using the motion of the label itself), the DX8200 Controller is able to "reconstruct" the barcode. A typical set of partial scans is shown below.

  • Page 34: Packtrack

    DX8200 CONTROLLER 4.2 PACKTRACK™ PackTrack™ is a patented operating mode for DATALOGIC Omnidirectional Reading Stations used to read and correctly assign codes read on parcels when placed in the scanner Reading Area at the same time. In fact, in the example below, the codes of two or more consecutive parcels are found at the same time in the scanner reading area.

  • Page 35: Performance

    ANSI Grade B minimum The following tables describe the requirements for standard applications. Please contact Datalogic for specific advice on maximizing the reading performance possibilities to obtain the best possible performance for your application. Minimum Code Height for Omnidirectional Reading (mm) Conveyor Speed (m/s) 0.25...
  • Page 36 DX8200 CONTROLLER Minimum Code Height for Omnidirectional Reading (mm) Conveyor Speed (m/s) 0.25 0.30 Codabar 0.33 Code Resolution 0.38 (mm) 0.50 0.60 1.00 Table 4 Minimum Code Height for Omnidirectional Reading (mm) Conveyor Speed (m/s) 0.25 0.30 EAN 8-13, UPC-A 0.33...

  • Page 37: Reading Diagrams

    READING FEATURES 4.4 READING DIAGRAMS Single Configuration DX8200 Controller 201X 0.25 mm codes Ref. Dimensions given in mm 1100 Reading Area CONVEYOR PLANE Reading diagram for double-diode high resolution model...
  • Page 38 DX8200 CONTROLLER Single Configuration DX8200 Controller 200X 0.30 mm codes Ref. Dimensions given in mm 1300 Reading Area CONVEYOR PLANE Reading diagram for double-diode standard resolution model...
  • Page 39 READING FEATURES Single Configuration DX8200 Controller 200X 0.50 mm codes Ref. Dimensions given in mm 1500 Reading Area CONVEYOR PLANE Reading diagram for double-diode standard resolution model...
  • Page 40 DX8200 CONTROLLER Single Configuration DX8200 Controller 301X 0.25 mm codes Ref. Dimensions given in mm 1100 Reading Area CONVEYOR PLANE Reading diagram for triple-diode high resolution model...
  • Page 41 READING FEATURES Single Configuration DX8200 Controller 300X 0.30 mm codes Ref. Dimensions given in mm 1400 Reading Area CONVEYOR PLANE Reading diagram for triple-diode standard resolution model...
  • Page 42 DX8200 CONTROLLER Single Configuration DX8200 Controller 300X 0.50 mm codes Ref. Dimensions given in mm 1500 1000 Reading Area CONVEYOR PLANE Reading diagram for triple-diode standard resolution model...
  • Page 43 READING FEATURES Side-by-Side Configuration DX8200 Controller 201X 0.25 mm codes 1140 Ref. Dimensions given in mm 1100 Reading Area CONVEYOR PLANE Reading diagram for side-by-side double-diode high resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.
  • Page 44 DX8200 CONTROLLER Side-by-Side Configuration DX8200 Controller 200X 0.30 mm codes 1240 Ref. Dimensions given in mm 1300 1200 Reading Area CONVEYOR PLANE Reading diagram for side-by-side double-diode standard resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.
  • Page 45 READING FEATURES Side-by-Side Configuration DX8200 Controller 200X 0.50 mm codes 1240 Ref. Dimensions given in mm 1500 1200 1000 Reading Area CONVEYOR PLANE Reading diagram for side-by-side double-diode standard resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.
  • Page 46 DX8200 CONTROLLER Side-by-Side Configuration DX8200 Controller 301X 0.25 mm codes Ref. 1140 Dimensions given in mm 1100 Reading Area CONVEYOR PLANE Reading diagram for side-by-side triple-diode high resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.
  • Page 47 READING FEATURES Side-by-Side Configuration DX8200 Controller 300X 0.30 mm codes 1240 Ref. Dimensions given in mm 1400 1200 1000 Reading Area CONVEYOR PLANE Reading diagram for side-by-side triple-diode standard resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.
  • Page 48 DX8200 CONTROLLER Side-by-Side Configuration DX8200 Controller 300X 0.50 mm codes 1040 Ref. Dimensions given in mm 1200 1500 1000 1000 Reading Area CONVEYOR PLANE Reading diagram for side-by-side triple-diode standard resolution model Side-by-side configurations are shown with the minimum overlap. You should adapt the distance between the scanners and therefore the field width according to your application.

  • Page 49: Maintenance

    Repeat the operation frequently in particularly dirty environments. Use soft material and alcohol to clean the windows and avoid any abrasive substances. Clean the windows of the DX8200 Controller when the scanner is turned off or at least when the laser beam is not active.

  • Page 50: Replacing The Protection Fuses (For Ac Models)

    5.3 REPLACING THE PROTECTION FUSES (FOR AC MODELS) The device must be opened by qualified personnel only. WARNING Before removing the fuses from DX8200 Controller, make sure the power supply cable is disconnected to avoid shock or harm to the operator. WARNING Two protection fuses are located next to the on/off switch (Figure B, 12).

  • Page 51: Technical Features

    TECHNICAL FEATURES 6 TECHNICAL FEATURES DX8200 Controller ELECTRICAL FEATURES (see note 1) Models X0X1 Models X0X0 Input voltage 85-264 VAC 20 to 30 VDC Current consumption (max.) 0.4 ~ 0.2 A 1.5 ~ 1.0 A Communication interfaces Baud rate Lonworks network...
  • Page 52 DX8200 CONTROLLER DX8200 Controller SOFTWARE FEATURES READABLE CODE SYMBOLOGIES Interleaved 2/5 Code 128/EAN 128 Code 39 standard EAN/UPC Codabar Code 93 (standard & Full ASCII) Up to 10 code symbologies during one reading phase Code Selection Headers and Terminators Transmitted messages can be personalized using up to 128 headers and 128 terminators PackTrack™...
  • Page 53 Term used on the required CDRH warning labels to describe the laser exit window. ASTRA™ Automatically Switched Reading Area™ is a Datalogic technology based on a multi-laser architecture and a fixed mounted optic system which concentrates the multiple laser emissions in a single laser beam. As each laser emitter is focused on a specific range of the reading area, a sophisticated electronic controller selects the best focused laser emitter with respect to the code to read.
  • Page 54 See RS485. PackTrack™ PackTrack™ is a Datalogic patented parcel tracking system which improves the reading features in omnidirectional stations. In particular, PackTrack™ manages 6-sided reading systems when it is impossible to detect the real position of the code on the parcel, thus overcoming the need for external accessories essential in traditional tracking systems.
  • Page 55 Serial Port An I/O port used to connect a scanner to your computer, identifiable by a 9-pin or 25-pin connector. Signal An impulse or fluctuating electrical quantity (i.e.: a voltage or current) the variations of which represent changes in information. Symbol A combination of characters including start/stop and checksum characters, as required, that form a complete scannable barcode.
  • Page 56 INDEX Accessories; 3 Maintenance; 37 Advanced Code Reconstruction; 21 Mechanical Dimensions; 6 Model Description; 3 Electrical Connections; 7 Host Interface; 8 Outputs; 14 Power Supply; 7 Package Contents; 5 Fuse Replacement; 38 PackTrack™; 22 Parameter Explorer Window; 17 Parameter Groups Default Values;...
