G Make sure you use only the recommended power supplies. Damage caused to the camera or controller by incorrect voltage or wiring is not covered by the warranty. G Cutting the camera cable will void the warranty. EVC300D EVC22ZSD/EVC2KB Speed Dome/Keyboard Controller Colour Dome Camera...
Cautions 1. Please read this manual carefully before beginning the installation work. 2. This dome camera operates using a 24V AC power supply, the voltage input rating marks can be found at the bottom of the dome. 3. This dome camera is manufactured using precision optics and electrical components;...
Camera-Overview The EVC22ZSD Colour Speed Dome Camera is designed for use in high risk applications and can be panned, tilted and zoomed in seconds to the view you require. Features pan tilt speeds of up to 100° per second, a 22x Optical Zoom Lens, and operation down to 0.5 lux.
Camera-Features F. Home position: The home function is available when it is set to ON, namely, this means that the speed dome camera will return the home position (Preset Number 1) if there is no activity in a period of time, additionally the user can adjust the Dwell time.
Camera- Installation Dome Shield Cover Installation Step1- Align the dome core black cover open cut out with the camera lens, then align the four holes on the shield cover with the fours screw holes of the dome camera. Step2- Tighten up the 4x half thread screws. Step 3- Align the dome cover to the dome lock position, rotate clockwise to tighten.
Dome Camera Bracket Installation Step1- Use the diagram shown below to measure out the distances between the four holes required, then drill 4 holes in the chosen mounting location. Fig 1.3 Step 2- Feed the dome connection cable into the bracket hollow pipe. Caution! Before attaching to the wall, check that there is nothing left inside the bracket aperture.
Step 5- Fix the dome to the wall bracket, by tightening the screws, as shown in Fig 1.7. Cautions- Remember to use the washers supplied, with the screws during this step. Fig 1.7 Installation Tip Before fixing the speed dome permanently in position make sure that the baud rate, protocol and camera ID are all set.
Multiple Speed Domes When connecting multiple speed domes, the user can expand the system with additional devices such as a capture device, video matrix, DVR or an alarm box. Fig 1.9 AC24V: The camera’s power supply, will convert 110V/60HZ or 220V/50HZ input to a AC 24V output. RS-485 Bus: The RS485 signal output from the controller connects to the RS485 wires from each of the cameras, allowing one controller to control many speed domes.
Page 10
ON/OFF 1st digit 2nd digit 3rd digit 4th digit 5th digit 6th digit Status Protocol PELCO D PELCO P AUTO ON/OFF 5th digit 6th digit Status Protocol 2400 This dip switch in this example is 4800 set to PELCO D protocol and baud rate of 2400 9600 19200...
Preset Functions Some special protocols, such as “PELCO-D”, “PELCO-P”, have special functions that have no corresponding operation command specified. To allow the user to access the special functions of the camera easily, some of the normal commands have been altered. In general use,use the “Call preset point” and “Set preset point”...
2. Use“Screen Power On/Off” to access the camera menus, then “TELE”, ”WIDE”, ”NEAR” and “FAR” keys for menu item selection. 3. Some video cameras do not provide “Zero Illumination” function or the “Zero Illumination” function may be auto switched and therefore not controlled by command. In this case setting this function will have no effect. 4.
Troubleshooting Problem Possible Reason Solution Power supply module is damaged Replace Power Supply or not enough power After powering on the camera Power cable is not connected or is Check power cable there is movement and no image loose Replace Failure of camera connecting lead Camera mechanism failure Contact your distributor...
Controller- Cautions 1. Please read this manual carefully before beginning the installation work. 2. This controller is for indoor use only, do not use this products in damp or humid conditions, as this may cause a short circuit or electric shock 3.
Controller-Keyboard Panel Controller-Keyboard Operation 1.1. When the power is on, the keyboard will enter the standby mode when the screen displays A*** (*** indicates the dome number at the moment of the last power failure or the default dome number). In this mode, the users can alter the following settings: 1.1 a.
Page 17
1.2 Set the dome address: In standby mode, press numeric key to enter corresponding setup interface (as shown below), press the CAM key to save the current address of the dome or the CLEAR key to return to standby mode. 1.3 Set manual horizontal and vertical moving speed.
Page 18
1.7 Set the Guard Tour (NO.+TOUR+ON) In the standby mode, press numeric key to enter the guard tour number to be edited (as shown below); Press the TOUR and ON keys in order, and press the DOWN key to enter the parameter setting of the first tour point, or the UP key to enter the parameter setting of the 16th tour point.
1.9 Stop tour track operation: Press any of the LEFT, RIGHT, UP and DOWN keys to stop the guard tour operation. 1.10 Delete the tour track (NO.+ TOUR+OFF+NO.+OFF): In the standby mode, enter any number from 1 to 6, then press the TOUR and OFF key to enter the following interfaces displayed (as shown below).
Controller- Specifications Model: EVS2KB Communication Type: Point to multi point semi duplex Communication Interface: RS485 Baud Rate: 2400Bps, 4800Bps and 9600Bps Communication Distance: 1200m (maximum) Max. No. of domes: Power Supply: 12V DC 900mA (9V DC 1000mA) Dimensions (WxHxD): 142 x 140 x 68mm Weight: 0.8Kg TECHNICAL SUPPORT:...
