B -A 2 amplifier channels are used for each monitor. One amplifier channel
I MPED
will drive the bass, the other the mids & highs together. Both channels will use
the internal passive crossover, therefore this is not the same as running the
speakers 2
WAY ACTIVE
without the signal passing through the internal crossover.The mid and high
would use a separate amplifier channel with the mid being driven directly from
the amplifier and the high through the internal passive crossover. This method
of running the monitors would require the use of an external electronic
crossover. T VH3208
HE
T -A 3 amplifier channels are used for each monitor. One amplifier
RI MPED
channel will drive the bass, another the mids and the 3rd the highs. All chan-
nels will use the internal passive crossover, therefore this is not the same as
running the speakers
high are driven directly from the amplifier without the signal passing through
the internal crossover. This method of running the monitors would require the
use of an external electronic crossover. T
.
ACTIVE MODE

4.2.2 Passive operation

These monitors can either be installed with a single twin cable, 2 twin cables
(bi-wired) or 3 twin cables (tri-wired). It is recommended that the monitors are
installed bi or tri-wired. This will make a small improvement in sound quality by
minimising distortions produced by voltage losses associated with the interac-
tion of signal currents flowing through the loudspeaker cables. If the speakers
are to be sofit mounted and there is any intention to convert to bi or tri-amped
operation then the speakers should be bi or tri-wired to avoid the need to
remove the speakers from their sofit mounting position when converting.
If installing with a single twin cable the hot or positive wire should be
connected to the appropriate terminal marked (+) and having the red
marking round the screw down knob. The cold or negative wire should be
connected to the corresponding terminal marked (-) and having the black
marking round the screw down knob. The brass connecting links between the 3
where the bass would be driven directly from the amplifier
CANNOT BE RUN IN THE
3 where each set of drive units (bass, mid &
WAY ACTIVE
Passive operation: The connection from the amplifier can be
to any of the terminals, but the connecting links must be kept
in place. The hot or positive wire to the terminal marked (+) red.
and the cold or negative wire should be connected to the
terminal marked (-) black.
or
or
All links remain in place
Page 7
2 .
WAY ACTIVE MODE
VH3208
HE CANNOT BE RUN IN THE
AMPLIFIER
3
WAY
