WATER DISPENSER
PROFF
WD, WD-E, WD-N, WD-EN, WD-2, WD-E2, WD-N2, WD-EN2, D-I WD ,D-I WD-E, D-I
WD-N, D-I WD-EN, D-I WD-2, D-I WD-E2, D-I WD-N2, D-I WD-EN2
Installation and Operation Manual
17 .4.2014
(Rev. 3.3)
4213317 , 4213319, 4213321, 4213323, 4213325, 4213327 , 4213329, 4213331, 4213341, 4213342, 4213343, 4213344, 4319228, 4319230, 4319232, 4319234, 4319408,
4319410, 4319412, 4319414, 4309870, 4309872, 4309874, 4309876, 4309878, 4309880, 4309882, 4309884, 4309886, 4309888, 4309890, 4309892, 4309894, 4309896,
4309898, 4309899
Advertisement
Table of Contents
Summary of Contents for Metos PROFF WD
-
Page 1: Water Dispenser
WATER DISPENSER PROFF WD, WD-E, WD-N, WD-EN, WD-2, WD-E2, WD-N2, WD-EN2, D-I WD ,D-I WD-E, D-I WD-N, D-I WD-EN, D-I WD-2, D-I WD-E2, D-I WD-N2, D-I WD-EN2 Installation and Operation Manual 17 .4.2014 (Rev. 3.3) 4213317 , 4213319, 4213321, 4213323, 4213325, 4213327 , 4213329, 4213331, 4213341, 4213342, 4213343, 4213344, 4319228, 4319230, 4319232, 4319234, 4319408, 4319410, 4319412, 4319414, 4309870, 4309872, 4309874, 4309876, 4309878, 4309880, 4309882, 4309884, 4309886, 4309888, 4309890, 4309892, 4309894, 4309896, 4309898, 4309899... -
Page 2: Table Of Contents
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER TABLE OF CONTENTS General ...............................3 2.1. Symbols used in the manual ........................3 2.2. Symbols used on the appliance ........................3 2.3. Check ing the relationship of the appliance and the manual ...............3 Safety .................................4 3.1. -
Page 3: General
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER General Carefully read the instructions in this manual as they contain important information regarding proper, effi cient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. -
Page 4: Safety
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Safety 3.1. Safe use of the appliance The appliance must be connected to an earthed socket. STOP When moving or servicing the appliance, always unplug it from the power supply. STOP Modifying the equipment without the approval of the manufacturer invalidates the manufacturer’s STOP product liability. -
Page 5: Functional Description
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Functional description 4.1. Intended use of the appliance The appliance is intented for cooling and dispensing drinking water. 4.2. Structure and operating principle WD, WD-E, WD-N, WD-EN, WD-2, WD-E2, WD-N2, WD-EN2 are free-standing models and designed to be situated in a serving line. -
Page 6: Operating Instructions
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Operating instructions 5.1. Operation Mechanical faucet: Push the lever with a glass. Electronic faucet: Hold a glass under the faucet. 5.2. After operation 5.2.1. Cleaning the exterior surfaces Clean the stainless steel surfaces with neutral, liquid detergents. Abrasive or corrosive agents must not be used. -
Page 7: Installation
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Installation 6.1. General The appliance is designed to function in locations with temperatures of 10°C to 35°C. The appliance must not be installed close to appliances that generate heat, e.g. ranges. 6.2. Storage The appliance should be stored in a dry place, at a temperature over +1°C. -
Page 8: Opening For The Drip Basin (D-I Models)
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Ensure suffi cient air inlet/air circulation for the condenser. Condenser air circulation Do not mount the condenser on a closed plinth, as this will prevent condenser air circulation. Air venting takes place below the appliance and air intake at the front. Do not block the condenser air inlets. -
Page 9: Electrical Connections
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Fixing the mechanical faucet Fixing the electronic faucet Make a water connection between the faucet and the water cooler. Installation sequence: 1. Assemble the faucet 2. Attach the faucet to the drip basin 3. -
Page 10: Adjusting The Glass Fi Lling Rate (Mechanical Faucet)
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER 6.7. Adjusting the glass fi lling rate (mechanical faucet) Water fi lling rate can be adjusted with the help of a screw (1) located on top of the faucet by turning the screw with a screwdriver. -
Page 11: Troubleshooting
In this way you can avoid unnecessary service calls and costs. In all enquiries, please contact the nearest Metos service. Most problems can be mana- ged on the phone. -
Page 12: Technical Specifi Cations
17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Technical specifi cations Refrigeration circuit diagram Connection diagram S00354 A3 Connection diagram S00196 A2 Dimensions, machinery Installation drawing... - Page 13 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Heat exchanger Capillary tube Drier Condenser Compressor Refrigeration circuit diagram...
- Page 14 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Switch wit signal light Thermostat Pump Condenser Compressor Connection diagram S00354 A3...
- Page 15 Connection diagram S00196 A2...
- Page 16 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Dimensions, machinery...
- Page 17 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER Rev.: 3.2 Installation drawing...
- Page 18 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER ITEM TYPE SPECIFICATION Electric connection Cooling and electronic 1/N/PE AC 230V 50Hz Power input Cooling and electronic 0,16 kW Extraction capacity Cooling 180 W, +7°/54° Exterior Cooling R134a Ulkovuoraus Stainless steel Control unit...
- Page 19 17 .4.2014 Rev.: 3.3 METOS WATER DISPENSER...
