Summary of Contents for MindPlace Kasina
- Page 2 3. It is advisable to charge the system for a few hours before initial use. Plug the USB power supply into the mini-USB socket on the top of the console. 4. Before turning your Kasina on, remove the MicroSD card from the SD adapter and push it carefully,...
- Page 3 6. Plug the earbuds (or your own headphones) into the socket to the left of the MicroSD socket. 7. You may now turn on your Kasina by pressing the button on the top of the console for about two seconds. The LCD will display four main icons...
- Page 4 Alternately, you can connect via USB (select USB on the main menu and press the mid-dle button; the Kasina will appear on your Mac or PC as an external drive). Just drag and drop files into the appropriate folder. Note that files will transfer more slowly using the USB connection.
- Page 5 Left button to navigate back to the main menu. Press or press-and-hold the buttons on the left and right sides of the Kasina to adjust volume and brightness. The bars on the top of the display indicate the current volume and brightness levels.
-
Page 6: Troubleshooting And Support
In the event of any problems, please check all of your connections and, if necessary, place your Kasina on charge for at least an hour and then try again. To reset all settings to factory defaults, turn the unit on while holding the audio and light “-“... -
Page 7: Battery Condition
Down button. BATTERY CONDITION At the top right of the Kasina display you will see the battery condition indicator. When connected to a power source (AC power supply or PC USB port) the indicator will repeatedly “fill”... -
Page 8: Advanced Operation
Files created with this format offer a much richer and more subtle experience than does AS. AudioStrobe Your Kasina is also a great AS decoder that can map the two AS signals onto any combination of red, green and blue via the ColorSets. Some ColorSets slowly change the color mapping during a session, creating a more dynamic and complex experience. - Page 9 Service This screen provides technical details about your Kasina - you may be asked to provide some of these details in the event that you require support. Where to find your Kasina serial number In the Settings section, select Service. Your serial number follows the letters SN.
- Page 10 Kasina micro-SD Card Contents When you turn on your Kasina and select Sessions, you’ll notice six numbered folders: SpectraStrobe. AudioStrobe, KBS Sessions, Color Organ, Docs, and KASINA. Though most of your sessions will reside in the SpectraStrobe folder, there is some AudioStrobe...
- Page 11 Where should you start? If you want to quickly get a sense of what the Kasina is capable of, try A Starlit Night or Patternity, in the Mind Art category. Biomarkers (Rejuvenate) is another great place to start…...
- Page 12 Category Length Name Accelerate Before Learning 12:00 Designed for use before class, studies, this starts at 9 Hz and targets 4.5, 7.83, 11.25, and 18 Hz. Cheer Up Accelerate 35:00 Starting at an alert 12 Hz, Cheer Up steps up to a vigorous 35 Hz be- fore makings its way back to a calm 10 Hz.
- Page 13 Category Length Name Everglade Meditate 20:00 A spring morning with gentle rain… time is suspended in this peaceful, calming session. Mostly low to mid range light frequencies to pro- mote calm clarity. Forest and River Meditate 16:00 Another peaceful backdrop of nature, in another locale. Frequencies start at 14 Hz and end at 4 Hz for deeper relaxation.
- Page 14 Category Length Name Touch of Silence Meditate 14:36 Peaceful sounds of Tibetan bowls and minimalist piano sets a calming ambience; lights start at 10 Hz and descent to 6.25 Hz. A Starlit Night Mind Art 15:00 This entrancing, ambient soundtrack and complex visual encoding evokes a clear, Moonless Summer’s night, with shooting stars tracing patterns in the sky.
- Page 15 Category Length Name Mind Art Patternity 20:00 Rich synthesizer textures combine with lush visual effects to create a dreamy, slightly surreal and entrancing mind-scape. Phobos Mind Art 6:00 Your spacecraft has just arrived in orbit around Mars, and the crea- tures living inside Phobos have started communicating with you using sound and light...
- Page 16 Category Length Name Mind Art Stagecraft 20:00 Gazing out across a land never before seen, you feel yourself lifting off the ground, gently riding the currents, always safe and amazed. Trainspot Mind Art 7:02 Variation on a simple EcoSync system. The sound of low rumbling subway train or trip on a space probe lulls you into meditative mind- set.
- Page 17 Category Length Name Rest Night Voyage 30:00 Very slow and subtle modulations of light and sound, intended to quiet your mind before sleep. Sleep Night Voyage 1:00:00 A gradual descent from 10 Hz, pausing at 6 Hz before continuing to very slow modulations.
- Page 18 Category Length Name Clear Your Mind Rejuvenate 16:00 Frequent hops between slower and higher frequencies, together with the relaxing sounds of Tibetan bowls to help restore your mental en- ergy. Starts at 12.8 Hz and ends at 13.5 Hz. Rejuvenate Deep Rejuvenation 24:00 With a starting frequency of 8.5 Hz and a target of just 1.45 Hz, and...
- Page 19 This will take you even deeper than Vapor-Chill, as the slowly shifting drone-structures and beat frequencies lead to towards the edge of sleep. Be sure to visit www.soundcloud.com/mindplace for additional free SpectraStrobe and AudioStrobe sessions, and www.mindplacesupport.com for the latest information and updates...
Need help?
Do you have a question about the Kasina and is the answer not in the manual?
Questions and answers
I boughr a kasina i didn't use it for months the battery is dead and wont take chargé ( completely dead) how can i fix it.
To fix a dead battery in a MindPlace Kasina that won't charge, follow these steps:
1. Reset the Connection:
- Unplug the USB cable from the Kasina.
- Leave it disconnected for 15 seconds while keeping the other end connected to the power source.
- Plug the USB cable back into the Kasina.
- Quickly press the power button.
2. Check Charging Status:
- Observe the battery icon. It should show a "filling" animation until it turns solid green.
- While charging, check the Settings/Service menu for values like battery voltage and charge current.
3. Check the Charger and Cable:
- If charging is very slow or not working, test with a different USB cable.
- If the cable is fine, try using a different USB charger. A charger with at least 5V/1A is recommended.
4. Firmware Update:
- Once the device is fully charged, update the firmware to the latest version.
If the Kasina still does not charge or hold a charge, the battery may need replacement.
This answer is automatically generated
