BenQ FP72E User Manual

BenQ FP72E User Manual

Lcd color monitor 17.0" lcd panel size
Hide thumbs Also See for FP72E:
Table of Contents

Advertisement

Quick Links

FP72E/T721
LCD Color Monitor
17.0" LCD Panel Size
User's Manual
Welcome
Downloaded from ManualMonitor.com Manuals

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FP72E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BenQ FP72E

Summary of Contents for BenQ FP72E

  • Page 1 FP72E/T721 LCD Color Monitor 17.0" LCD Panel Size User’s Manual Welcome Downloaded from ManualMonitor.com Manuals...

  • Page 2: Power Safety

    Copyright Copyright © 2006 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation.

  • Page 3: Table Of Contents

    How to detach the stand base ...................11 How to use the monitor wall mounting kit .............12 Getting the most from your BenQ monitor ..............14 How to install the monitor on a new computer ............15 How to upgrade the monitor on an existing computer ..........16 How to install on Windows XP system ..............17...
  • Page 4 Table of Contents Downloaded from ManualMonitor.com Manuals...

  • Page 5: Getting Started

    Getting started When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. BenQ LCD Monitor Quick Start Guide CD-ROM Power Cord Signal Cable: D-Sub Signal Cable: DVI-D (optional) Getting started Downloaded from ManualMonitor.com Manuals...
  • Page 6 Audio Cable Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor. The fitted foam packing is ideal for protecting the monitor during transport. Getting started Downloaded from ManualMonitor.com Manuals...

  • Page 7: Getting To Know Your Monitor

    Getting to know your monitor Front view Earphone socket Back view 1. Audio cable socket 2. AC power input jack 3. DVI-D input socket 4. D-Sub input socket Getting to know your monitor Downloaded from ManualMonitor.com Manuals...

  • Page 8: How To Assemble Your Monitor Hardware

    How to assemble your monitor hardware If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. 1. Attach the monitor base. Please be careful to prevent damage to the monitor. Placing the screen surface on an object like a stapler or a mouse will crack the glass or damage the LCD substrate voiding your warranty.
  • Page 9 2. Connect the PC video cable. Either Do not use both DVI-D cable and D-Sub cable on the same PC. The only case in which both cables can be used is if they are connected to two different PCs with appropriate video systems. Connect one end of the DVI-D cable to the monitor DVI-D socket and the other end to the DVI-D port on your computer.
  • Page 10 Turn on the monitor by pressing the power button on the front of the monitor. Turn on the computer too, and follow the instructions in Section 4: Getting the most from your BenQ monitor to install the monitor software. on page 14 How to assemble your monitor hardware...

  • Page 11: How To Detach The Stand Base

    How to detach the stand base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. Turn off the computer before unplugging the monitor signal cable. Please be careful to prevent damage to the monitor. Placing the screen surface on an object like a stapler or a mouse will crack the glass or damage the LCD substrate voiding your warranty.

  • Page 12: How To Use The Monitor Wall Mounting Kit

    How to use the monitor wall mounting kit The back of your LCD monitor has a VESA standard mount with 100mm pattern, allowing the installation of a wall mount bracket. Before starting to install a monitor wall mounting kit, please read the precautions carefully.
  • Page 13 3. Remove the rear cover. Slide the rear cover back toward you to remove it. The screw plate at the back of the monitor could be revealed. 4. Follow the instruction manuals of the wall mount bracket you purchased to complete the installation. How to assemble your monitor hardware Downloaded from ManualMonitor.com Manuals...

  • Page 14: Getting The Most From Your Benq Monitor

    Getting the most from your BenQ monitor To gain the most benefit from your new BenQ color LCD flat screen monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM. The circumstances under which you connect and install your BenQ LCD Monitor will determine which process you need to follow to successfully install the BenQ LCD Monitor driver software.

  • Page 15: How To Install The Monitor On A New Computer

    BenQ LCD Monitor is the first ever monitor to be connected to it. If you are adding the BenQ LCD Monitor to an existing computer that has already had another monitor connected to it (and has monitor driver software installed), you should not be following these instructions.

  • Page 16: How To Upgrade The Monitor On An Existing Computer

    The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems.

  • Page 17: How To Install On Windows Xp System

    The Monitor Properties window will display. If the driver provider is listed as BenQ, and the model matches that of your new monitor, the proper drivers are already installed, and you need do nothing further. Cancel out of these property windows.

  • Page 18: How To Install On Windows 2000 System

    4. In Windows 2000, click the Driver tab and the Update Driver button. The Upgrade Device Driver Wizard will display. How to complete the Windows Upgrade Device Driver Wizard on page Getting the most from your BenQ monitor Downloaded from ManualMonitor.com Manuals...

  • Page 19: How To Complete The Windows Upgrade Device Driver Wizard

    The contents of the ‘Driver’ folder will display. 7. Click the Open button. This will return you to the Install from Disk window, and it will have entered the address to the BenQ LCD Monitor CD ‘Driver’ folder into the field titled ‘Copy manufacturer’s files from:’ .
  • Page 20 This will close the Display Properties window, and if you made any changes to the screen resolution, Windows 2000 will prompt you for confirmation to effect the changes, and further confirmation to accept the changes. Click OK and Yes respectively. Getting the most from your BenQ monitor Downloaded from ManualMonitor.com Manuals...

  • Page 21: How To Adjust The Screen Resolution

    Due to the nature of liquid crystal display (LCD) technology, the picture resolution is always fixed. The best possible picture for your FP72E/T721 is achieved with a resolution of 1280 x 1024. This is called “Native Resolution” or maximal resolution – that is, the clearest picture. Lower resolutions are displayed on a full screen through an interpolation circuit.

  • Page 22: How To Adjust The Screen Refresh Rate

    How to adjust the screen refresh rate You don’t have to choose the highest possible refresh rate on an LCD display, because it is not technically possible for an LCD display to flicker. The best results are obtained by using the factory modes already set in your computer.

  • Page 23: Picture Optimization

    If you wish, you can always adjust the screen geometric settings manually using geometry menu items. To assist you in this endeavour, BenQ has provided a screen test image utility which you can use to check for screen color, grayscale and line gradient display.

  • Page 24: How To Adjust Your Monitor

    How to adjust your monitor The control panel 1. “ key”: Adjust vertical position, phase, horizontal position and pixel clock automatically. 2. “MENU” key: Activate OSD main menu and return to the previous menu or exit OSD. (Left) key: For Left/Decrease adjustment. Left key is the hot key for Contrast. (Right) key: For Right/Increase adjustment.

  • Page 25: On Screen Display (Osd) Menu Structure

    On Screen Display (OSD) menu structure Auto Adjustment DISPLAY H. Position V. Position Pixel Clock Phase PICTURE Brightness Normal Green Contrast Bluish Blue Sharpness Reddish Color User Mode Reset Color Volume AUDIO Mute English French German Italian Spanish SYSTEM Input D-sub Polish/Japanese Czech/Traditional...

  • Page 26: Hot Key Mode

    Hot key mode The monitor keys perform as hotkeys to provide direct access to particular functions whenever the menu isn't currently displaying on-screen. Brightness hot key Press the key to display the Brightness indicator. Further press the key to increase or the key to decrease the screen brightness, and press the MENU key to exit.

  • Page 27: Main Menu Mode

    Main menu mode You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor. Press the MENU key to display the following main OSD menu. There are four main OSD menus: 1. Display 2. Picture 3.
  • Page 28 Display menu 1. Press the MENU key to display the main menu. 2. Press the keys to select DISPLAY and then press the ENTER key to enter the menu. 3. Press the keys to move the high- light to a menu item and then press the ENTER key to select that item.
  • Page 29 H. Position Adjusts the horizontal 0 to 100 position of the screen image. V. Position Adjusts the vertical 0 to 100 position of the screen image. Pixel Clock Adjusts the pixel clock 0 to 100 frequency timing to synchronize with the analog input video signal.
  • Page 30 Picture menu 1. Press the MENU key to display the main menu. 2. Press the keys to select PICTURE and then press the ENTER key to enter the menu. 3. Press the keys to move the high- light to a menu item and then press the ENTER key to select that item.
  • Page 31 User Mode Tailors the image color • Red Press the keys and (0 to 100) tint. The blend of the Red, the ENTER key to select Green and Blue primary Red, Green, or Blue. Then • Green colors can be altered to (0 to 100) use the keys to...
  • Page 32 Audio menu 1. Press the MENU key to display the main menu. 2. Press the keys to select AUDIO and then press the ENTER key to enter the menu. 3. Press the keys to move the high- light to a menu item and then press the ENTER key to select that item.
  • Page 33 System menu 1. Press the MENU key to display the main menu. 2. Press the keys to select SYSTEM and then press the ENTER key to enter the menu. 3. Press the keys to move the high- light to a menu item and then press the ENTER key to select that item.
  • Page 34 H. Position Adjusts the horizontal 0 to 100 position of the OSD menu. V. Position Adjusts the vertical 0 to 100 position of the OSD menu. Display Time Adjusts the display time of • 5 sec. Press the keys to the OSD menu.

  • Page 35: Troubleshooting

    Troubleshooting Frequently asked questions (FAQ) The image is blurred: Read the How to adjust the screen resolution on page 21 section, and then select the correct resolution, refresh rate and make adjustments based on these instructions. How do you use a VGA extension cable? Remove the extension cable for the test.

  • Page 36: Need More Help

    Need more help? If your problems remain after checking this manual, please contact your place of purchase or e-mail us at: Support@BenQ.com Troubleshooting Downloaded from ManualMonitor.com Manuals...

  • Page 37: Supported Pc Timings

    Supported PC Timings Incoming display mode (Input timing) Resolution Horizontal Vertical Pixel Comment Frequency (KHz) Frequency (Hz) Frequency (MHz) 640x350 31.47(P) 70.08(N) 25.17 720x400 31.47(N) 70.08(P) 28.32 640x480 31.47(N) 60.00(N) 25.18 640x480 35.00(N) 67.00(N) 30.24 Macintosh 640x480 37.86(N) 72.80(N) 31.50 VESA 640x480 37.50(N)

  • Page 38: Specifications

    Specifications Model FP72E/T721 Display type 17.0”, active, TFT Viewable diagonal 432 mm Native (maximum) resolution 1,280 x 1,024 Colors 16.2 million Contrast / Brightness 500:1 / 300 cd/m Response time 8 ms Viewing angle (left/right, up/down) 140, 130 (CR=10) 160, 160 (CR=5)
  • Page 39 Operating voltage Automatic switched mode power supply, 90-264 V, 47-63 Hz Dimensions (H x W x D) 369 x 371.6 x 151.3 mm Weight 3.9 kg Specifications Downloaded from ManualMonitor.com Manuals...
