Ace Plus EX-G072 User Manual

8x2 hd/sd-sdi matrix switch
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

ACE PLUS CORP.
EX-G072
8x2 HD/SD-SDI Matrix Switch
User Manual
Page 1 of 7
Headquarters :
9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian,
Taipei, Taiwan 231
TEL: +886-2-2912-4201
FAX: +886-2-2912-3164
Website:
www.ace-plus.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EX-G072 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ace Plus EX-G072

  • Page 1 ACE PLUS CORP. EX-G072 8x2 HD/SD-SDI Matrix Switch User Manual Page 1 of 7 Headquarters : 9F-2., No. 190 Sec. 2 Jung Shing Rd.,Hsin-dian, Taipei, Taiwan 231 TEL: +886-2-2912-4201 FAX: +886-2-2912-3164 Website: www.ace-plus.com...

  • Page 2: Safety And Notice

    However, like all electronic equipments, the EX-G072 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 3 SDI switch becomes versatile and easier. By perfectly duplicating the chosen SDI input, this SDI switch provides two identical outputs, and acts like a SDI splitter. EX-G072 offers the most convenient and cost effective means for swift switch and duplication of high quality SDI in the market.
  • Page 4 0~40°C [32~104°F] Storage temperature -20~60°C [-4~140°F] Relative humidity 20~90% RH [no condensation] 1x EX-G079 / EX-G080 / EX-G078 / EX-G072 1x IR remote controller Package Contents 1x 5V power adapter 1x User Manual The measurement results are from Tektronix VFM-700 with SDI through 1m (3.3ft) long Belden 1694A.

  • Page 5: Panel Descriptions

    ACE PLUS CORP. Panel Descriptions Front Panel 1. Chosen input channel LED 2. Input channel auto detection LED 3. Output HD/SD detection LED 4. IR remote receiver 5. Power indicator LED 6. Push button for input channel switch Rear Panel 7.

  • Page 6: Ir Remote Control

    Hardware Installation 1. Connect SDI enable equipments to the output of EX-G072. 2. Connect the SDI input sources to the inputs of EX-G072. 3. Plug power adapter cable into 5V DC power jack. 4. Use IR remote, RS-232, or front panel push button to switch between input channels.

  • Page 7: Limited Warranty

    ACE PLUS CORP. Limited Warranty The SELLER warrants the EX-G072 8x2 HD/SD-SDI Matrix Switch to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The SELLER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surges.
