- Page 1 AW1004M / AW1204M OWNER’S MANUAL...
- Page 2 Judge for yourself, and remember what it’s all about, “If it’s not Bigger, Badder & Better, it’s not Au- diobahn.” If audio is your life, Audiobahn is the brand for you! We make you look as good as you sound.
-
Page 3: Table Of Contents
Table Of Contents Woofer Introduction____________________________________________3 Woofer Features_______________________________________________4 Parameters__________________________________________________5 Box Parameters_______________________________________________6 Enclosure Setup & Troubleshooting_________________________________7 Warning / Disclaimer____________________________________________8 Warranty__________________________________________________9 - 10... -
Page 4: Woofer Introduction
Woofer Introduction Audiobahn woofers are a low frequency driver designed primarily for use in small sealed or vented enclosures depending on the model of sub. Please check the specifications in this manual, our website at www.audiobahn.com. As specifications and parameters are subject to change, we highly advise always checking our website or calling us for the most current information. -
Page 5: Woofer Features
Woofer Features Aluminum Voice Coil Former The voice coil former is black, anodized aluminum for highly efficient thermal transfer. This allows winding high temperature copper wire in multiple layers for improved efficiency. This allows improved power handling by effectively dissipating heat. Spun Aluminum 1 Piece Cone The spun aluminum 1 piece cone offers more stability than any other woofer before. -
Page 6: Parameters
Parameters... -
Page 7: Box Parameters
Box Parameters Audiobahn Box Specifications All ports listed are circle ports unless otherwise stated. Surface area of a circle port = (3.14) X (radius) (squared) Remember to build your box to the total volume, not just air space, as total volume includes all displacement. -
Page 8: Enclosure Setup & Troubleshooting
Enclosure, Setup & Troubleshooting Building an Enclosure To work properly, the walls of the enclosure must be rigid and not flex when subjected to high pressure generated by the speaker’s operation. For optimum performance, we recommend using 3/4” MDF (Medium Density Fiberboard) and internal bracing. The enclosure should be glued together along with support of screws or nails. -
Page 9: Warning / Disclaimer
Disclaimer Specifications are subject to change without notice. For the most updated Specifications call Audiobahn, your local Authorized Audiobahn Dealer, or check the Audiobahn web site. -
Page 10: Warranty
Audiobahn Consumer Product Warranty Policy Audiobahn products are manufactured with the highest quality components and some of the most advanced technology available. Because of this we recommend that you have your new products installed by an Authorized Audiobahn Dealer. (A list of Authorized Audiobahn Dealers can be found on our web page). - Page 11 This might include having an Authorized Audiobahn Dealer look at the product to confirm the source of the problem. Any product found to have a manufacturer defect will be replaced with a new piece of the same or similar model, or repaired at the discretion of Audiobahn.
