SLOW JUICER

FRESHER & PURER THAN EVER BEFORE

I N STRU CTI ON M AN UA L

Table of Contents

Need help?

Do you have a question about the UNO SLOW JUICER and is the answer not in the manual?

Questions and answers

Summary of Contents for Juico UNO SLOW JUICER

Page 1 SLOW JUICER FRESHER & PURER THAN EVER BEFORE I N STRU CTI ON M AN UA L...
Page 2 Please ensure the current, voltage and frequency are in accordance with the standard of your country. This Juico Uno Slow Juicer design and workings are subject to change without warning due to continual product development. 02 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 3 08-09 Parts and Accessories 10-11 Assembly Instructions 12-15 Cleaning your Juico Uno 16-17 Directions for Use 18-19 Food Preparation and Juicing Techniques Self Clean 20-21 Cleaning and Maintaining your Juicer 22-23 Troubleshooting Specifications JUICO UNO SLOW JUICER INSTRUCTION MANUAL 03...
Page 4: Self-Cleaning
Years of experience, months of design and testing, Greenis has teamed up with some of the world’s most reputable slow-juicer manufacturers to launch the revolutionary Juico Uno Slow Juicer. With its world-leading all-in-one juicing system and 35 RPM,Juico Uno will bring you remarkable juicing experience.
Page 5: Safety Cautions
To avoid injury and damage, never disassemble the machine during use. Do not block the pulp outlet while the unit is operating. Use both hands when moving or lifting the unit,it weighs around 4 KG. Keep out of reach of children. JUICO UNO SLOW JUICER INSTRUCTION MANUAL 05...
Page 6 Do not operate the unit without fruit or vegetables for more than a few seconds,some parts can become damaged due to lack of lubrication. Clean the product thoroughly after use. 06 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 7 JUICO UNO CUSTOMER MESSAGE Juico Uno is dedicated to providing 100% natural nutrition to our customers through our high quality kitchen appliances. With the Juico Uno Slow Juicer you can enjoy a variety of nutrient rich juice along with these benefits.
Page 8: Parts And Accessories
FRESHER & PURER THAN EVER BEFORE PARTS AND ACCESSORIES HOPPER SAFETY PULP JUICE PITCHER PITCHER SQUEEZING SCREW JUICING SCREEN 08 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 9 FRESHER & PURER THAN EVER BEFORE PARTS AND ACCESSORIES CLEANING JUICING BRUSH BOWL PUSHER / TAMPER PULP OUTLET MAIN BODY JUICE OUTLET JUICO UNO SLOW JUICER INSTRUCTION MANUAL 09...
Page 10: Product Assembly
FRESHER & PURER THAN EVER BEFORE PRODUCT ASSEMBLY Engage the juicing bowl Before usage, place the silicone onto the Motor Base. stopper into the pulp outlet as shown below. 10 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 11 Make sure “unlock sign” on the hopper aligns with “white dot” on the juicing bowl. Turn the hopper clockwise until it fully engages into the juicing bowl. JUICO UNO SLOW JUICER INSTRUCTION MANUAL 11...
Page 12 For less frequent use, thorough cleaning might not need to take place as frequently. In order to get optimum lifespan from the UNO juicing screen, close inspection is recommended on a regular basis. 12 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 13 Remove the auger /screw from Juico Turn the auger / screw up side down UNO and have the spanner ready Remove each of the two rubber Remove each of the two rubber grommets grommets JUICO UNO SLOW JUICER INSTRUCTION MANUAL 13...
Page 14 Remove each of the two rubber Take the spanner and line it up with grommets the grey screw inside the auger Place the spanner inside the grey Turn Anti-clockwise until you here a screw “CLICK” 14 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 15 Lift the grey screw out of the auger Hold the auger at the screw end Pull the juicing screen away from the screw REASSEMBLY OF UNO AUGER / SCREW Repeat steps 1 to 11 in reverse JUICO UNO SLOW JUICER INSTRUCTION MANUAL 15...
Page 16: Directions For Use
“REV” means reverse operation. Use button when something is stuck. It will remove the clogged material. If Juico UNO is not juicing correctly, try following the next steps. Turn off the machine Run the product in “REV” mode for a few seconds.
Page 17: Precautions For Use
Drink juices as soon as possible after juicing, if you wish to store juice place it in a sealed glass container in the refrigerator. Juicing too much food or juicing hard food stuffs may make it difficult to remove the hopper from the juicing bowl. JUICO UNO SLOW JUICER INSTRUCTION MANUAL 17...
Page 18 Remove any hard seeds from fruits or vegetables. Otherwise, severe product damage especially on the screw. Do not insert too much ingredients / do not feed ingredients too fast. Otherwise, severe product damage may occur. 18 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 19 When juicing grasses, feed the Juico Uno a small amount of grass at a time, cutting the grass into short pieces approx 3cm long ensures the waste can easily come out of the waste chute.
Page 20: Cleaning And Maintaining Your Juicer
Switch on the juicer and pour a bowl of clean water slowly into the feed tube. Turn on juicing tap drain water after juicing bowl is clean. NB: Please disassemble fully after juicing is complete and follow the cleaning instructions found in this manual. 20 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 21: Cleaning Tips
Doing so will be more hygienic as potentially otherwise bacteria may develop inside the the squeezing screw. Use the spanner above to fit into the “nut button” and twist unclose to release the squeezing screw. JUICO UNO SLOW JUICER INSTRUCTION MANUAL 21...
Page 22: Troubleshooting
Please ensure that the food is prepared correctly. Separation of juice Please note that some ingredients have diff erent density and you may note a slight separation during juicing. Simply stir and enjoy. 22 JUICO UNO SLOW JUICER INSTRUCTION MANUAL...
Page 23: Product Specifications
PMDC Planetary Gearbox Motor 35 RPM Product weight App. 4.8 Kg (undeﬁ ned as packaging not ready) Dimensions 15.5cm(W)*15.5cm(L)*43.5cm(H) Working sound volume 30-45 decibels Standard usage time No more than 30 minutes continuously JUICO UNO SLOW JUICER INSTRUCTION MANUAL 23...
