SharpShooter DV502 Owner's Manual

Control of the security system
programmed) by the beep of the alarm. If the key is in the position "ignition" the alarm can not be turned on. This protects from the accidental turning on the
alarm while driving. Silent control of the system is programmed by the producer, i.e. turning on off the system the alarm will not beep. To turn on the audible
control apply to the section on the installation manual: Turning on/off the audible control of the security system. Note: the audible control of the security
system is allowed only if used outside the EU. Agrees with the UN directive No.97, regarding the requirements for the vehicle security systems. The
certificate of the conformance 97RA 01 04816.

Turning on the security system.

turn on and LED will blink as many times as many remote controls are programmed, then will start blink fast
(showing input delay time). The alarm will beep if audible control is programmed. When input delay time expires, car
alarm will enter into full turn on mode and LED will start blink slowly. If 30 sec. central lock pulse is programmed (it
could be used for windows, sunroof lifting control) is possible to interrupt it at any time by pressing remote controller
button 1 again (if you would like to leave windows partially opened for example). For higher security when using 30
sec. central lock mode, doors, hood and trunk switches inputs will be activated after 4 sec., but others sensors
inputs will be activated after only 30 sec. (to prevent false alarms).

Turning off the security system.

will blink twice. If the audible control is programmed the alarm will beep twice. The auto lock will unlock the car
doors and LED will stop blinking.
Audible turning on/off of the security system
programming mode). After pressing any button on the remote control corresponding beep of the alarm will be heard,
and silent turn on of the security system will be activated only by pressing button 1 twice.
Silent turn off of the security system.
twice. The turn light will blink twice (the alarm will not beep), the auto lock will unlock the car doors and LED will stop blinking.
Partial turn on of the security system
The turn lights will blink three times (the alarm will beep if audible mode is programmed). LED will start blinking. In this mode the sensors (shock, volume)
are disabled and in this way the people inside the car are safe from the harmful emission of the volume sensor. The alarm is caused only by opening the
doors, boot or engine capote.
Warning about incomplete turning on of the protection.
mode. If during those 4 sec. the input of any sensors is triggered (for example the door is not closed or shock sensor is triggered) the security system going
to protection mode will warn about this by blinking turn lights and beeps of the alarm three times and will block this input automatically. If the sensor will
return to normal protection mode (i.e. the opened door will be closed), then in 3 sec. it will be unblocked and one blink of turn lights will warn about this.
Checking if the protection is turned on.
once.
Turning off the alarm signal.
capote is opened, the additional sensors are triggered or the ignition is turned on, i.e. the turn lights will blink and the alarm will sound for 28 seconds. To
turn off the alarm sound press the button 1 on the remote once (protection mode will remain turned on). The system will not respond to pressing button 2.
Control of auto lock while engine is started.
the remote – the auto lock will lock the doors, and after pressing button 2 – unlock.
Emergency mode / car search.
around the car or looking for the car left in the big parking place.
While the system is in protection mode, press both buttons simultaneously. The turn lights will blink for 10 seconds (the alarm will beep 5 times if audible
mode is programmed). To stop - press button 1.
Other functions
Precise alarm memory.
times (the alarm beeps three times if audible mode is programmed), this means that the system was
in alarm mode. After turning on the ignition and pressing button 2 on the remote it is possible to
determine what caused the alarm according to the number of LED blinks (see Alarm table).
Number of alarms.
it will not cause the alarm. It is designed to stop the infinite false alarms. For example if 5 alarms are induced by malfunctioning shock sensor, the alarm will
not start if this sensor is triggered, although triggering other sensors or opening the doors will cause the alarm.
Control of other installations.
This channel is activated by pressing of both buttons at the same time (protection must be turned off).
V.207
Car alarm system
Press the button 1. The turn lights will blink once, auto lock will
After pressing the button 2 on the remote control the turn light
This option has sense only if the system is turned on in the audible mode. Press the button 2
(for example: when children are left in the car). Press the button 1on the remote three times.
The alarm will be caused if the system is in protection mode and the car doors are opened, the boot/engine
This function is useful for causing short time alarm for chasing away the suspicious persons wandering
If turning off the security system the turn lights blink three
After 5 alarms initiated by the same sensor the sensor are disabled –
With the control channel you can control the electromagnetic car hood lock (if it is connected by installer).
Owner's manual
The turn on / turn off of the alarm is confirmed be the blink of the turn lights and (if
(if this function is allowed in the
In 4 sec. after tuning on, the security system will go to protection
Press button 1 on the remote. If the security system is turned on the turn lights will blink
If the engine is started (the ignition is turned on), then after pressing the button 1 on
DV502
1
2
Alarm table
Number of
What caused the alarm
blinks
1 T he sensor
2 T he door
4 T he boot or engine capote
8 T urning on the ignition was attempted
1/2
