SMART Cordless TL-2100G Installation And Use Instruction

Quick Start Instructions
1

Install Battery, Adjust Settings

Remove the protective boot.
Insert batteries as shown.
CordLess Monitor settings:
Volume, Melody

Alert Tone/Melody Adjustment

Default Setting: Melody 1
Alert Volume Dial
Default Setting: Full Volume
Close the battery door and
secure it with the small
Phillips-head screw.
Place the monitor in its
protective plastic boot.
3
Test The System for each Pad
Apply pressure to pad
Monitor will beep two times
Status light will blink while pressure remains on pad
When pressure is removed, monitor will alarm
Press reset button to silence alarm or use caregiver key depending on your setting.
A. Test Pad 1
B. Test Pad 2
IMPORTANT: When using the
TL-2100G CordLess® Monitor with two pads,
place all the components (the two pads and the monitor) within 15 feet of each
other. Test the system before each use.
SMART CAREGIVER CORPORATION
Need Set-up Help? (800) 650-3637
2

Program Sensor Pad(s)

The CordLess® Monitor can work in two modes:
1. With one CordLess® bed or chair sensor pad
2. With two CordLess® bed sensor pads
(See separate instructions for CordLess® Floor Mat operation)
Place one or two CordLess bed or chair pads within reach. Each sensor
Melody
Volume
pad comes with a CordLess Transmitter connected and turned on.
3 2 1
Decrease/Increase
-
Press and hold the Program Button on the back of the monitor until
you hear 3 short beeps to enter programming mode. Release the
button.
*NOTE: When there are 2 pads programmed to the monitor and
no one is on the pads, press the reset button twice to reset the
monitor.
Reset Pad 1
Monitor Not
In Use
Pad Signal Pad 2
Lost
Low Battery
Monitor Not Reset Pad 1
In Use
Pad Signal Pad 2
Lost
Low Battery
Resetting the Monitor/Tamper Proof ™ Mode with Caregiver Key ™
Caregivers can choose to reset the
CordLess Monitor in either of two ways:
"Reset Switch ON": Pressing the
Reset/Low Battery button on the
front of the monitor.
"Reset Switch OFF": Placing the
optional Caregiver Key over the red
dot on the front of the monitor.
Option 2 allows only the caregiver to
reset the monitor.
See switch on side of monitor to select the
option of your choice.
For more information about
the Caregiver Key ™ and how it can
be used in your facility's Fall Risk
Assessment Program call
800-650-3637
Tel: 800-650-3637 | www.smartcaregivercorp.com
Program
Button
Monitor Not
In Use
Pad Signal
Lost
Press and hold the Program
Monitor ready to
Button until you hear 3 short
program
beeps to enter programing
mode.
Pad 2
Reset
Monitor Not Pad 1
In Use
Pad Signal Pad 2
Lost
Low Battery
Place pressure on second pad for 3
Monitor ready to
seconds then release to program as
program Pad 2
Pad 2. Monitor beeps twice.
Option 1
Monitor Not Reset
Reset
In Use
Check Low Battery Status/
Pad In Use
Pad Signal
Lost
Low Battery
When using "Reset Button ON" Mode
Press the Reset/Low Battery button to
reset the monitor.
TL-2100G
Pad 1
Reset Pad 1
Pad 2
Low Battery
Place pressure on rst
pad for 3 seconds,
then release to
Pad 1
program as Pad 1.
Monitor beeps twice.
Exit Programming
Program 2nd pad
for single pad use
Reset
Monitor Not Reset Pad 1
In Use
Button
Pad Signal Pad 2
Lost
Low Battery
Press the Reset Button to
exit programming.
(Optional)
Option 2
Pad 1 Monitor Not Reset Pad 1
In Use
OR
Pad 2 Pad Signal Pad 2
Lost
Low Battery
When using "Reset Button OFF"
Place the Caregiver Key ™ over the red dot to
reset the monitor.
