Disassembly Procedure

Please follow the information provided in this section to perform the complete
disassembly procedure of the notebook. Be sure to use proper tools.
C
15B Notebook consists of various modules. This chapter describes the procedures for the
complete notebook disassembly. In addition, the detailed disassembly procedure of
individual modules will be provided for your service needs.
The disassembly procedure consists of the following removal steps:
• Battery
• Bottom Door
• ODD Module
• Memory
• HDD Module
• WLAN Card
• Thermal Module
• CPU
• Keyboard
• Top Case Module
• Touchpad FFC
• Power Board FFC
• Power Board
• IO Board FFC
• IO Board
• Motherboard
• Bottom Case
• LCD Bezel
• Camera
1 - 1
Disassembly Procedure
1
Chapter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C15B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ASI C15B

  • Page 1: Disassembly Procedure

    Disassembly Procedure Chapter Disassembly Procedure Please follow the information provided in this section to perform the complete disassembly procedure of the notebook. Be sure to use proper tools. 15B Notebook consists of various modules. This chapter describes the procedures for the complete notebook disassembly.
  • Page 2 Disassembly Procedure • LCD Panel • LVDS Cable 1 - 2...
  • Page 3 Disassembly Procedure Battery B A T T E R Y The illustrations below show how to remove the battery from the notebook. Remove Battery 1. Shut down the operating system, close the LCD panel, turn over the notebook and place it on a clean platform.
  • Page 4: Bottom Door

    Disassembly Procedure Bottom Door B O T T O M The illustration below shows how to remove the bottom door from the notebook. D O O R Remove Bottom Door 1. Remove 3 screws from the bottom door. 1 - 4...
  • Page 5 Disassembly Procedure 2. Use a finger to lift the upper edge of bottom door. 3. Lift to separate the bottom door from the bottom case. 1 - 5...
  • Page 6: Odd Module

    Disassembly Procedure ODD Module The illustrations below show how to remove the ODD module from the notebook. O D D M O D U L E Remove ODD Module 1. Pull the ODD module out from its housing. 2. Apply a force shown in below figure to separate the ODD bezel from the drive. 1 - 6...
  • Page 7 Disassembly Procedure 3. Remove 2 screws to separate the ODD bracket from the drive. Memory M E M O R Y The illustration below shows how to remove the memory from the notebook. Remove Memory 1. Pull 2 socket latches outward until the memory upsprings. 1 - 7...
  • Page 8: Hdd Module

    Disassembly Procedure 2. Pull the memory out from its socket. HDD Module H D D The illustrations below show how to remove the HDD module from the notebook. M O D U L E Remove HDD Module 1. Remove 2 screws from the HDD bracket. 1 - 8...
  • Page 9 Disassembly Procedure 2. Pull the handling mylar left to disconnect the HDD from the motherboard. 3. Lift to remove the HDD module. 1 - 9...
  • Page 10 Disassembly Procedure 4. Remove 4 screws to separate the HDD bracket from the drive. WLAN Card W L A N C A R D The illustration below shows how to remove the WLAN card from the notebook. Remove WLAN Card 1.
  • Page 11 Disassembly Procedure 2. Remove 1 screw from the WLAN card. 3. Pull the WLAN card out from its socket. 1 - 11...
  • Page 12: Thermal Module

    Disassembly Procedure Thermal Module T H E R M A L The illustration shows how to remove the thermal module form the notebook. M O D U L E Remove Thermal Module 1. Disconnect the fan cable from the motherboard. 2.
  • Page 13 Disassembly Procedure 3. Remove 6 screws from the thermal block springs. 4. Lift to remove the thermal module. 1 - 13...
  • Page 14 Disassembly Procedure C P U The illustrations below show how to remove the CPU from the notebook. Remove CPU 1. Use a Torx screwdriver to rotate the lock screw of CPU socket counterclockwise on 180 degrees. 1 - 14...
  • Page 15: Remove Keyboard

    Disassembly Procedure 2. Lift to remove the CPU. Keyboard The illustrations below show how to remove the keyboard from the notebook. K E Y B O A R D Remove Keyboard 1. Remove 1 screw from the bottom case. 1 - 15...
  • Page 16 Disassembly Procedure 2. Turn over the notebook and open the LCD panel. Use a plastic pry slice to release the lock tongue of top case. 3. Release all lock tongues of top case. 1 - 16...
  • Page 17 Disassembly Procedure 4. Lift the upper edge of keyboard to reveal the keyboard connector. 1 - 17...
  • Page 18 Disassembly Procedure 5. Disconnect the keyboard cable from the motherboard and remove the keyboard. Top Case Module T O P C A S E The illustrations below show how to remove the top case module from the notebook. M O D U L E Remove Top Case Module 1.
