Quirky R-INS-TAPT-WH02 Installation Instructions

PANTONE
115 C
PART # : R-INS-TAPT-WH02
SPEC : 100gsm bright white C2S, Matte UV
FLAT DIMS : 220 x 336 mm
FINISHING : Z-fold both ways
Tapt was invented by Michael Taylor,
a business analyst from Canton, GA.
An energy-conscious dad of three,
Michael was constantly following
his kids around to make sure they
turned off lights, TVs, and ceiling fans.
He came up with Tapt so he could
manage his household at a glance.
INVENTED BY
Michael Taylor
These days, you're likely to find
Michael practicing taekwondo,
+2020 INFLUENCERS
running a Spartan race, or listening
to Weird Al Yankovic.
IN THE BOX IMPORTANT SAFETY INFORMATION
• Wall switch assembly kit with pre-stripped, • Read all instructions and warnings prior to
stranded wires (green, red, white, and black), using Tapt. Failure to comply with instructions
and 4 wire connectors (for wires up to and warnings constitutes improper use of Tapt.
12 gauge) Save all instructions.
• Faceplate (hides visible screws) • Quirky, Inc. not responsible for improper
use, which may result in personal injury or
• Snap plate (pre-attached)
product damage.
• User guide
• Not a toy. Keep away from children.
Note: The included faceplate and snap plate • WARNING: RISK OF ELECTRIC SHOCK
are intended for single gang box installations OR FIRE. Before installing, servicing, or
only. If installing in a double gang box, use a removing Tapt, TURN OFF POWER AT THE
double gang wall plate (not included) without CIRCUIT BREAKER THAT CONTROLS THE
the faceplate and snap plate. SWITCH. After power has been turned off,
make sure the light switch you are going to
replace with Tapt is powered down before
WHAT YOU'LL NEED continuing installation. It is recommended to
use a circuit tester to make sure the circuit
• A Wink HUB or ZigBee-enabled, Wink-
is off. Exercise extreme caution when using
certified hub (sold separately)
devices controlled via Tapt.
• Apple® or Android™ smart device (tablets
• This device is intended for installation and
and desktops not supported)
use in accordance with the National Electric
• The Wink app downloaded to your mobile Code (NEC) and local regulations in the United
device from the iTunes® App Store or Google States, or the Canadian Electrical Code (CEC)
and local regulations in Canada. If you are
Play™. If you already have the Wink app
unsure or uncomfortable about performing
installed, please download the latest version
to ensure you have the most updated support. this installation, consult a qualified electrician.
• Tapt is a single pole switch and a neutral
• A Wi-Fi® network connection with a router
using WPA-PSK security. WEP security is connection is required.
not supported. Please refer to your router's
• Tapt is not compatible with a 3-way light switch.
manual for instructions on converting your
router to WPA security. • NOT FOR USE WITH MEDICAL OR LIFE
SUPPORT EQUIPMENT. App-enabled
• Slotted screwdriver and Phillips head
devices should never be used to supply power
screwdriver
to or control the On/Off status
of medical and/or life support equipment.
• Do not use to control electric heaters or
any other appliances which may present a
hazardous condition due to unattended or
unintentional or automatic power on control.
• 120VAC. Must not exceed 600 watts
(Incandescent); 15 Amps, 1800W (Resistive);
or 1⁄2 HP (Motor). The maximum rating for
entire switch is 1800W (15A) Resistive.
• There are no user-serviceable parts.
• Only use this device with copper or copper-
clad wires.
TAPT
SMART
SWITCH
• Switches can be used to turn standard
or smart bulbs on or off
• Programmable features within the Wink app
allow switches to dim smart bulbs
• Tapt can trigger other smart products with
one touch (e.g., Push one of its buttons when
you wake up to open all of your smart blinds,
adjust the smart thermostat to a desired
temperature, and turn on smart light bulbs)
• Switches allow you to schedule standard
bulbs to turn on/off
COMPLIANCE Quirky will refund or replace, at its option, any defective
product free of charge.
This device complies with Part 15 of the FCC Rules.
In order to qualify for this warranty, the Purchaser must
Operation is subject to the following two conditions:
provide the defective product and a copy of the original
(1) this device may not cause harmful interference, and
receipt of purchase to Quirky for inspection. The receipt of
(2) this device must accept any interference received,
purchase must indicate the product purchased, price paid,
including interference that may cause undesired
date of purchase, and name of merchant.
operation.
To request service under this warranty, contact Quirky at
Changes or modifications not expressly approved by the
866-5-QUIRKY or questions@quirky.com and a Quirky
party responsible for compliance could void the user's
representative will provide instruction on how to proceed.
authority to operate the equipment.
This warranty shall be null and void if Quirky determines
NOTE: This equipment has been tested and found
that the product has been improperly installed, altered
to comply with the limits for a Class B digital device,
or tampered with in any way. This warranty does not
pursuant to Part 15 of the FCC Rules. These limits are
protect against normal use, wear and tear, or damage due
designed to provide reasonable protection against
to abuse.
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
THIS WARRANTY CONTAINS THE SOLE WARRANTY
frequency energy and, if not installed and used in
OF QUIRKY. THERE ARE NO OTHER WARRANTIES,
accordance with the instructions, may cause harmful
EXPRESSED OR IMPLIED, INCLUDING THE IMPLIED
interference to radio communications. However, there
WARRANTY OR CONDITION OF QUALITY,
is no guarantee that interference will not occur in a
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
particular installation. If this equipment does cause
PURPOSE, AND SUCH IMPLIED WARRANTIES, IF
harmful interference to radio or television reception,
ANY, ARE LIMITED IN DURATION TO THE TERM OF
which can be determined by turning the equipment
THIS WARRANTY. IN NO EVENT SHALL QUIRKY
off and on, the user is encouraged to try to correct the
BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT,
interference by one or more of the following measures:
INDIRECT OR CONSEQUENTIAL DAMAGES SUCH AS,
BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS
• Reorient or relocate the receiving antenna.
ARISING OUT OF THE SALE OR USE OF ANY QUIRKY
• Increase the separation between the equipment
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
and receiver.
SUCH DAMAGES.
• Connect the equipment into an outlet on a circuit
Some jurisdictions do not allow exclusions or limitations
different from that to which the receiver is connected.
on implied warranties or incidental, consequential or other
damages, so the above exclusions and limitations may not
• Consult the dealer or an experienced radio/TV
apply to you.
technician for help.
This equipment complies with FCC radiation exposure
COPYRIGHT AND TRADEMARK NOTICES
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum
©2014 Quirky, Inc. All rights reserved.
distance 20cm between the radiator & your body.
Quirky is a registered trademark of Quirky, Inc.
The country code selection is for non-US models only
and is not available to all US models. Per FCC
Wink is a trademark of Wink, Inc.
regulations, all Wi-Fi products marketed in US must be
fixed to US operation channels only. GE is a registered trademark of General Electric Company
and is under license by Quirky, Inc.
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the Wi-Fi is a registered trademark of the Wi-Fi Alliance.
following two conditions:
ZigBee is a registered trademark of ZigBee Alliance.
(1) this device may not cause interference, and (2)
Apple and iTunes are registered trademarks of Apple, Inc.
this device must accept any interference, including
interference that may cause undesired operation of
App Store is a service mark of Apple, Inc.
the device.
Android and Google Play are trademarks of Google, Inc.
LIMITED ONE-YEAR WARRANTY
SUPPORT
Quirky, Inc. ("Quirky") Original Purchase Product
Warranty:
Need help?
Quirky warrants to the original purchaser ("Purchaser") of
Email questions@quirky.com
this Quirky product, for the period of one (1) year following
Call 1-866-5QUIRKY
the date on which Purchaser purchases the product, that
the product shall be free of defects in design, assembly,
material, or workmanship.
