STEERING WHEEL LEARNING

The steering wheel buttons of the product are appropriate for the original car steering wheel with
non-bus control mode.
The original car's steering wheel buttons should be voltage input control,that is ,when operating each
button,the corresponding inputs of original car audio input different voltage.
Before installation,find out the ground wire,original car steering wheel cables(Caution: some cars have
three wires and others have two),and the steering wheel button power supply line(+5v),then connect
with the corresponding steering wheel buttons power line still have power,no need to connect power line
again,Otherwise,please connect it with the "+5v output of our product's steering wheel buttons function
to use.)
Click the "steering wheel learning" icon on system setting interface to enter steering wheel buttons
setting interface,as the shown picture:
Steering Wheel Control Buttons Setting
Enter the setting interface to select key learning, "steering wheel control reset" firstly,then long press the
buttons on the steering wheel,select the corresponding keys in the interface,
When the setting is successful,the corresponding buttons of interface will light up.
21
